Contec SRC-350 Programming And Operating Instructions

Model SRC-350
Universal Remote Control
Programming and Operating
Instructions
(Part # 9-542-901)
To have a clearer idea of the features and capabilities of
your remote control, take a moment to read these
instructions. Save for future reference.
© 2006 Contec Holdings, LLC, Rev. 08/06

1. Introduction

Your SRC-350 remote control is simple to program,
easy to use, and can operate two (2) devices, which
include:
•
Residential Gateways (RG)
•
Televisions
The SRC-350 remote control allows access to the
features available in your Residential Gateway by
using an IR (infrared) and UHF (ultra high frequency)
signal, depending on how it is programmed. When
the SRC-350 is set to operate in IR mode, you must
point it directly at your Residential Gateway in order to
operate it. When the SRC-350 is set to operate in
UHF mode, it can operate your Residential Gateway
from anywhere in your home.
Before you can use your SRC-350, it must be
programmed (set-up) to operate your Residential
Gateway and TV. Programming your remote control
is simple following the steps outlined in this manual.

2. Before Getting Started

Some of the special features and buttons on your
SRC-350 remote control are as follows:
Point and Press® Programming
Lets you program your TV without codes. For more
information, see Sections 7 and 9.
Memory Guard®
Eliminates reprogramming after battery changes.
Time Out
If the same button is pressed and held for 30-
seconds, your remote control will turn itself off
automatically. This extends the battery life should
the remote become lodged under or between heavy
objects, for example sofa cushions.

3. Installing / Replacing Batteries

Install two (2) new "AA" batteries as indicated by the
diagram in the battery compartment.
When the batteries become low and need to be
replaced, the [LED] button will not illuminate normally
or at all during use.
When this happens, replace the existing batteries with
two (2) new "AA" batteries to restore normal operation
to the remote control.

4. Setting the Remote Control Operating Mode

The SRC-350 remote control operates older as well
as newer Residential Gateway models. To allow for
this, the remote can be set to operate in either SRC-
200 Compatibility Mode (to operate like the older
remote control) or SRC-350 Native Mode.
default Operating Mode is SRC-200 Compatibility
Mode.
Programming the Remote Control Operating Mode
using your SRC-350 keypad:
1. In this order, press and hold the [SELECT] button,
then the [MUTE] button. Hold both buttons down
together until the [LED] button illuminates.
Release both buttons as soon as the [LED] button
illuminates.
2. Press and release the [D] key. The [LED] button
temporarily turns off. Releasing the key causes
the [LED] button to light up again. You can now
set the correct Operating Mode.
3. Press [0] to select SRC-200 Compatibility Mode or
[1] to select SRC-350 Native Mode. The [LED]
button will blink three-times and go out. The new
Operating Mode is stored in the device.
Important! Changing the Operating Mode from [0] to
[1] will reset the Gateway ID within the SRC-350 back
to [000].
Once changes have been made, the remote control
resumes normal operation. If the value entered was
not valid (a keypress other than [0] or [1]) the [LED]
button indicates the error by turning off immediately,
The
