- Page 1 C - SERIES Height Adjustable Portable Goal Supports • C1000 • C2000 Installation & Owner’s Instructions Made in the USA...
- Page 2 C1000 & C2000 Assembly Instructions This manual explains the proper installation, operation, and maintenance of your Schutt Sports goal. Study and understand these instructions thoroughly before installing, operating, or maintaining the goal. Failure to do so could result in serious injury or death and/or equipment damage.
-
Page 3: Table Of Contents
Backboard and Rim Leveling ... 17 Upper Padding Attachment... 18 Operation and Maintenance... 18 Raise and Lower Rim ... 18 Converting to Storage Position - C1000 ... 19 Converting to Storage Position - C2000 ... 19 Cleaning ... 20 Lubrication ... 20 www.schuttsports.com... -
Page 4: Warranty
Any labor costs, travel expenses and any other changes involved in the removal, installation or replacement of the defective or repaired parts from or to your Schutt Sports Portable Goal Support will be your (the purchaser's) responsibility. -
Page 5: Safety Instructions
• Do not install or use this product unless the instructions within this manual have been carefully read and understood. • Consult your Schutt Sports dealer or Schutt Manufacturing, Co. if you do not understand the instructions in this manual or need additional information. -
Page 6: Safety Decals
C1000 & C2000 Assembly Instructions A F E T Y E C A L S www.schuttsports.com 800-426-9784... -
Page 7: Playing Court Considerations
Court Markings (reference only) 50'-0" Optimum Inside Sidelines Note: Lines are 2" wide. 4'-0" www.schuttsports.com C1000 & C2000 Assembly Instructions O U R T O N S I D E R A T I O N S 12'-0" Regulation Court Lengths:... -
Page 8: Goal Specifications
C1000 & C2000 Assembly Instructions Goal Specifications Model Backboard Size C1000 32" x 48" acrylic C2000 32" x 48" acrylic C1000 DO NOT HANG ON RIM DO NOT HANG ON RIM 28" 800-426-9784 Extension Distance (B) at: Height Range (A) 6'-6"... -
Page 9: C2000
C2000 Storage Configuration DO NOT HANG ON RIM DO NOT HANG ON RIM 32" www.schuttsports.com C1000 & C2000 Assembly Instructions 88" 17" 33" 56" 50" 800-426-9784... -
Page 10: Goal Assembly
C1000 & C2000 Assembly Instructions IMPORTANT: Safe assembly of the goal requires two or three people in good physical condition and capable of lifting 80–100 lb (36–45 kg) each. IMPORTANT: Locate and familiarize yourself with all parts of the goal before beginning assembly. -
Page 11: Unpacking - C1000
C1000 & C2000 Assembly Instructions Fully loaded pallet weighs 352 lbs (160 kg) and is difficult to handle. To prevent serious injury, a suitable lifting device must be used to remove pallet from truck. -
Page 12: Base Assembly - C1000
C1000 & C2000 Assembly Instructions Base Assembly - C1000 Step 1: Push two brackets (1) down to raise brake feet and lower wheels. Step 2: Remove four countersunk screws from lower padding. (Lower padding has six sides.) Step 3: Attach padding to underside of brackets using screws. -
Page 13: Unpacking - C2000
Remove pallet, and then lower unit down to ground. www.schuttsports.com C1000 & C2000 Assembly Instructions Fully loaded pallet weighs 440 lbs (200 kg) and is difficult to handle. To prevent serious injury, a suitable lifting device must be used to remove pallet from truck. -
Page 14: Base Assembly - C2000
C1000 & C2000 Assembly Instructions Base Assembly - C2000 Step 1: Push two brackets (1) down to raise brake feet and lower wheels. Step 2: Remove four countersunk screws from lower padding. (Lower padding has six sides.) Step 3: Attach padding (2) to underside of brackets using screws. -
Page 15: Backboard, Rim, And Extension Post Assembly
(2) from slider post. Hardware will be used in Backboard Attachment. Step 2: Remove extension post (3) from slider post. Step 3: Position backboard vertically on floor with slots toward bottom. www.schuttsports.com C1000 & C2000 Assembly Instructions 800-426-9784... - Page 16 C1000 & C2000 Assembly Instructions Backboard, Rim, and Extension Post Assembly (continued) Step 4: Position extension post (1) against backboard (2) rear and rim (3) against backboard front with slots in all parts aligned. Step 5: Assemble with four 3/8" x 1"...
-
Page 17: Backboard Attachment
Backboard and goal leveling requires the loosening and then the retightening of different backboard, brace, and goal hardware combinations. www.schuttsports.com C1000 & C2000 Assembly Instructions Step 2: First, loosen appropriate hardware, and level backboard and goal horizontally. Step 3: Second, loosen appropriate hardware, and level backboard vertically by adjusting braces. -
Page 18: Upper Padding Attachment
C1000 & C2000 Assembly Instructions Upper Padding Attachment Step 1: Remove four screws and washers from upper rectangular shaped padding. Step 2: With lower padding and red lever latched, so that brake feet are in down position and wheels are in up position, set upper padding on top of lower padding. -
Page 19: Converting To Storage Position - C1000
Converting to Storage Position - C1000 CAUTION: Portable system can tip easily if moved when goal is too high. To prevent serious injury, do not move portable system with goal above 6'-6" (2 m). Step 1: Fully lower goal. Step 2: Hold onto goal;... -
Page 20: Cleaning
C1000 & C2000 Assembly Instructions Cleaning • The exterior finish of the Schutt Sports goal is designed for many years of trouble-free operation and will not require any maintenance except for periodic cleaning. • When cleaning is necessary, use water and a mild dish detergent; apply with a soft non-abrasive cloth.
