Sievert Crane & Hoist BUDGIT 2ton Installation Instructions Manual

BUDGIT
Disconnect power source from hoist. Lock disconnect in the off position
and tag to prevent accidental application of power.
Disconnect motor and brake leads from the controls.
Remove brake and motor.
Remove contactor and install provided contactor (4-normally open).
Note: 3-normally open-1-normally closed contactor will not function properly
Install motor, pulling wire leads through the gear case wire passage.
Install brake using provided hardware.
·
(2) NO2112 - 3/8-16 x 1" Hex socket head cap screw
·
(2) 10095703 - 3/8" Lock-washer, socket head cap screw
·
(1) 10119413 - External retaining ring 0.625" outside diameter 0.035" thick
Wire the hoist using the provided (3) 22700310 - 7.5" black wire jumpers and the
appropriate wiring diagram.
·
Sheet 2 - 115V single phase without transformer
·
Sheet 3 - 230V single phase without transformer
·
Sheet 4 - 115V single phase with transformer
·
Sheet 5 - 230V single phase with transformer
·
Sheet 6 - 230V three phase, single speed hoist
·
Sheet 7 - 460V three phase, single speed hoist
·
Sheet 8 - 200V or 575V three phase, single speed hoist
·
Sheet 9 - All voltages, two speed hoist
Power unit and test per the procedure outlined in section 7-12, of the Operation, Parts,
and Service Manual.
April, 2007
For more information contact: Sievert Crane and Hoist, (708) 771-1600, parts@sievertelectric.com, www.sievertcrane.com
®
COPYRIGHT 2007, Lift-Tech International, division of Columbus McKinnon Corporation
INSTALLATION INSTRUCTIONS RETROFIT
REPLACEMENT KIT BUDGIT
HOIST AC MOTOR BRAKE
ELECTRIC
®
PART NO. 113535-34
