  • Page 1 AL-S ERIES Standard Duty Commercial...

  • Page 2: Performance Features

    Reversible latch unit Throw (13 mm) springlatch and deadlatch Deadlocking plunger Heavy duty cast mounting plates On our cover, the AL-Series Saturn in satin chrome (626). Cylinders Designs Door Preparation Functions How to Order Interchangeable Core Latches Primus ®...

  • Page 3: Specifications

    (95 mm) (Formerly Title 19, California State Fire Marshal Standard) All levers with returns comply; levers return to within ˝ of door face. UL / ULC: All locks listed for A label single doors, 4´ x 8´. Letter F and UL symbol on latch front indicate listing.
  • Page 4 606 Satin Brass 609 Bright Brass, Blackened 612 Satin Bronze 613 Oil Rubbed Bronze 625 Bright Chromium Plated 626 Satin Chromium Plated This icon designates designs available with inter- Schlage Schlage changeable core options. 4-1/4" 108 mm 3-7/16" 87 mm 2-1/2"...
  • Page 5 Push-button locking. Unlocked from outside by turning emergency turn button. Turning inside lever or closing door releases button. AL170 Single Dummy Trim Single dummy trim for one side of door. Used for door pull or as matching inactive trim. Keyed Functions SCHLAGE AL50PD Schlage...

  • Page 6: Standard Cylinders

    Full Size Interchangeable Core Full size interchangeable cores can be integrated into any 5 or 6-pin Schlage key with no adverse affects on keying capacity. To order complete locks with full size cores, change suffix from PD to RD. Example: AL53RD. To order locks less core, change suffix to JD.
  • Page 7 80-033 and 80-043 cores are available in A, D, E, F, G, H, J, K, L, and M keyways. 80-036 and 80-037 restricted keyway cores require a letter of authorization from the end user. Schlage assigns the keyway when establishing new Everest restricted key systems.
  • Page 8 S E R I E S Latches AL-Series latches are adjustable for flat or beveled edge doors. Latches and strikes are furnished in brass, bronze, or chrome finishes compatible with lock trim. When ordering separately, specify quantity, part number, and finish.
  • Page 9 Strikes All Schlage strikes are furnished complete with screws. The 10-025 standard AL-Series strike has a 1 (30 mm) separately, specify quantity, product number, finish, and lip length. Strikes Number Lip Length 1 , 1 (std), 1 10-001 (25 mm, 29 mm, 32 mm, 38 mm, 44 mm, 51 mm)

  • Page 10: How To Order

    Keying detail (e.g. key symbol, keyway, bitting) and other special requirements. EXAMPLE Line Outside Inside Product Item AL10S AL50RD AL85PD Note: Schlage order forms are available at no charge by contacting your Schlage Representative or Customer Service. Latch Strike Latch Strike 10-001 11-085 Additional Details Additional Details C145 245793...
  • Page 11 S E R I E S...
