Product Manual
Barracuda XT Series SATA
ST32000641AS
100586689
Rev. C
January 2010

Advertisement

Table of Contents
loading

Related Manuals for Seagate BARRACUDA XT SERIES SATA ST32000641AS

Summary of Contents for Seagate BARRACUDA XT SERIES SATA ST32000641AS

  • Page 1 Product Manual Barracuda XT Series SATA ST32000641AS 100586689 Rev. C January 2010...

  • Page 2: Revision History

    Publication number: 100586689, Rev. C January 2010 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Barracuda, SeaTools and SeaTDD are either trademarks or registered trademarks of Sea- gate Technology LLC or one of its affiliated companies in the United States and/or other countries.

  • Page 3: Table Of Contents

    Seagate Technology support services ........
  • Page 4 Barracuda XT Series SATA Product Manual, Rev. C...

  • Page 5: List Of Figures

    List of Figures Figure 1. Attaching SATA cabling ........... . . 17 Figure 2.
  • Page 6 Barracuda XT Series SATA Product Manual, Rev. C...

  • Page 7: Introduction

    Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate ® Barracuda XT model drives: ST32000641AS These drives provide the following key features: • The SATA 6Gb/s interface enables the use of the industry’s newest and fastest hard drive controllers while providing backward compatibility to legacy SATA 1.5Gb/s or 3Gb/s systems.

  • Page 8: About The Serial Ata Interface

    About the Serial ATA interface The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advan- tages include: • Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options.

  • Page 9: Drive Specifications

    Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For con- venience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: ST32000641AS The specification summaries listed in the following tables are for quick reference. For details on specification measure- ment or definition, see the appropriate section of this manual.
  • Page 10 To determine the warranty for a specific drive, use a web browser to access the following web page: support.seagate.com/customer/warranty_validation.jsp From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive serial number, model number (or part number) and country of purchase. The system will display the war- ranty information for your drive.

  • Page 11: Formatted Capacity

    Formatted capacity Formatted Model capacity* ST32000641AS 2000GB *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. 2.1.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above.

  • Page 12: Physical Characteristics

    Physical characteristics ST32000641AS Maximum height 26.1mm / 1.028 in Maximum width 101.85mm / 4.010 in Maximum length 146.99mm / 5.787 in Typical weight 700g / 1.543 lb Cache buffer 64MB (64,768kb) Start/stop times Power-on to ready (s) max. Standby to ready (s) max. Ready to spindle stop (s) max.

  • Page 13: Power Specifications

    Power specifications The drive receives DC power (+5V or +12V) through a native SATA power connector. See Figure 1 on page 17. 2.6.1 Power consumption Power requirements for the drives are listed in the table on page 9. Typical power measurements are based on an aver- age of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature.
  • Page 14 2.6.1.1 Typical current profiles Note. Typical 5V startup and operation current profile Note. Typical 12V startup and operation current profile Barracuda XT Series SATA Product Manual, Rev. C...

  • Page 15: Conducted Noise

    2.6.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12V line or an equivalent 15-ohm resistive load on the +5V line. • Using 12-V power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave injected noise at up to 10MHz.

  • Page 16: Environmental Specifications

    Environmental specifications 2.7.1 Ambient temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case temperature should not exceed 69°C (156°F) within the operating ambient conditions. Operating: 0° to 60°C (32° to 140°F) Nonoperating: * –40°...

  • Page 17: Shock

    2.7.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.7.5.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 63 Gs based on half-sine shock pulses of 2ms during read operations.

  • Page 18: Acoustics

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audi- bility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.

  • Page 19: Warranty

    EN55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused I/O ports.

  • Page 20: Fcc Verification

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.

  • Page 21: Environmental Protection

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damag- ing.

  • Page 22: Configuring And Mounting The Drive

    Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution: •...

  • Page 23: Configuring The Drive

    Configuring the drive Each drive on the Serial ATA interface connects point-to-point with the Serial ATA host adapter. There is no master/slave relationship because each drive is considered a master in a point-to-point relationship. If two drives are attached on one Serial ATA host adapter, the host operating system views the two devices as if they were both “masters”...

  • Page 24: Drive Mounting

    Drive mounting You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom- mounting holes. See Figure 2 for drive mounting dimensions. Follow these important mounting precautions when mount- ing the drive: •...

  • Page 25: Serial Ata (Sata) Interface

    Serial ATA (SATA) interface These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0 to 4; multiword DMA modes 0 to 2, and Ultra DMA modes 0 to 6. For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”...

  • Page 26: Serial Ata Device Plug Connector Pin Definitions

    Serial ATA device plug connector pin definitions Table 5 summarizes the signals on the Serial ATA interface and power connectors. Table 5: Serial ATA connector pin definitions Segment Function Ground Ground Signal Ground Key and spacing separate signal and power segments Ground Ground Ground...

  • Page 27: Supported Ata Commands

    Supported ATA commands The following table lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA International Organization: Serial ATA Revision 2.6 (http://www.sata-io.org). See “S.M.A.R.T. commands” on page 28 for details and subcommands used in the S.M.A.R.T. implementation. Table 6: Supported ATA commands Command name...
  • Page 28 Command name Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Set Features Set Max Address Note: Individual Set Max Address commands are identified by the value placed in the Set Max Features regis- ter as defined to the right. Set Max Address Extended Set Multiple Mode Sleep...

  • Page 29: Identify Device Command

    4.3.1 Identify Device command The Identify Device command (command code EC The data is organized as a single 512-byte block of data, whose contents are shown in Table 6 on page 21. All reserved bits or words should be set to zero. Parameters listed with an “x” are drive-specific or vary with the state of the drive. See Section 2.0 on page 3 for default parameter settings.
  • Page 30 Word Description Total number of user-addressable LBA sectors available (see Section 2.1 for related information) *Note: The maximum value allowed in this field is: 0FFFFFFFh 60–61 (268,435,455 sectors, 137Gb). Drives with capacities over 137Gb will have 0FFFFFFFh in this field and the actual number of user-address- able LBAs specified in words 100-103.
  • Page 31 NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. 112–127 ATA-reserved Security status 129–159 Seagate-reserved 160–254 ATA-reserved Integrity word Note. Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported Note.
  • Page 32 Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported. Ultra DMA mode 6 is supported. Ultra DMA mode 0 is currently active. Ultra DMA mode 1 is currently active. Ultra DMA mode 2 is currently active.

  • Page 33: Set Features Command

    4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this com- mand, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted.

  • Page 34: S.m.a.r.t. Commands

    SeaTools diagnostic software activates a built-in drive self-test (DST S.M.A.R.T. command for D4 essary drive returns. The diagnostic software ships with all new drives and is also available at: http://seatools.seagate.com. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T.

  • Page 35: Seagate Technology Support Services

    Global Customer Support Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com or through one of our call centers.
  • Page 36 Data Recovery Services Seagate offers data recovery services for all formats and all brands of storage media. Our data recovery services labs are currently located throughout the world. Additional information, including an online request form and data loss prevention resources, is available at http://services.seagate.com/index.aspx.
  • Page 37 Index acceleration 11 acoustics 12 active mode 9 agency certification 13 altitude 10 ambient temperature 7 areal density 5 ATA commands 21 Australia/New Zealand Standard AS/NZ CISPR22 14 Australian Communication Authority (ACA) 14 Australian C-Tick 14 buffer 6 cables and connectors 17 cache 6 capacity 5 case temperature 10...
  • Page 38 Korean Communications Commission (KCC) 14 Korean Radio Research Laboratory (RRL) 14 LBA mode 5 length 6 logical geometry 5 master/slave 2 mounting 18 noise 9 nonoperating shock 11 nonoperating vibration 11 operating (DC power) 7 operating power 7 operating shock 11 operating vibration 11 perpendicular recording technology 1 physical characteristics 6...
  • Page 39 shock 11 Write Uncorrectable 22 Sleep 22 sleep ( DC power) 7 sleep mode 9 sound 12 Specification summary table 3 spindle speed 5 spinup (DC power) 7 spinup power 7 Standby 22 standby (DC power) 7 Standby Immediate 22 standby mode 7 standby timer 9 standby to ready 6...
  • Page 40 Barracuda XT Series SATA Product Manual, Rev. C...
  • Page 42 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100586689, Rev. C, Printed in U.S.A.
