USER MANUAL
MINI WILDLIFE CAMERA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Outback MINI and is the answer not in the manual?

Questions and answers

Related Manuals for ElectrIQ Pro Outback MINI

Summary of Contents for ElectrIQ Pro Outback MINI

  • Page 1 USER MANUAL MINI WILDLIFE CAMERA...
  • Page 2 INTRODUCTION Thank you for purchasing our mini wildlife camera. This device is a special camera designed specifically for recording and observing wildlife. These easy to follow instructions will provide you with information on the operation and functions of the camera, enabling you to get the most from your new purchase.
  • Page 3 SAFETY Please read the following safety precautions carefully before using the device.  Do not try to open the camera case by yourself. Repairs can only be carried out by the manufacturer or their authorized agents.  During operation the temperature of device may rise, this is normal.

  • Page 4: Parts Of The Camera

    PARTS OF THE CAMERA 1. Display 2. Motion Sensors 3. Lens 4. Up/Video Button 5. Down/Capture Button 6. Front motion sensor 7. OK/Shot button 8. Menu Button 9. Right button 10. Playback button 11. DC adapter port 12. Tripod Slot 13.
  • Page 5 14. Battery compartment 15. ON-TEST-OFF button 16. USB jack 17. Micro SD card slot...

  • Page 6: Power Supply

    POWER SUPPLY Before use, ensure that the batteries are inserted  Unlock the two clasps on the side and open the camera. Install 4 x 1.5V AA batteries. Please ensure they are installed the correct way round.  If the camera is in low power, please connect the camera to a power adapter (not provided) for power supply.

  • Page 7: Inserting The Memory Card

    INSERTING THE MEMORY CARD Since the camera has no built-in memory, A MicroSD card should be inserted into the camera to enable videos and pictures to be saved. The card must be formatted before use.  Supports MicroSD cards, up to 32GB. ...

  • Page 8: Basic Operation

    BASIC OPERATION TURN THE CAMERA ON AND OFF To turn the camera on, slide the Mode Switch to “Test or On”. To turn the camera off, slide the Mode Switch to “Off”. System Setup Slide the Mode Button to “Test”, to gain access to the system setup.

  • Page 9: Photo Resolution

    Setup menu and functions as below: MODE Set the working mode. In Photo mode: The camera will just take pictures. In Video mode: The camera will just record video. In Photo & Video mode: The camera will take a photo first, and then start to record video.

  • Page 10: Video Resolution

    VIDEO RESOLUTION Set the resolution of videos recorded. Increasing the resolution will decrease the length of video that can be stored. Options： 【1920x1080P】 / 【1280x720P】 / 【720x480P】 / 【640x480P】 /【320x240P】. TL VIDEO RESOLUTION Set the resolution of time lapse video . Options:【2592x1944P】/【2048x1536P】.
  • Page 11 SHOT LAG Set the delay that is applied after a video or photo is saved, before the unit can be retriggered. This can be used to prevent the storage been taken up with the same event. Options：5 seconds~60 minutes. IR DISTANCE Set the distance covered by the Infrared when running in darkness.

  • Page 12: Time Lapse

    TARGET RECORDING TIME Settings Set the target recording time. You are Set target recording time able to set the start and stop time. The Start： Stop： Hr：Min Hr：Min camera will only work within the stated 00 00 time slot. Options：【On】/【Off】. MENU Back OK Select TIME LAPSE...
  • Page 13 LANGUAGE Set the language display on screen. Options： 【English】 / 【 German】 / 【 Danish】 / 【 Finnish】 / 【 Swedish】 【Spanish】/【French】/【Italian】/【Dutch】/【Portuguese】/ 【Simplified Chinese】/【Japanese】. ENDLESS CAPTURE Set the camera to record video in loop, so that when the memory card is full it will record over the oldest recordings. Options：【On】/【Off】.

  • Page 14: Password Protection

    PHOTO STAMP Choose whether to stamp the date and time on photos. Options：【Time & date】/【Date】/【Off】. PASSWORD PROTECTION Set the power-on password of the camera. The password is four digits，each digit ranges from 0 to 9. Options：【On】/【Off】. BEEP SOUND Turn on/off sounds when buttons are pressed on the keypad. Options：【On】/【Off】.

  • Page 15: Reset Settings

    SERIAL NO. Set a unique number for the camera. The number is four digits， each digit ranges from 0 to 9 and A to Z. Options：【On】/【Off】. RESET SETTINGS Restore the camera to factory default settings removing the password, and any changes made to the settings. Options：【On】/【Off】.
  • Page 16 TAKE PHOTOS、RECORD VIDEO、PLAYBACK Slide the mode switch to “Test”. In this mode, you can take photos, record video and playback files manually. Take Photos: Press the Capture button to switch to photo mode. Press the OK button to take a picture. Record Video: Press the Video button to switch to video mode.

  • Page 17: Playback Menu

    PLAYBACK MENU Delete current file: Delete the selected photo or video. Options：【Cancel】/【Delete】. Delete all files: Delete all photo and video files on the memory card. Options：【Cancel】/【Delete】. Activate slide show: Playback the photos as a slide show. Each photo will display 3 seconds. Press OK to stop playback. Write protect: Lock the file to help prevent accidental deletion.

  • Page 18: Working Mode

    WORKING MODE Slide the mode switch to “On”. The screen will display a 15 second countdown. The LEDs and screen will then go out and the camera will start to operate in accordance with the rules set up within the menus. If animals enter the detection range of the camera, it will be activated.

  • Page 19: Using The Wall Bracket

    USING THE WALL BRACKET You can mount the camera on a wall or tree by the supplied wall bracket. Before mounting the wall bracket you should ensure that all existing screws are tight. The best installation height distance from the ground about 1 meter. COMPONENTS 1.
  • Page 20 MOUNTING THE WALL BRACKET REQUIRED TOOLS  Drill  6 mm masonry/concrete drill bit  Phillips head screwdriver CAUTION  Ensure that there are no electric lines, water or heating pipes installed at the proposed drilling location.  The supplied wall plugs are only suitable for mounting on concrete or stone.

  • Page 21: Installation

    INSTALLATION  Mark the drill holes by holding the base of the bracket at the desired mounting position and mark the position of the holes.  Use a drill with a 6 mm bit to drill the holes and insert the plugs so that they sit flush with the wall.

  • Page 22: Using A Card Reader

    USING A CARD READER 1. Remove the memory card from the camera and insert it into a card reader. Then connect the card reader to a computer. 2. Open [My Computer] or [Windows Explorer] and double-click the removable disk icon that represents the memory card.
  • Page 23 NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available. electriQ UK Support www.electriQ.co.uk/support 0871 620 1057 Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
