Electric Deadbolt
Model: SD-997B
Adds concealed deadbolt security to
most wood or hollow metal doors,
with the added convenience of
electrical operation.
* With control wire
which allows for
releasing without
cutting unit's power.
Stainless steel bolt,
Fail-safe operation (unlocks if power is lost).
Door open/close monitor (NO/C/NC).
Adjustable door lock delay timer —
(0, 2.5, 5, or 9 seconds).
Control wire allows release without cutting
unit's power.
Magnetic switch determines door position
for positive locking.
Solenoid shuts off if door not closed properly
to prevent burning out.
Use with an optional digital keypad for high
security without a key.
Easily connects to SECO-LARM's SK-983A
Electronic Keypad.
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
For more information, contact
SECO-LARM U.S.A., Inc.
®
16842 Millikan Avenue
Irvine, CA 92606
Copyright© 2001 SECO-LARM U.S.A., Inc.
/ " diameter, / " throw.
5 5
8 8
Suitable for office-type applications.
Shallow design for use with most metal
door jambs.
Powered by a solenoid.
Stainless steel for strength and long life.
Power — 12VDC, 900mA on activation, 360mA
on standby
Lock body (faceplate) dimensions —
7 / " x 1 / " (200 x 32mm).
7 5
8 16
Lock body (cavity) dimensions —
5 / " x 1 / " x 1 / " (145 x 28 x 38mm).
3 1 1
4 8 2
Strike plate dimensions —
3 / " x 1" x 1 / " (90 x 25 x 3mm).
9 1
16 8
