- Page 1 OWNER’S MANUAL Model No. 47002 6/2 AMP MANUAL BATTERY CHARGER CAUTION: Read and Follow All Safety Rules and Operating Instructions Before Every Use of this Product. Sears Canada Inc., 222 Jarvis St., Toronto, Ontario, Canada M5B 2B8...
-
Page 2: Table Of Contents
Please read this Owner's Manual before using your Battery Charger The Sears model 47002, Manual Battery Charger, offers a wide range of features to accommodate the needs for home or light commercial use. This manual will show you how to use your charger safely and effectively. -
Page 3: Sears 002 - Sch 548 11/2/95
If this occurs, flush eyes immediately with running cold water for at least 10 minutes. Then immediately get medical attention. Sears 002 - Sch 548 11/2/95 – SAVE THESE INSTRUCTIONS – To reduce the risk of explosion, explosive gases, or injury while using your battery charger, follow the precautions listed below: •... -
Page 4: Parts
Parts This section shows an illustration of your battery charger. Use it to become familiar with where all the parts are located, and what they look like. Replacement Parts List Sears 47002 Item Description Cover Heatsink/Diode Assembly Base AC Power Cord... -
Page 5: Sears 002 - Sch 548 11/2/95
• Make sure that the wire size is large enough for its length and for the AC ampere rating as specified in the accompanying chart. Sears 002 - Sch 548 11/2/95 MINIMUM RECOMMENDED EXTENSION CORD Length of Cord, in Feet... -
Page 6: Sears 002 - Sch 548 11/2/95
A spark may be caused if all accessories in the vehicle are not completely turned off. NOTE: A marine battery installed in a boat must be removed and charged on shore. Sears 002 - Sch 548 11/2/95... -
Page 7: Using Your Battery Charger
Battery Charger our Battery Charger For best results from your battery charger, learn to use it properly. This section tells how to set the controls and how to charge a battery in or out of the vehicle. Setting the Controls... - Page 8 (1) from the chassis connection and, (2) from the battery post or terminal. 12. Clean and store the battery charger in a dry location. Charging your battery outside the vehicle: 1. Remove the battery from vehicle, making sure to disconnect grounded terminal first with all accessories and lights turned off in the vehicle.
-
Page 9: Calculating Charge Time
To convert Reserve Capacity to Amp Hours, divide Reserve Capacity by 2, and add 16: Amp Hours = Reserve Capacity + 16 Sears 002 - Sch 548 11/2/95 • Marine, or deep-cycle batteries are usually rated in Reserve Capacity (RC). -
Page 10: Maintenance And Care
This will help prevent acci- dental damage to the cords and charger. 3. Occasional cleaning of the case of the charger with a soft cloth will keep the finish shiny and help prevent corrosion. Sears 002 - Sch 548 11/2/95... -
Page 11: Troubleshooting
Separate the clamps. Circuit breaker cycles when current draw is too high. Check for worn cables and replace if needed. Have qualified Sears technician test the battery. Correct connections. Use shorter or heavier extension cord. Sulfated battery will eventually take a normal charge if left connected. - Page 12 OWNER’S MANUAL Model No. 200.47002 When requesting service or ordering parts, always provide the following information: • Product Type • Model Number • Part Number • Part Description 0000000548-1195 6/2 AMP MANUAL BATTERY CHARGER For information about troubleshooting Call toll-free from anywhere in the U.S.A. or Canada...
