  • Page 1 Infrared Camera Instruction Manual: IR0018 www.perfectprime.com for product register and warranty...

  • Page 2: Table Of Contents

    Contents 1. Overview---------------------------------------------------------------------------------------1 2. Considerations and Safety Maintenance---------------------------------------------------1 3. Performance Index----------------------------------------------------------------------------2 4. Product Description---------------------------------------------------------------------------3 5. Initial Operation-------------------------------------------------------------------------------5 6. Introduction to “Setting” Submenu---------------------------------------------------------6 7. Color Palette-----------------------------------------------------------------------------------7 8. Application of Color Palette and Image Check-------------------------------------------8 9. Time Setting-----------------------------------------------------------------------------------9 10. Capture Thermal Points---------------------------------------------------------------------9 11.

  • Page 3: Overview

    USB or saved in a computer to generate report and printing. IR0018 is easy to use; Test may be conducted in several seconds after powering on. The product can be used in fields of medical treatment, fire fighting, archaeology,...

  • Page 4: Performance Index

    3. Performance Index Display screen 3.2” full angle TFT display screen Infrared image resolution 220 ×160 visible image resolution 0.3 million pixel Field angle/shortest focus length 27°× 35°/0.5m Thermal sensitivity 0.07°C Temperature measurement range -20~300°C (-4°F~572°F) Test and measurement precision ±2.5°C or ±2.5% Emissivity Adjustable from 0.1 to 10.0...

  • Page 5: Product Description

    4. Product Description 4.1. Instruction to structure...
  • Page 6 4.2. Key description Central point temperature cursor: The central position temperature at the screen area. Thermal point temperature cursor: The cursor moves along with the highest temperature within the screen area and the location of cursor is the highest temperature. Cold point temperature cursor: The cursor moves along with the lowest temperature within the screen area and the location of cursor is the lowest temperature.

  • Page 7: Initial Operation

    4.3. Key description On/off key Menu/Yes key Select/No key Enter key Navigation key: Up, down, left and right 5. Initial Operation 1. Charging: the product is provided with built-in 18650 lithium battery. When the battery power is not sufficient, please charge it through Micro USB interface in time.

  • Page 8: Introduction To "Setting" Submenu

    6. Introduction to “Setting” Submenu...

  • Page 9: Color Palette

    7. Color Palette The menu of color palette can change the false color on the display screen or capture infrared image. The product provides five types of color palette: rainbow, iron oxide red, cold color, black white and white black. Suitable selection of color palette displays the details of the target objective better.

  • Page 10: Application Of Color Palette And Image Check

    8. Application of Color Palette and Image Check 8.1. Application of color palette Press “SELECT ” to select; Press “ ” to return. Press “ ”/“ ” to adjust the selected items. 8.2. Check images Press “SELECT” key to select; press “Enter” key to return under the interface of image check.

  • Page 11: Time Setting

    9. Time Setting Press “ ”/“ ” to select year/month/day/hour/minute. Press “SELECT” to enter edit and press “ENTER” again to confirm and return. Press “ ” /“ ” to adjust the selected items. Press left key or “MENU” key to return and complete the setting.

  • Page 12: Measure Objects

    11. Measure Objects The product is provided with four types of object measurement modes: ① Coarse object (0.95); ② Semi-matte object (0.80); ③ Semi-shiny object (0.60); ③ Shiny object (0.30); According to the characteristics of the measured objects, users may select corresponding measurement mode and enter “advanced”...

  • Page 13: Emissivity

    12. Emissivity The emissivity of the product can be adjusted from 0.10 to 1.00 with the default value of 0.95. Many common objects and materials (such as timber, water, skin and textile fabric) can reflect the heat energy effectively. So it is easy to obtain relatively correct measurement value. The emissivity is usually set as 0.95 when the coarse objects that are easy to give out energy.
