Schumacher 9500A Owner's Manual

MODEL 9500A
Fully Automatic 6 & 12 volt
2 amp / 15 amp / 40 amp
Battery Charger with
125 amp / 250 amp Engine Start
WORKING IN VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES
GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY OPERATION. FOR THIS
REASON, IT IS OF UTMOST IMPORTANCE THAT EACH TIME BEFORE USING YOUR
CHARGER, YOU READ THIS MANUAL AND FOLLOW THE INSTRUCTIONS EXACTLY.
A
1. Before you use your battery charger, be sure to read all
instructions and cautions printed on:
• Battery Charger
• Battery
• Vehicle or unit using battery
2. Use battery charger on LEAD ACID type rechargeable bat-
teries only, such as used in trucks, autos, tractors, airplanes,
trolling motors, vans, RV's, etc. Charger is not intended to
supply power to a low-voltage electrical system other than
in an automotive application.
WARNING: Do not use battery charger for charging dry-
cell batteries that are commonly used with home appliances.
These batteries may burst and cause injury to persons and
damage to property.
3. Use only attachments recommended or sold by manufac-
turer. Use of non-recommended attachments may result in
fire, electric shock, or injury.
4. When disconnecting the battery charger, pull by the plug
not by the cord. Pulling on the cord may cause damage to
cord or plug.
5. Locate battery power cord so it cannot be stepped on,
tripped over, or subjected to damage or stress.
6. Do not operate charger with damaged cord or plug. Have
cord replaced immediately.
7. Do not operate charger if it has received a sharp blow, been
dropped, or otherwise damaged in any way. Take it to a
qualified professional for inspection and repair.
8. Do not disassemble charger. Take it to a qualified profes-
sional when service or repair is required. Incorrect reas-
sembly may result in electric shock or fire.
9. To reduce risk of electric shock, unplug charger from outlet
before attempting any maintenance or cleaning.
• IMPORTANT SAFETY INSTRUCTIONS •
Send Warranty Product Repairs to: P.O. Box 280 • 1025 East Thompson Avenue, Hoopeston, IL 60942
OWNER'S MANUAL
GENERAL BATTERY SAFETY
• SAVE THESE INSTRUCTIONS •
801 BUSINESS CENTER DRIVE • MOUNT PROSPECT, ILLINOIS 60056-2179
Call Customer Service if you have questions: 1-800-621-5485
10. Do not use an extension cord unless absolutely necessary.
Use of an improper extension cord could result in fire or
electric shock. If an extension cord must be used, make
sure that:
• Pins on plug of extension cord are the same number, size,
and shape as those of the plug on the charger.
• Extension cord is properly wired and in good electrical
condition.
• Wire size is large enough for AC ampere rating of charger,
as specified below:
_____________________________________________
Length of cord (feet): 25
AWG size of cord:
(American Wire Gauge)
_____________________________________________
11. Always charge battery in a well ventilated area. NEVER
operate in a closed-in or restricted area without adequate
ventilation because of risk of explosive gases.
12. Locate charger as far away from battery as DC charger
cables permit.
13. Do not expose charger to rain or snow.
14. NEVER charge a frozen battery. If battery fluid (electrolyte)
is frozen, bring into a warm area to thaw before charging.
15. NEVER allow battery acid to drip on charger when reading
specific gravity or filling battery.
16. NEVER set a battery on top of charger.
17. NEVER place charger directly above battery being charged.
Gases from battery will corrode and damage charger.
18. NEVER touch the battery clips together when the charger
is energized.
ELECTRIC CORPORATION
1
Read Rules for
Safe Operations
and Instruction
Carefully
50 100 150
16 12 10 8
