Senco Products Inc.
8485 Broadwell Road
Cincinnati, Ohio 45244
Warnings for the safe use of this tool are included in this manual.
Questions? Comments?
call SENCO'S toll-free Action-line: 1-800-543-4596
or e-mail: toolprof@senco.com Visit our Website www.senco.com
PC1130 Electric
Air Compressor
Operating Instructions
PC1130 Electric Compressor
Issued Oct. 18, 2006
© 2006 by Senco Products, Inc.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Senco PC1130
Summary of Contents for Senco PC1130
- Page 1 8485 Broadwell Road Cincinnati, Ohio 45244 Warnings for the safe use of this tool are included in this manual. Questions? Comments? call SENCO’S toll-free Action-line: 1-800-543-4596 or e-mail: toolprof@senco.com Visit our Website www.senco.com PC1130 Electric Air Compressor Operating Instructions PC1130 Electric Compressor Issued Oct.
-
Page 8: Compressor Features
COMPRESSOR FEATURES Motor/Pressure Switch Motor Thermal Overload Air Intake Filter Air Compressor Pump Air Tank Drain Valve Air Tank Pressure Gauge Outlet Pressure Gauge Pressure Regulator Dipstick Oil Drain Delivery tube 115 Volt electric power cord Quick disconnect Safety relief valve Cold start valve... - Page 9 1) MOTOR/PRESSURE SWITCH: This switch is used to start or stop the air compressor. Moving the switch to the "Auto" (On) position will provide automatic power to the pressure switch which will allow the motor to start when the air tank pressure is below the factory set "cut-in"...
- Page 10 Remove plug from cylinder head port and replace w/ air filter.
-
Page 11: Operation
PRE-START CHECKLIST: 1. Check oil level. Add if necessary. 2. Remove any moisture in the air compressor air tank. Remove excessive pressure with an air tool or by pulling the safety relief valve ring, then open the air tank drain valve in the bottom of the air tank. Close tightly when drained. - Page 12 ON position, motor runs continuously.
- Page 15 Amperage Oil Capacity Running Duty Type Noise PC1130 1.0 running, 1.5 peak 3400 7 oz. Foam Insert 2.5 gallon 38 seconds 10 seconds 39 lbs 21”x8”x18.5” S1 @ 100 psig 79 dBA...
