- Page 1 Amplify your world C15F-5B User’s Manual Foshan Amplitec Tech Development Co.,Ltd.
-
Page 2: Table Of Contents
Amplify your world CONTENTS OVERVIEW .......................... 3 FUNCTION AND FEATURES ...................... 3 PARTS LIST .......................... 4 .......................... 4 ONFIGURATION ANTENNA SOLUTION ......................... 5 ........................ 5 PTIONAL ANTENNA KITS PPEARANCE & INTERFACE DIAGRAM .................. 7 INSTALLATION GUIDE ...................... ... -
Page 3: Overview
Amplify your world Overview C15F-5B wide band mini Booster is designed with harmonious humanity conception, as a perfect combination of environmental protection and signal coverage. The C15F-5B products carried with many features like, low consumption, light weight, high gain, low output power and easy installation, etc, It provides a rapid and perfect solution to solve and optimize the weak signal of houses, offices, hotels, elevators, underground parking lots and other small weak signal area. -
Page 4: Parts List
AC/DC Pow er Adapter Indoor Ant tenna Donor Antenn na N‐male To N‐m male RF Cable We will prov vide many ki nds of access sories for the signal booste er according t to the persona interest, if y you want more e information n, Visit www. .amplitec.net. -
Page 5: Antenna Solution
Amplify your world Antenna Solution Optional antenna kits Outdoor Antenna Option 1: 5/7dBi Outdoor Panel Antenna with 10 meters 5D-FB Coax Cable (N-Male Connectors) Model IP0725-770 Frequency Range 698-894/1710-2500MHz Bandwidth 196/790 MHz Gain 5/7dBi VSWR ≤1.5 Polarization Vertical Max power 100 W Nominal Impedance 50 Ω... - Page 6 mplify your w world Opti ion 2: 3dBi O Omni Ceiling Antenna Model OO0725-03 3360 Frequency y Range 698-894/17 710-2500MH Bandwidth 196/790 M Gain 3dBi VSWR ≤1.5 Polarizatio Vertical Max powe 100 W Nominal I mpedance 50 Ω Opti ion 3: 2.5dBi Pucker Rubb ber Antenna Model...
-
Page 7: Ppearance & Interface Diagram
mplify your w w orld pearance e & Interf face Diagr DC+5V：Po ower supply v voltage is +5V BS：Output port, to be co onnected with h service ante enna Grounding, e equipment ca n be grounde ed by screwin MS：Input p port, to be con nnected with donor antenn... -
Page 8: Installation Guide
AC power supply. Install the indoor antenna where you want to improve signals. 1. Donor Antenna 2. C15F-5B Cellular signal booster 3.Indoor antenna Installing the Booster 1. Select a location close to a power outlet, normally a wall. -
Page 9: Installing Donor Antenna
Amplify your world Installing Donor antenna 1. Use your mobile phone find an area with the strongest signal. 2. Select a proper place to install the donor antenna. 3. Based on the installation environment, take the right way to install donor antenna on the best signal place, as below: Installing Indoor antenna 1. -
Page 10: Trouble Shooting
Amplify your world 3. Please use the corresponding power supply adaptor for the Booster. 4. Please avoid choose strong electricity, high-intensity magnetic field, corrosive, moist and other likely environment when select the installation location, and make sure the ventilation is good and cool. -
Page 11: Specification
Amplify your world Specification Items Uplink Downlink LTE17 704 ~ 716 MHz 734 ~ 746 MHz LTE13 776 ~ 787 MHz 746 ~ 757 MHz Frequency Range Cellular 824 ~ 849 MHz 869 ~ 894 MHz 1710 ~ 1755 MHz 2110 ~ 2155 MHz 1850 ~ 1910 MHz 1930 ~ 1990 MHz... -
Page 12: Fcc Warning
Amplify your world FCC Warning This is a CONSUMER device. BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. -
Page 13: Contact Information For Providers
Amplify your world Contact Information for providers A subscriber must have the consent of a wireless provider to operate a Consumer Signal Booster. Please register your booster with your wireless service provider, refer to contact information for providers Sprint: signalbooster@sprint.com T-Mobile: www.T-Mobile.com/BoosterRegistration https://support.t-mobile.com/docs/DOC-9827...
