Setting the MDS Kit installation option

Set SEG23, the MDS Kit installation option of the indoor unit where the MDS Kit is installed, to the desired value with
referring to the table below.
SEG23
Function
0
1
Off after 20 min. (from the last motion detection)
Standard
2
3
4
Premium
5
6
SOFT OFF: The indoor unit turns off its operation at the indicated time in the table for Installation Option after its final
motion detection. But, it turns on again if the MDS detect motion.
HARD OFF: Designated time after SOFT OFF, it cannot turn on automatically when it detect motion. Users should control to
turn on the indoor unit with remote controller, etc.
NOTE
Detectable MDS area: 6 m radius at 2.7 m height.
When the air conditioner supports the Wind-Free Cooling function, it operates the Wind-Free Cooling function
automatically before the air conditioner turns off.
air conditioner is turned off for energy efficency.
In the Standard mode, you can only turn on/off the air conditioner.
In the Premium mode, you can also operate the functions such as turning on/off the air conditioner, comfort
temperature and comfort saving controls.
The MDS sensor may detect other heat sources, not humans, and perform the MDS functions.
MDS Button Click
Standard
Premium
Soft Off + Hard off
Disuse
Off after 40 min.
Off after 80 min.
Off after 20 min.
Off after 40 min.
Off after 80 min.
Once
Turn on
Indirect Flow
SEG23
7
8
9
A
B
C
Twice
Turn off
Direct Flow
Soft Off only
Off after 20 min.
Off after 40 min.
Off after 80 min.
Off after 20 min.
Off after 40 min.
Off after 80 min.
Three times
-
Turn Off
English
7
