  • Page 1 1ST PRINTING MARCH 99 SEGA ENTERPRISES, INC. USA MANUAL NO. 4201-6470-01...
  • Page 2 Warranty Your new Sega Product is covered for a period of 90 days from the date of shipment. This certifies that the Printed Circuit Boards, Power Supplies and Monitor are to be free of defects in workman- ship or materials under normal operating conditions. This also certifies that all Interactive Control Assemblies are to be free from defects in workmanship and materials under normal operating condi- tions.

  • Page 3: Table Of Contents

    INTRODUCTION OF THE OWNERS MANUAL GENERAL PRECAUTIONS 1. PRECAUTIONS TO BE HEEDED FOR OPERATION 2. NAME OF PARTS 3. ACCESSORIES 4. ASSEMBLY AND INSTALLATION 5. PRECAUTIONS TO BE HEEDED WHEN MOVING MACHINE 6. EXPLANATION OF TEST AND DATA DISPLAY 6-1 COIN METER SWITCH UNIT 6-2 TEST MODE 6-3 GAME TEST MODE 6-4 INPUT TEST...

  • Page 4: Specifications

    MONITOR: INTRODUCTION OF THE OWNERS MANUAL SEGA ENTERPRISES, LTD., has for more than 30 years been supplying various innovative and popular amusement products to the world market. This Owners Manual is intended to provide detailed descriptions together with all the necessary installation, game settings and parts ordering information related to the ZOMBIE REVENGE, a new SEGA product.

  • Page 5: General Precautions

    General Precautions Follow Instructions: All operating and use instructions should be followed. Attachments: Do not use attachments not recommended by the product manufacturer as they may cause hazards. Accessories: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product.
  • Page 6 Safety Check: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition. Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other prod- ucts (including amplifiers) that produce heat.

  • Page 7: Precautions To Be Heeded For Operation

    1 . PRECAUTIONS TO BE HEEDED FOR OPERATION In order to prevent accidents, be sure to comply with the following points before and during operation. PRECAUTIONS TO BE HEEDED FOR OPERATION BEFORE STARTING THE OPERATION In order to avoid accidents, check the following before starting the operation: Check if all of the adjusters are in contact with the surface.

  • Page 8: Name Of Parts

    2 . NAME OF PARTS MARQUEE MONITOR CONTROL PANEL CABINET COIN TOWER WEIGHT lbs. WIDTH in. LENGTH in. HEIGHT in. GAME SPECIFICATIONS ~ 300 LBS. All measurements are and rounded UP Weight-DURING SHIPPING WHEN ASSEMBLED 28” 36” 71” 250 LBS.

  • Page 9: Accessories

    TO ‘MODEL 3’ BOARDS CONTAINED IN THE FOLLOWING LOST WORLD, VIRTUA FIGHTER 3, SUPER GT, SEGA BASS FISHING, STRIKER 2HARLEY DAVIDSON, RALLY 2, DAYTONA 2, DIRT DEVILS, HOUSE OF THE DEAD 2, CRAZY TAXI, ZOMBIE REVENGE !!NEVER SHIP MODEL 3 / NAOMI GAME BOARDS OUT-...

  • Page 10: Assembling And Installation

    4 . ASSEMBLING AND INSTALLATION Assembling should be performed as per this manual. Since this is a complex machine, erroneous assembling may cause damage to the machine, or malfunctioning to occur. When assembling, be sure to perform work by plural persons. Depending on the assembly work, there are some cases in which performing the work by a single person can cause personal injury or parts damage.
  • Page 11 SECURING IN PLACE (ADJUSTER ADJUSTMENT) Be sure to have all the Adjusters make contact with the surface. Un- less the Adjusters come into contact with the surface, the Cabinet can move of itself, causing an accident. This machine has 2 each of casters and 4 each of adjusters (shown below). When the installation position is deter- mined, cause the adjusters to come into contact with the floor directly, make adjustments in a manner so that the casters will be raised approximately 5mm.

  • Page 12: Power Supply

    POWER SUPPLY Ensure that the power cord is not exposed on the surface (passage, etc.). If exposed, they can be caught and are susceptible to damage. If damaged, the cord can cause an electric shock or short circuit. Ensure that the wiring position is not in the customer's passage way or the wiring has protective covering.

  • Page 13: Game Test Mode

    ASSYCHECK GAME TEST MODE (ZOMBIE REVENGE) TEST MENU INPUT TEST SOUND TEST GAME ASSIGNMENTS STICK SETTING BOOKKEEPING BACKUP DATA CLEAR ->EXIT SELECT WITH SERVICE BUTTON PRESS TEST BUTTON INPUT TEST This test displays the state of each switch. If this switch goes ON when activated, it is satisfactory.

  • Page 14: Sound Test

    SOUND TEST This allows sound and background used in the game to be checked/ tested. SOUND TEST BGM : 00 SELECT WITH SERVICE BUTTON PRESS TEST BUTTON TO EXIT CRT TEST C.R.T. TEST 1/2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2...

  • Page 15: Precautions To Be Heeded When Moving Machine

    5 . PRECATIONS TO BE HEEDED WHEN MOVING THE MACHINE When moving the machine, be sure to pull out the plug from the power supply. Moving the machine with the plug as is inserted can damage the power cord and cause a fire or elec- tric shock.

  • Page 16: Explanation Of Test And Data Display

    6 . EXPLANATION OF TEST AND DATA DISPLAY By operating the switch unit, periodically perform the tests and data check. When installing the machine initially or collecting cash, or when the machine does not function correctly, perform checking in accordance with the explanations given in this section.

  • Page 17: Switch Unit And Coin Meter

    6 - 1 SWITCH UNIT AND COIN METER Never touch places other than those specified. Touching places not specified can cause electric shock and short circuit. Adjust to the optimum sound volume by considering the environmental requirements of the installation location. If the COIN METER and the game board are electrically disconnected, game play is not possible.

  • Page 18: Test Mode

    3.) Bring the arrow to the item of Game TEST MODE and press the TEST button to display the GAME TEST MENU peculiar to ZOMBIE REVENGE. See the next page onward. 4.) Upon finishing the test, bring the arrow to EXIT and press the TEST button to return to the Gam Mode.

  • Page 19: Input Test

    6 - 4 INPUT TEST This test displays the state of each switch. If this switch goes ON when activated, it is satisfactory. Display varies depending on the JOYSTICK TYPE setting in (3) GAME ASSIGNMENTS. INPUT TEST START1 :OFF START2 SW_SHOT 10 :OFF SW_SHOT 20 :OFF SW_SHOT 11 :OFF...

  • Page 20: Game Assignments

    6 - 6 GAME ASSIGNMENTS GAME ASSIGNMENTS JOYSTICK TYPE ANALOG GAME DIFFICULTY NORMAL MAX LIFE VIOLENCE MODE ->EXIT SELECT WITH SERVICE BUTTON PRESS TEST BUTTON TO EXIT (A) JOYSTICK TYPE (ANALOG, DIGITAL (NORMAL)) This allows the Control Panel’s JOYSTICK TYPE to be selected. (B) GAME DIFFICULTY (VERY EASY, EASY, MEDIUM EASY, NORMAL, BITS HARD, MEDIUM HARD, HARD, VERY HARD)

  • Page 21: Stick Setting

    6 - 7 STICK SETTING If the JOSTICK TYPE is set to ANALOG in (3) GAME ASSIGNMENTS, the ANALOG STICK volume can be adjusted. UP - DOWN: (VOLUME 0) 1P LEFT - RIGHT: 00 (VOLUME 1) UP - DOWN: (VOLUME 4) 20 LEFT - RIGHT: (VOLUME 5 ) PRESS TEST BUTTON TO EXIT...

  • Page 22: Bookkeeping

    6 - 8 BOOKKEEPING This test mode allows each of the CREDIT/TIME/GAME data to be ascertained. NUMBER OF GAMES NUMBER OF CONTINUE 0 TOTAL COIN COIN CREDIT SERVICE CREDIT TOTAL CREDIT TOTAL TIME PLAY TIME AVERAGE PLAY TIME LONGEST PLAY TIME SHORTEST PLAY TIME (A) NUMBER OF GAMES 1P, 2P total game playfrequency.

  • Page 23: Bookkeeping

    Page 2/2 displays by-play-time play frequency. 0M00S ~ 0M29S 0M30S ~ 0M59S 1M00S ~ 1M29S 1M30S ~ 1M59S 2M00S ~ 2M29S 2M30S ~ 2M59S 4M00S ~ 4M29S 4M30S ~ 4M59S 5M00S ~ 5M29S 5M30S ~ 5M59S 6M00S ~ 6M29S 6M30S ~ 6M59S 7M00S ~ 7M29S 7M30S ~ 7M59S 8M00S ~ 8M29S...

  • Page 24: Cleaning The Coin Selector

    7 . COIN SELECTOR HANDLING THE COIN JAM If the coin is not rejected when the REJECT BUTTON is pressed, open the coin chute door and open the selector gate. After removing the jammed coin, put a normal coin in and check to see that the selector correctly functions.
  • Page 25 OPTIONAL DOLLAR BILL ACCEPTOR THE COIN DOOR ASSEMBLY USED ON ZOMBIE REVENGE EQUIPPED TO ACCEPT A DOLLAR BILL ACCEPTOR. ALL NEEDED WIRING CONNECTIONS ARE CONVIENENTLY LOCATED INSIDE THE GAME FOR THIS APPLICATION. THE COIN DOOR CAN ACCCOMMODATE THE FOLLOWING VALIDATORS:...

  • Page 27: Monitor

    (plug) before starting work. Proceeding the work without following this instruction can cause electric shock of malfunctioning. Using the monitor by converting it without obtaining a prior permission is not allowed. SEGA shall not be liable for any malfunctioning and accident caused by said conversion.

  • Page 28: Cleaning The Crt Surfaces

    For the purpose of static prevention, special coating is applied to the CRT face of this product. To protect the coating, pay attention to the following points. Damaging the coating film can cause electric shock to the customers. For the caution to be heeded when clearing, refer to the Section of Periodic inspection Table.

  • Page 30: Replacement Of Fluorescent Lamp

    9. REPLACEMENT OF FLUORESCENT LAMP When performing the work, be sure to turn power off. Working with power on can cause an electric shock or short circuit acci- dent. The Fluorescent Lamp, when it gets hot, can cause burns. Be very careful when replacing the Fluorescent Lamp.

  • Page 31: Periodic Inspection Table

    10. PERIODIC INSPECTION TABLE The items listed below require periodic check and maintenance to retain the performance of this machine and ensure safe operation. Be sure to check once a year to see if Power Cords are damaged, the plug is securley inserted, dust is accumulated between the Socket Outlet and the Power Plug, etc.

  • Page 32: Troubleshooting

    11. TROUBLESHOOTING Should trouble occur, first check connector connections. PROBLEMS CAUSE With Main SW Power is not supplied. ON, no activation Power supply/voltage is not correct. Irregular sound Greasing to gear mesh portion is not emitted from satisfactory, or extraneous matter inside Cabinet mixed in.

  • Page 33: Game Board

    12. GAME BOARD In order to prevent an electrical shock, be sure to turn power off before performing work by touching the interior parts of the product. Be careful so as not to damage wirings. Damaged wiring can cause an electric shock or short circuit accident.

  • Page 34: Composition Of The Game Board

    12 -2 COMPOSITION OF GAME BOARD Ensure that the DIP SW setting is performed as designated as designated. Failure to observe thisw may cause functioning not suitable for tyhe operation, or mal- functioning. ASSY CASE NAO USA (840-0003D-01) : ZOMBIE USA DIP SW SETTINGS...

  • Page 35: Design Related Parts

    13. DESIGN RELATED PARTS ITEM NO. PART NO. DESCRIPTION 999-0777 MARQUEE PLEX ZBX 999-0780 SUB INSTR SH ZBX 999-0779 INSTRUCTION SHEET ZBX 999-0778 CONTROL PANEL OVERLAY ZBX 999-0775 STICKER CABI LEFT ZBX 999-0776 STICKER CABI RIGHT ZBX...

  • Page 36: Parts List 33~44

    14. PARTS LIST TOP ASSY ZBX...
  • Page 37 TOP ASSY ZBX ITEM NO. NOT AVAILABLE* SEE DESCRIPTION* SEE DESCRIPTION* SEE DESCRIPTION* * THESE ITEMS ARE NOT SOLD AS COMLETE UNITS, PLEASE SEE INDIVIDUAL ASSEMBLIES FOR PART NUMBERS OF ALL ITEMS CONTAINED ON THEM. PART NO. DESCRIPTION ASSY SUB-CABINET ZBX ASSY BILLBOARD ZBX ASSY COIN TOWER HOD1-1570...
  • Page 38 ASSY SUB CABI ZBX...
  • Page 39 ASSY SUB CABI ZBX ITEM NO. NOT AVAILABLE* SEE DESCRIPTION* SEE DESCRIPTION* 000-T00420-W 000-T00516-0B * THESE ITEMS ARE NOT SOLD AS COMLETE UNITS, PLEASE SEE INDIVIDUAL ASSEMBLIES FOR PART NUMBERS OF ALL ITEMS CONTAINED ON THEM. PART NO. DESCRIPTION ASSY SUB-CABINET ZBX UP-1018 AIR VENT ASSY ELEC BASE...
  • Page 40 ASSY BILLBOARD ITEM NO. LOCAL PURCHASE LOCAL PURCHASE PART NO. DESCRIPTION 999-0777 MARQUEE PLEX FL BALLAST 20W FL BULB 20W...
  • Page 41 ASSY CONTROL PANEL ITEM NO. PART NO. 999-0783 509-5560-Y 610-6723-4C01 509-5561-G DESCRIPTION CONTROL PANEL PLATE ZBX NAO PB SW W/L 6V 1L Y ASSY ANALOG JOY 4C GREEN PB SW W/L 6V 5L G...
  • Page 42 ASSY COIN TOWER ITEM NO. *This is a COIN CONTROLS PART No. and can be ordered through them, please view insert in the COIN DOOR Chapter of this manual for more information. PART NO. DESCRIPTION SPG1-0350 SW UNIT DP-1167 TNG LKG BOX-CASH CASH BOX 105-5202...
  • Page 43 ASSY SW UNIT (SPG5-0350) ITEM NO. PART NO. DESCRIPTION SPG5-0351 SWITCH BRKT 509-5028 SW PB 1M 220-5179 VOL CONT B-5K OHM 601-0042 KNOB 22MM 220-5412 MAG CNTR W/CONN 509-5453-91-V-B ROCKER SWJ8 V-B...
  • Page 44 ASSY AC UNIT (DRT1-0400) ITEM NO. PART NO. DESCRIPTION SPG1-0401 AC BRKT 600-5843-25 CA & PLUG ASSY 15A W/F-L=2.5M 280-5134-6N34 BUSHING STRAIN RELIEF 6N34 LOCAL PURCHASE FUSE 5A 509-5453-91-V-B SW ROCKER J8 V-B...
  • Page 45 ASSY MONITOR 29TYPE 31K (HOD1-1570) ITEM NO. PART NO. DESCRIPTION AIN-1026 MONITOR BRKT A AIN-1027 MONITOR BRKT B 280-5112 BUSH FOR TV 280-5113 COLLAR FOR TV 280-5114 SPACER 6.4-25X2 200-5787 ASSY CLR DSPL 29TYPE 31K 100V 000-P00512-W M SCR PH W/FS M5X12 050-F00600 FLG NUT M6...
  • Page 46 ASSY ELEC BASE ITEM NO. PART NO. DESCRIPTION NOT AVAILABLE WOODEN BASE ELEC LOCAL PURCHASE FUSE BLOCK W/ FUSES 560-5360-01 XFMR 12.8V 6.3A 34V 4.2A 837-13551-91 I/O BD 840-0003D-01 NAOMI BD zbx 400-5397 PWR SPPLY 838-13616 AUDIO POWER AMP 2CH...
  • Page 47 ASSY SHIELD CASE NAO ZBX (840-0003D-01) ITEM NO. 840-0003A-01 PART NO. DESCRIPTION SHIELD CASE ZBX NAO USA 840-0003C ROM CASE NAO...
