MODEL GC-STC
THIS MANUAL CONTAINS THE OPERATING
INSTRUCTIONS AND SAFETY INFORMA-
TION FOR YOUR SCAG ACCESSORY. READ-
ING THIS MANUAL WILL PROVIDE YOU
WITH MAINTENANCE AND ADJUSTMENT
PROCEDURES TO KEEP YOUR ACCESSORY
PERFORMING TO MAXIMUM EFFICIENCY.
THE SPECIFIC MODELS THAT THIS BOOK
COVERS ARE CONTAINED ON THE INSIDE
COVER. BEFORE OPERATING YOUR MA-
CHINE, PLEASE READ ALL THE INFORMA-
TION ENCLOSED.
PART NUMBER 03154

Advertisement

loading
Need help?

Need help?

Do you have a question about the GC-STC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scag Power Equipment GC-STC

Summary of Contents for Scag Power Equipment GC-STC

  • Page 1 MODEL GC-STC THIS MANUAL CONTAINS THE OPERATING INSTRUCTIONS AND SAFETY INFORMA- TION FOR YOUR SCAG ACCESSORY. READ- ING THIS MANUAL WILL PROVIDE YOU WITH MAINTENANCE AND ADJUSTMENT PROCEDURES TO KEEP YOUR ACCESSORY PERFORMING TO MAXIMUM EFFICIENCY. THE SPECIFIC MODELS THAT THIS BOOK COVERS ARE CONTAINED ON THE INSIDE COVER.
  • Page 2 This manual covers the operating instructions GC-STC with a serial number of A7700001 to A7799999 WARNING and illustrated parts list for:...

  • Page 3: Direction Reference

    A replacement manual is available from your authorized Scag Service Dealer or by contacting: Scag Power Equipment, Service Department at P.O. Box 152, Mayville, WI 53050. You may also contact us through our website at www.scag.com The...
  • Page 4 Figure 3-3, Page 3. 9. Install the belt to the spindle pulley. When replacing the belt, see figure below. BACK SIDE IDLER PULLEY REMOVE EXISTING RT. SIDE BELT COVER FRONT SIDE IDLER PULLEY Figure 1- GC-STC install art -NOTE- BLOWER PULLEY SPINDLE PULLEY...
  • Page 5 FLATWASHER ELASTIC STOP TIGHTEN CATCH PLATE HARDWARE MOUNTING PIN TIGHTEN MOUNTING BRACKET HARDWARE 2005 GC-STC install art 3 CARRIAGE BOLT FIGURE 3-2 BLOWER ASSEMBLY HAIR MOUNTING BRACKET P R O P E R L Y S E R V I C E...
  • Page 6 10. Install the new belt covers and secure. See items number 1 and number 21 on page 8 of the Blower Mounting Components section in the Illustrated Parts List for proper installation. 11. Install the hopper mounting brackets to the outside of the frame on the rear of the machine.
  • Page 7 BLOWER ASSEMBLY HAIR MOUNTING BRACKET 2005 GC-STC removal art 1 (Note: Some parts not shown for viewing purposes.) FIGURE 4-1 5. Loosen the locking bolts and remove the two (2) pins holding the hood assembly to the mounting posts on the rear of the machine. See Figure 4-2.
  • Page 8 GC-STC 48" & 52" BLOWER HOUSING ASSEMBLY 2005 GC Blower Assembly...
  • Page 9 GC-STC 48" & 52" BLOWER HOUSING ASSEMBLY Ref. Part Number Description 04067-07 Pin, Ring 2-1/4" Long 481547 Lanyard, Deck Height Pin 04019-02 Nut, Serr. Flange 1/4-20 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4" 04001-01 Bolt, Hex Head 1/4-20 x 3/4"...
  • Page 10 GC-STC 48" & 52" BLOWER MOUNTING COMPONENTS FOR MACHINES WITH A SERIAL NUMBER BETWEEN 7630001 - 8479999 ONLY UNDER SIDE OF CUTTER DECK SHOWN RIGHT SIDE OF CUTTER DECK SHOWN 390STC203B...
  • Page 11 GC-STC 48" & 52" BLOWER MOUNTING COMPONENTS Ref. Part Number Description 482612 Belt Cover, GC-STC 04029-04 Wingnut, Plastic 3/8" Small 482300 Cap, Square Vinyl 04021-08 Nut, Elastic Stop 1/4-20 461723 Adapter, Blower GC-STC, includes item #7 04040-14 Flatwasher, 1/4-.312 x .750 x .065 48137-04 Rubber Strap 7-3/4"...
  • Page 12 GC-STC BUCKET SUPPORT COMPONENTS (UPPER)
  • Page 13 GC-STC BUCKET SUPPORT COMPONENTS (UPPER) Ref. Part Number Description 423302 Screen, Catcher Hood 04090-02 Pop Rivet, 3/16 x .652 04041-19 Flatwasher, 3/16-.196 x .469 x .048 04001-32 Bolt, Hex Head 3/8-16 x 1-1/4" 04041-01 Flatwasher, 3/8-.391 x .938 x .105 461408 Hood Assembly, GC-STT (includes items 1, 2 &...
  • Page 14 GC-STC BUCKET SUPPORT COMPONENTS (LOWER) "A" TO "A" STC 2002 BSC...
  • Page 15 GC-STC BUCKET SUPPORT COMPONENTS (LOWER) Ref. Part Number Description 04090-02 Pop Rivet, 3/16 x .652 482321 Seal, Hood 423262 Tube, Upright 04041-07 Flatwasher, 3/8-.391 x .938 x .105 04021-09 Nut, Elastic Stop 3/8-16 04020-04 Nut, 3/8-16 04021-05 Hex Lock Nut, 3/8-16 04067-07 Pin, Ring 1/2 x 2-1/4"...
  • Page 16 GC-STC DECALS 481039 482275 481327 481377 483037 483039...
  • Page 17 This warranty does not cover engines and electric starters, which are warranted separately by their manufacturer. Scag Power Equipment reserves the right to change or improve the design of any accessory without assuming any obligation to modify any accessory previously manufactured.
