. Plug the short cable into the 2V accessory port of the vehicle
with the good battery. Wait for the Power and Status lights to
glow steadily.
2. The long cable plug should now be lit. Plug this end into the
accessory port of the disabled battery. If the connection to the
disabled battery is good, the plug and status light will blink.
If the light does not blink, check your connections. Also, try
turning the engine ignition key to the ACC position.
3. The plug will blink continuously. Try starting the vehicle after 5
to 0 minutes or if the plug stops blinking. If the vehicle does
not start, the plug will continue to blink.
4. If the vehicle does not start after 5 to 0 minutes of charging,
wait 5 additional minutes before trying again. When the 5
minute waiting period is up, try starting again.
OPERATING INSTRUCTIONS
Model: VTV-20
00-99-000720/06
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Schumacher E-CHARGE VTV-20
Summary of Contents for Schumacher E-CHARGE VTV-20
- Page 1 OPERATING INSTRUCTIONS . Plug the short cable into the 2V accessory port of the vehicle with the good battery. Wait for the Power and Status lights to glow steadily. 2. The long cable plug should now be lit. Plug this end into the accessory port of the disabled battery. If the connection to the disabled battery is good, the plug and status light will blink. If the light does not blink, check your connections. Also, try turning the engine ignition key to the ACC position. 3. The plug will blink continuously. Try starting the vehicle after 5 to 0 minutes or if the plug stops blinking. If the vehicle does not start, the plug will continue to blink. 4. If the vehicle does not start after 5 to 0 minutes of charging, wait 5 additional minutes before trying again. When the 5 minute waiting period is up, try starting again. Model: VTV-20 00-99-000720/06...
- Page 2 5. If the vehicle still does not start, repeat step 4. The VTV-20 will continue charging the battery for up to an hour. 6. If your vehicle does not start after an hour of charging, there may be other problems with the engine and/or starting sys- tem. It is also possible that the battery is incapable of taking a charge and needs to be replaced. NOTE: It is normal for the status light to blink rapidly and/or to hear a clicking noise while charging. 7. If your vehicle does start, and if your battery was in severely discharged state, you will want to completely charge your bat- tery with a standard battery charger as soon as possible. 8. If the Working Vehicle’s Power LED light continually flashes on and off, then the Working Vehicle’s battery may be too low to use. Try connecting to a different vehicle before assuming that the VTV-20 is dysfunctional.
-
Page 3: Troubleshooting
PROBLEM VTV-20 lights are not lit when plugged in Power light is blinking and status light is off TROUBLESHOOTING CAUSE Wrong end is plugged in Bad connection in the accessory port Accessory port does not have power Fuse in cables or car is blown VTV-20 is overheated VTV-20 detected a current overload SOLUTION Plug the short end into the good- battery vehicle’s accessory outlet Disconnect and reconnect the plug Turn ignition key to ACC position Replace fuse(s) Make sure the VTV-20 has sufficient clearance and that the vents are not blocked Unplug the VTV-20, wait 5 seconds, then plug the VTV-20 back in... - Page 4 PROBLEM Power light is blinking and status light is on WARNING: Handling the cord on this product or cords associ- ated with accessories sold with this product, may expose you to lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. CAUSE The good battery does not have sufficient power (less than volts) The short cable has been plugged into the wrong vehicle SOLUTION Start the good- battery vehicle to provide extra power to the VTV-20 Make sure the short cable is plugged into the good-battery’s vehicle...
-
Page 7: Limited Warranty
LIMITEd WARRANTy SCHUMACHER ELECTRIC CORPORATION 80 BUSINESS CENTER DRIVE MOUNT PROSPECT, ILLINOIS 60056-279 MAKES THIS LIMITED WARRANTY TO THE ORIGINAL PURCHASER AT RETAIL OF THIS PRODUCT. THIS LIMITED WARRANTY IS NOT TRANSFERABLE. Schumacher Electric Corporation warrants this battery charger for 2 years from date of purchase at retail against defective material or workmanship. If such should occur, the unit will be repaired or replaced at the option of the manufacturer. It is the obligation of the purchaser to forward the unit together with the original sales receipt, transportation and/or mailing charges prepaid to the manufacturer or its authorized representative. For warranty service, return your VTV-20 to: Schumacher Electric Corp., Warranty Service Department 025 E. Thompson, Hoopeston, IL 60942-0280. Questions? Call: Customer Service: 800-62-5485 7 a.m. - 4:30 p.m. CST, Monday through Friday. This limited warranty is void if the product is misused, subjected to careless handling, or repaired by anyone other than the manufacturer or its authorized representative. - Page 8 NOTES...
