Pro-Form 535LE User Manual

Pro-Form 535LE User Manual

Sears, roebuck and co trademill user's manual 535le
Hide thumbs

Advertisement

Table of Contents

Model No. 831.298400
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number
Decal
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
¨
USER'S MANUAL
SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 535LE and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form 535LE

Summary of Contents for Pro-Form 535LE

  • Page 1 Serial Number Decal CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Save this manual for future reference. ¨ USER'S MANUAL SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179...

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........
  • Page 3 35 or persons with pre-existing health problems. Read all instructions before using. SEARS assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    And when youÕre not exercising, the unique 535LE can be folded up, requir- ing less than half the floor space of other treadmills. For your benefit, read this manual carefully before using the treadmill.

  • Page 5: Assembly

    This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 6 With the help of a second person, carefully tip the Uprights (82) back to the upright position. 5. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place a mat under the treadmill.

  • Page 7: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. Such substances will deteriorate the walking belt and cause excessive wear.

  • Page 8: Console Diagram

    PLUG IN THE POWER CORD on page 7). When you are ready to begin exercising, step onto the foot rails of the treadmill. Find the clip attached to the key (see the drawing above), and slide the clip onto the waistband of your clothing.
  • Page 9 Change the incline of the treadmill as desired. To change the incline of the treadmill, press the incline buttons. Each time one of the buttons is pressed, the incline will change by 0.5%. The but- tons can be held down to change the incline rapidly.
  • Page 10 SPEED button to change the unit of measurement. The TIME/PACE display will show the total number of hours the treadmill has been used. The SPEED display will show the total number of miles that the walking belt has moved. To exit the information mode, remove the key from the...

  • Page 11: How To Fold And Move The Treadmill

    HOW TO LOWER THE TREADMILL FOR USE 1. Refer to drawing 2 above. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, slide the storage latch to the left and hold it. Pivot the treadmill down until the frame is past the storage latch.

  • Page 12: Maintenance And Trouble-Shooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see 1. c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 13 3 to 4 inches off the walking platform. Be careful to keep the walking belt centered. Plug in the power cord, insert the key and run the treadmill for a few minutes. Repeat until the walking belt is properly tightened.

  • Page 14: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be Òaerobic.Ó...

  • Page 15: Part List

    PART LISTÑModel No. 831.298400 Key No. Qty. Description Motor Belt Pulley/Flywheel/Fan Motor Nut Motor/Pulley/Flywheel/Fan Incline Motor Bolt Incline Motor Spacer Incline Motor Stop Bracket Small Nut Star Washer Optic Switch Frame Small Bolt Incline Optic Disk Incline Motor Nut Screw Plastic Stand-Off Hood Bracket (short) Hood Bracket (long)

  • Page 18: Replacement Parts

    SEARS TREADMILL EXERCISER, contact the nearest SEARS Service Center throughout the United States and SEARS will repair or replace the TREADMILL EXERCISER, free of charge. This warranty does not apply when the TREADMILL EXERCISER is used commercially or for rental pur- poses.
