SECO-LARM ENFORCER Stand-Alone Proximity Reader PR-112S-A Specification Sheet

The ENFORCER Stand-Alone Proximity Reader provides
a flexible solution for controlled access. The stylish case
and small size make it ideal for use in offices, homes and
apartments. The wave-shaped tri-color LED status bar
accents the case design. Simple installation, quick
programming, and high reliability are combined in the
PR-112S-A Stand-Alone Proximity Reader.
Features:
Sealed and weatherproof (IP67).
Tri-color wave-shaped LED status bar indicates proximity
reader's mode and status.
Blue On/Valid Card Indicator
Green Programming Mode
Red Invalid Card
Output relay for either time (1 to 180 seconds) or "Toggle" mode.
Egress input for easy exiting.
Buzzer for audible confirmation or silent mode (programmable).
Up to 100 user cards can be programmed.
User cards easily deleted. Delete a single card, or all cards.
Up to 5 "Master" cards can be programmed.
10 Cards included.
(additional cards available, Model # PR-K1S1-A)
Dimensions:
Front
3 / " 3
4
(95mm)
1 / 3 " (44mm)
4
/ " " /
11 13
16
16
(17mm) (21mm)
Copyright 2007 SECO-LARM U.S.A., Inc. All rights reserved.
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
16842 Millikan Avenue, Irvine, CA 92606
Wire Coding:
RED -- (+) 12VDC
5
/ "
8
(16mm)
BLACK -- (-) GND
BLUE -- Egress Input
1 / 9 "
16
(40mm)
YELLOW -- N.C.
GRAY -- N.O.
BROWN -- COM
" /
13 16
(21mm)
11 / "
16
(17mm)
" /
13
16
(21mm)
1.949.261.2999 (CA & Int'l)
Email: info@seco-larm.com

Technical Specifications:

Power Input 12VDC
Current Draw Standby:
Active:
Max. Read Distance 6" (15cm)
User Card Limit 100 cards
Master Card Limit 5 Cards
Transmit Frequency 125Khz
Outputs 1 Relay (Com, N.O., N.C.)
Contact Rating 1A @ 30V
Relay Time Delay 1~180 secs. / Toggle Mode
Temperature -4 ~158 F (-20 ~70 C)
Enclosure Rating IP67
Dimensions 3 / " x 1 / " x / " (95 x 44 x 17 mm) 11
1.800.662.0800 Fax: 1.949.261.7326
Website: www.seco-larm.com
10 cards included
Model #: PR-K1S1-A
PR-112S-A
80mA @ 12VDC
200mA @ 12VDC
o o o o
3 5
16 4 8
