Schumacher SE-3002 Owner's Manual

6 and 2 amp battery charger for 6 and 12 volt batteries
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Owner's Manual
Read Rules for Safe Operation and Instructions Carefully
Working in vicinity of a lead-acid battery is dangerous. Batteries generate explosive gases during normal
battery operation. For this reason, it is of utmost importance that each time before using your charger, you
read this manual and follow the instructions exactly.
WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will expose you to lead, a chemical
known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
1.
Before you use your battery charger, be sure to read all
instructions and cautions printed on:
• Battery Charger
• Battery
• Vehicle or unit using battery
2.
Use battery charger on LEAD ACID type rechargeable batter-
ies only, such as used in autos, trucks, tractors, airplanes,
vans, RV's trolling motors, etc. Charger is not intended to sup-
ply power to low-voltage electrical system other than in an
automotive application.
WARNING: Do not use battery charger for charging dry-cell
batteries that are commonly used with home appliances.
These batteries may burst and cause injury to persons and
damage to property.
3.
Use only attachments recommended or sold by manufacturer.
Use of non-recommended attachments may result in fire, elec-
tric shock, or injury.
4.
When disconnecting the battery charger, pull by the plug not
by the cord. Pulling on the cord may cause damage to cord or
plug.
5.
Locate battery power cord so it cannot be stepped on, tripped
over, or subjected to damage or stress.
6.
Do not operate charger with damaged cord or plug. Have cord
replaced immediately.
7.
Do not operate charger if it has received a sharp blow, been
dropped, or otherwise damaged in any way. Take it to a quali-
fied professional for inspection and repair.
8.
Do not disassemble charger. Take it to a qualified professional
when service or repair is required. Incorrect reassembly may
result in electric shock or fire.
9.
To reduce risk of electric shock, unplug charger from outlet
before attempting any maintenance or cleaning.

Important Safety Instructions

GENERAL BATTERY SAFETY
SCHUMACHER ELECTRIC CORPORATION
801 BUSINESS CENTER DRIVE • MOUNT PROSPECT, ILLINOIS 60056-2179
Send Warranty Product Repairs to: 1025 E. Thompson, Hoopeston, IL 60942-0280
Call Customer Service if you have questions: 1-800-621-5485
Battery
Charger
Models:
–Save–
10. Do not use an extension cord unless absolutely neces-
sary. Use of an improper extension cord could result in fire
or electric shock. If an extension cord must be used, make
sure that:
• Pins on plug of extension cord are the same number, size,
and shape as those of plug on charger.
• Extension cord is properly wired and in good electrical con-
dition.
• Wire size is large enough for AC ampere rating of charger,
as specified below:
_____________________________________________
Length of cord (feet): 25
AWG size of cord:
_____________________________________________
11. Always charge battery in a well ventilated area.
NEVER operate in a closed-in or restricted area without ad-
equate ventilation.
WARNING: Risk of explosive gas.
12. Locate charger as far away from battery as DC charger cables
permit.
13. Do not expose charger to rain or snow.
14. NEVER charge a frozen battery. If battery fluid (electrolyte) is
frozen, bring into a warm area to thaw before charging.
15. NEVER allow battery acid to drip on charger when reading
specific gravity or filling battery.
16. NEVER set a battery on top of charger.
17. NEVER place charger directly above battery being charged.
Gases from battery will corrode and damage charger.
18. NEVER touch the battery clips together when the charger is
energized.
19. NEVER crank engine with charger attached to battery.
1
SE-82-6 & SE-3002
6 and 2 Amp
Battery Charger
For 6 and 12 Volt Batteries
50 100 150
18
18 18
16
00-00-000531/0103

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE-3002 and is the answer not in the manual?

Questions and answers

Related Manuals for Schumacher SE-3002

Summary of Contents for Schumacher SE-3002

  • Page 1: Important Safety Instructions

    WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will expose you to lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. Before you use your battery charger, be sure to read all instructions and cautions printed on: •...

  • Page 2: Preparing To Charge

    This battery charger is designed for use on a nominal 120- volt circuit and has a grounded plug that looks like the plug illustrated FIGURE 1 (A).

  • Page 3: Battery Charger Controls

    The SE-82-6 and SE-3002 battery charger has a selector switch and an ammeter for reading AMP's. FIGURE 3 shows the charger controls. INPUT: 120V AC 60HZ 1.3 AMP OUTPUT: 6/2 AMP AT 12V DC, 6 AMP AT 6V DC READ INSTRUCTION MANUAL AND WARNING ON BACK NOTE: Model SE-3002 meter is similar but, presented in a horizontal format.

  • Page 4: Circuit Breaker

    2 AMP SETTING: When fully charged on the 2 AMP setting needle will indicate 1 amp or less, as shown in FIGURE 4. FIGURE 4 FULLY CHARGED NOTE: Model SE-3002 meter is similar but, presented in a horizontal format. This battery charger is equipped with a self-resetting circuit breaker.
  • Page 5 POSITIVE GROUNDED POST For positive-grounded vehicle, connect NEGATIVE (BLACK) clip from battery charger to NEGATIVE (NEG, N, -) un- grounded post of battery. Connect POSITIVE (RED) clip to ve- hicle chassis or engine block away from battery. Connect to a heavy gauge unpainted metal part of the frame or engine block.

  • Page 6: Maintenance/Cleaning Instructions

    MAINTENANCE/CLEANING INSTRUCTIONS Very little maintenance is required for the battery charger. Follow common sense in wiping the charger clean and store in a clean, dry area. After use, wipe all battery corrosion and other dirt or oil from clip, cord, and the charger case. Use a dry cloth.
  • Page 7 1. GUARDAR ESTAS INSTRUCCIONES de este manual, el cual contiene todas las instrucciones necesarias para trabajar estos cargadores de baterías. Para lo Modelos: SE-82-6 y SE-3002. UN CARGADOR DE BATERIAS RECIBE POTENCIA (CORRIENTE ALTERNA (AC) EL TOMA-CORRIENTE ELÉCTRICO Y LA ENTREGA DE ESA CORRIENTE SERA EN FORMA DE CORRIENTE DIRECTA (DC) QUE ES LA QUE VA HACIA LA BATERIA DEL CARRO.
  • Page 8 El interruptor par seleccionar la corriente para el modelos SE-82-6 y SE-3002 está marcado con 2 amperes - 6 amperes. La proporción de carga en emperes para la batería será...
