Senco XtremePro SCN60XP Specifications

The rugged-duty SENCO SCN60XP Coil Nailer is light enough for
®
one-handed operation, yet is up to 25% more powerful. It can hold up to
275 nails (depending upon nail type) for maximum productivity in a
wide variety of applications.
Applications:
For on-site, manufactured housing, including sheathing, decking,
subflooring, and exterior decks. Also, industrial markets such as
heavy-duty pallet construction, pallet repair, and crate and box
assembly.
Features and Benefits:
• Highest power-to-weight ratio in its class
• Light enough for one-handed operation for quality workmanship and
greater productivity
• Adjustable depth-of-drive allows for precise countersinking at a
lower air pressure
• High load capacity (up to 275 nails)
• Fast cycle time increases productivity
• E-Z load design saves time
• Five year limited warranty
Always read the Operators Manual and Safety Instructions with all tools to ensure proper
use and safety precautions. For additional information on trigger systems and how SENCO
will save you time, reduce costs, and increase quality, call our toll-free Action Line:
800-543-4596 to find your nearest Authorized Senco Dealer, Distributor or visit our web
site at: www.senco.com
©2007 Senco Products, Inc.
XtremePro 2½" Rugged-Duty Coil Nailer
™

Tool Specifications:

Item #: 520101N - Contact actuation
Tool Weight: (Unloaded) 7.5 lbs. (3.4 kg)
Height: 12 ⁄ " (314mm)
3
8
Length: 14" (356 mm)
Collation: Flat, angled coil wire
Operating Pressure: 70-120 p.s.i.g. (4.8-8.3 bar)
Mode of Operation: Tool is avilable with either sequential or contact
actuation trigger mechanism.
Hose Fitting:
Fastener Specifications:
Drives 11, 11.5 and 12.5 Gauge. Round-Head Nails, 2"– 2 ½" 6d to 9d
Nail Range. Capacity 250-275
R
BK (.099)
BL (.099)
GL (.113)
GD (.113)
Choose the right trigger system for your specific needs!
Sequential Actuation Trigger (also known as restrictive trigger or trigger fire)
operates in the following a sequence - depress the safety element at the nose of tool
against the work surface then pull the trigger. After each fastener is driven, release the
trigger and lift the tool off the work surface before starting the sequence again. This
trigger is recommended and acceptable for most applications.
Contact Actuation Trigger (also known as dual action, bounce or bottom fire)
operates in the following sequence- pull the trigger first and keep the trigger pulled
while moving the tool along the work surface with a bouncing motion, depressing
the safety element at the nose of the tool against the work surface where the fastener is
to be driven. This trigger is recommended for use by trained professionals only in
high production or volume applications.
www.senco.com
SCN60XP
⁄ " NPT
3
8
2 2 1 / 2 1 /
4 2
2 3 /
8
®
