SeaLand BASIC HOLDING TANK SYSTEM Owner's Manual

Basic holding tank system for vacuflush and other marine sanitation systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BASIC HOLDING TANK SYSTEM
OWNER'S MANUAL
For VacuFlush
and other marine sanitation systems
®
!
WARNING
This manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can
result in property damage.
Dometic Corporation • Sanitation Systems
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
SeaLand Product Customer Service: 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BASIC HOLDING TANK SYSTEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SeaLand BASIC HOLDING TANK SYSTEM

Summary of Contents for SeaLand BASIC HOLDING TANK SYSTEM

  • Page 1 BASIC HOLDING TANK SYSTEM OWNER'S MANUAL For VacuFlush and other marine sanitation systems ® WARNING This manual must be read and under- stood before installation, adjustment, service, or maintenance is performed. Modification of this product can result in property damage.
  • Page 2 Leak-Proof Design: All hose connections in SeaLand holding tanks are on the top of the tank, eliminating possibility of leakage due to a faulty connection below the liquid level of the tank contents. Our unique diptube design reduces the risk of plugging while keeping the residual contents in the tank to a minimum.
  • Page 3 INSTALLATION CHOOSING A LOCATION FOR THE BASIC HTS As a general rule, the HTS should be positioned as low in the hull as possible with all interconnecting hoses or pipes sloped to permit gravity drainage and prevent potential hose odor permeation. The holding tank must not be exposed to temperatures above 120°F (45°C).
  • Page 4 INSTALLATION (cont’d) PLUMBING CONNECTIONS AND HOSE LAYOUTS When connecting flexible hose to plastic fittings, use liquid dish soap on end of fitting and inside hose end to make connection easier. Do not use any other lubricants, sealants or adhesives when connecting sanitation hoses and fittings. Do not restrict the ability to pull the hose or pipe.
  • Page 5 SERVICE ACCESS Because SeaLand holding tanks may require minimal service in normal operation, the tank must be installed so that there is easy access to the tank inspection port, discharge pump and vent filter (if installed).
  • Page 6 PLUMBING FITTINGS, HOSE AND PIPE SeaLand® valves and fittings are designed for use with 1-1/2" (38mm) ID OdorSafe® Plus sanitation hose and 1-1/2" (38mm) PVC pipe. HOSE BALL VALVE PART NO. DESCRIPTION 307346087 Ball Valve Non-corrosive PVC with Teflon HOSE FITTINGS PART NO.
  • Page 7 OPTIONAL HTS COMPONENTS TankWatch 4 Level Monitor and Micro-Float ® Switches Includes four tank level indicator lights – Empty, Low, Mid and Full, and international symbology of four tank levels. One light is always on. Reliable micro-float switches are installed in holding tank. No electrical components come in contact with waste or water.

  • Page 8: Ordering Parts

    35 countries plus approximately 65 distributors globally. 600344867 1/04 Dometic Corporation • Sanitation Systems 13128 State Rt 226, PO Box 38 SeaLand Product Customer Service: 1-800-321-9886 Registered; ™ Trademark of Dometic Corporation Big Prairie, OH 44611 (8:00 a.m. - 5:00 p.m. ET) 2004 Dometic Corporation...
