Senco FramePro 602 Specification Sheet

Fastening Solutions
Best Value in the Industry!
Full round head nailers are the result of our award-winning
designs and fifty years experience. The FRH nailers feature a
toenail safety, rugged aluminum casting, power to drive a wide
range of full round head nails, even common nails and an
in-line magazine for superior balance and line of sight.
All this and more for the Pro.
Applications:
Framing, truss building, subflooring, sheathing, decking,
siding, fencing, pallets and crate assembly
.
Features and Benefits:
• Sawtooth safety that digs in for precision toenailing
• In-line magazine for superior balance and line of sight
• 602 FRH drives ring and smooth shank nails in four gauges
(.113, .120, .131 and .148) from 2" to 3 -1/2"; 652 FRH drives
four gauges (.120, .131, .148, and .162) from 2-1/4" to 3 -1/2"
• Adjustable exhaust
• Soft comfort grip handle reduces fatigue
• Dry fire lockout
• Adjustable depth-of-drive
• No-mar bumper
• One-year warranty
• Rear two-step loading
• FramePro 652 provides 15% more power than FramePro 602
©2005 SENCO Products, Inc. Litho in U.S.A.
™
www.senco.com
FramePro
FRH Framing/Sheathing Nailer
Tool Specifications:
FramePro 602
Power: 869 in/lbs
Tool Weight: 8.1 lbs (3.7 kg)
Height: 13 .2" (343 mm)
Length: 20.1" (511 mm)
Nail Capacity: 61
Reg. Operating Pressure: 70-120 psig
Mode of Operation: Available with either Dual Action or Restrictive
Trigger activating mechanisms.
Fastener Specifications:
FramePro 602 FRH nailer drives 2" – 3 -
(Sencote or plain) and 2"– 3" ring shank nails. Shank diameters
®
include .113, .120, .131 and .148.
FramePro 652 FRH nailer drives 2-1/4" – 3-1/2" smooth shank
nails (Sencote or plain) and 3" ring shank nails. Shank diameter
®
includes .120, .131, .148 and .162 (common nails).
602/652
®
FramePro 652
992 in/lbs
8.6 lbs (3.8 kg)
14.2" (370.8 mm)
20.1" (511 mm)
61
⁄ " smooth shank nails
1
2
Safety First. ®
The only way to work.
