Wall Mount Installation; Installing/Removing The Base Stand; Mounting On The Wall - ProScan PLDED3996A-E Instruction Manual

Front Front
(long) (long)
Screws
Screw holes
4 pcs
This unit is VESA-compliant, and is designed to be wall-mounted with a VESA-compliant 7.8"x7.8".
(200mm x 200mm)
1*-- The length of the two screws(size M5×10 screw) should not exceed 12 mm.
2*--When installing a wall hanging, please remove the shell after the four SJ2828-87 M5×10.
self-tapping screws (see chart), put on the hanging bracket, use remove.
self-tapping screw assembly in the original position (not screws substitute) with it.
1*
8"
8"
2*
1
2
Front
(long) (Short)
3
