2009 Saturn VUE Green Line Hybrid Owner Manual Seats and Restraint ... 1-1 System Head Restraints ... 1-2 Front Seats ... 1-3 Rear Seats ... 1-9 Safety Belts ... 1-10 Child Restraints ... 1-22 Airbag System ... 1-41 Restraint System Check ...
Page 2: Canadian Owners
General Motors Corporation. This manual includes the latest information at the time it was printed. Saturn reserves the right to make changes after that time without further notice. This manual describes features that may or may not be on your speciﬁc vehicle.
Page 3: Index
Index To quickly locate information about the vehicle use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found. Safety Warnings and Symbols A circle with a slash through it is a safety symbol which means “Do...
Page 4 Preface Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the index. : Airbag Readiness Light : Air Conditioning : Antilock Brake System (ABS) : Audio Steering Wheel ®...
Page 5: Seats And Restraint System
Seats and Restraint System Head Restraints Head Restraints ...1-2 Front Seats Manual Seats ...1-3 Seat Height Adjuster ...1-4 Power Seat ...1-4 Manual Lumbar ...1-5 Heated Seats ...1-5 Reclining Seatbacks ...1-5 Passenger Folding Seatback ...1-7 Rear Seats Split Folding Rear Seat ...1-9 Safety Belts Safety Belts: They Are...
Page 6: Head Restraints
Seats and Restraint System Head Restraints The front and rear seats have adjustable head restraints in the outboard seating positions. CAUTION With head restraints that are not installed and adjusted properly, there is a greater chance that occupants will suffer a neck/spinal injury in a crash.
Page 7: Front Seats
Active Head Restraint System The vehicle has an active head restraint system in the front outboard seating positions. The active head restraints automatically tilt forward to reduce the risk of neck injury if the vehicle is hit from behind. Seats and Restraint System Front Seats Manual Seats CAUTION...
Page 8: Seat Height Adjuster
Seats and Restraint System Seat Height Adjuster If the vehicle has a manual driver seat height adjuster, it is located on the outboard side of the seat near the front of the seat cushion. To raise the seat, move the lever upward repeatedly until the seat is at the desired height.
Page 9: Manual Lumbar
Manual Lumbar If the vehicle has this feature, the knob is located on the inboard side of the driver seatback. Turn the knob clockwise or counterclockwise to increase or decrease the lumbar support. Heated Seats On vehicles with heated front seats the controls are located on the center console.
Page 10 Seats and Restraint System To recline the seatback: 1. Lift the recline lever. 2. Move the seatback to the desired position, then release the lever to lock the seatback in place. 3. Push and pull on the seatback to make sure it is locked. To return the seatback to an upright position: 1.
Page 11: Passenger Folding Seatback
Do not have a seatback reclined if the vehicle is moving. Seats and Restraint System Passenger Folding Seatback The front passenger seatback may fold ﬂat. CAUTION If you fold the seatback forward to carry longer objects, such as skis, be sure any such cargo is not near an airbag.
Page 12 Seats and Restraint System 3. Lift the recliner lever, located on the outboard side of the seat, up fully and fold the seatback forward until it disengages. 4. Continue to fold the seat forward into the folded position. 5. Pull up on the seatback to be sure it is locked.
Page 13: Rear Seats
Rear Seats Split Folding Rear Seat The rear split bench seatbacks can be folded forward, upright, or partially reclined, independent of the other seatback position. CAUTION If either seatback is not locked, it could move forward in a sudden stop or crash. That could cause injury to the person sitting there.
Page 14: Safety Belts
1-10 Seats and Restraint System Safety Belts Safety Belts: They Are for Everyone This section of the manual describes how to use safety belts properly. It also describes some things not to do with safety belts. CAUTION Do not let anyone ride where a safety belt cannot be worn properly.
Page 15 Why Safety Belts Work When you ride in or on anything, you go as fast as it goes. Take the simplest vehicle. Suppose it is just a seat on wheels. Seats and Restraint System Put someone on it. Get it up to speed. Then stop the vehicle.
Page 16 1-12 Seats and Restraint System or the instrument panel... or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That is why safety belts make such good sense.
Page 17: How To Wear Safety Belts Properly
If I am a good driver, and I never drive far from home, why should I wear safety belts? You may be an excellent driver, but if you are in a crash — even one that is not your fault — you and your passenger(s) can be hurt.
Page 18 1-14 Seats and Restraint System fatal injuries. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The shoulder belt locks if there is a sudden stop or crash.
Page 19 What is wrong with this? The belt is buckled in the wrong buckle. Seats and Restraint System CAUTION You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not on the pelvic bones.
Page 20 1-16 Seats and Restraint System What is wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. CAUTION You can be seriously injured if you wear the shoulder belt under your arm.
Page 21: Lap-Shoulder Belt
CAUTION You can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, you would not be restrained by the shoulder belt. Your body could move too far forward increasing the chance of head and neck injury. You might also slide under the lap belt.
Page 22 1-18 Seats and Restraint System The lap-shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly. If the shoulder portion of a passenger belt is pulled out all the way, the child restraint locking feature may be engaged.
Page 23 To unlatch the belt, push the button on the buckle. The belt should return to its stowed position. Slide the latch plate up the safety belt webbing when the safety belt is not in use. The latch plate should rest on the stitching on the safety belt, near the guide loop on the side wall.
Page 24 1-20 Seats and Restraint System Safety Belt Pretensioners This vehicle has safety belt pretensioners for the front outboard occupants. Although the safety belt pretensioners cannot be seen, they are part of the safety belt assembly. They can help tighten the safety belts during the early stages of a moderate to severe frontal, near frontal, or rear crash if...
Page 25 3. Be sure that the belt is not twisted and it lies ﬂat. The elastic cord must be under the belt and the guide on top. Seats and Restraint System CAUTION A safety belt that is not properly worn may not provide the protection needed in a crash.
Page 26: Safety Belt Use During Pregnancy
1-22 Seats and Restraint System Safety Belt Use During Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they do not wear safety belts. A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout...
Page 27 The manufacturer’s instructions that come with the booster seat, state the weight and height limitations for that booster. Use a booster seat with a lap-shoulder belt until the child passes the below ﬁt test: • Sit all the way back on the seat.
Page 28 1-24 Seats and Restraint System CAUTION Never do this. Never allow two children to wear the same safety belt. The safety belt can not properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A safety belt must be used by only one person at a time.
Page 29: Infants And Young Children
Infants and Young Children Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must...
Page 30 1-26 Seats and Restraint System CAUTION Never do this. Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Never put a rear-facing child restraint in the right front seat. Secure a rear-facing child restraint in a rear seat.
Page 31: Child Restraint Systems
CAUTION To reduce the risk of neck and head injury during a crash, infants need complete support. This is because an infant’s neck is not fully developed and its head weighs so much compared with the rest of its body. In a crash, an infant in a rear-facing child restraint settles into the restraint, so the crash forces can be...
Page 32 1-28 Seats and Restraint System (B) Forward-Facing Child Seat A forward-facing child seat (B) provides restraint for the child’s body with the harness. (C) Booster Seats A booster seat (C) is a child restraint designed to improve the ﬁt of the vehicle’s safety belt system. A booster seat can also help a child to see out the window.
Page 33: Where To Put The Restraint
To help reduce the chance of injury, the child restraint must be secured in the vehicle. Child restraint systems must be secured in vehicle seats by lap belts or the lap belt portion of a lap-shoulder belt, or by the LATCH system. See Lower Anchors and Tethers for Children (LATCH) on page 1-31 for more information.
Page 34 1-30 Seats and Restraint System A label on the sun visor says, “Never put a rear-facing child restraint in the front.” This is because the risk to the rear-facing child is so great, if the airbag deploys. CAUTION A child in a rear-facing child restraint can be seriously injured or killed if the right front passenger airbag inﬂates.
Page 35: Lower Anchors And Tethers For Children (Latch)
Lower Anchors and Tethers for Children (LATCH) The LATCH system holds a child restraint during driving or in a crash. This system is designed to make installation of a child restraint easier. The LATCH system uses anchors in the vehicle and attachments on the child restraint that are made for use with the LATCH system.
Page 36 1-32 Seats and Restraint System Top Tether Anchor A top tether (A, C) anchors the top of the child restraint to the vehicle. A top tether anchor is built into the vehicle. The top tether attachment (B) on the child restraint connects to the top tether anchor in the vehicle in order to reduce the forward movement and rotation...
Page 37 To assist you in locating the lower anchors, each seating position with lower anchors has two labels, near the crease between the seatback and the seat cushion. To assist you in locating the top tether anchors, the top tether anchor symbol is located near the top tether anchors.
Page 38 1-34 Seats and Restraint System Securing a Child Restraint Designed for the LATCH System CAUTION If a LATCH-type child restraint is not attached to anchors, the child restraint will not be able to protect the child correctly. In a crash, the child could be seriously injured or killed.
Page 39 Do not fold the empty rear seat with a safety belt buckled. This could damage the safety belt or the seat. Unbuckle and return the safety belt to its stowed position, before folding the seat. 1. Attach and tighten the lower attachments to the lower anchors.
Page 40: Securing A Child Restraint In A Rear Seat Position
1-36 Seats and Restraint System If the position you are using has an adjustable headrest or head restraint and you are using a dual tether, route the tether around the headrest or head restraint. If the position you are using has an adjustable headrest or head restraint and you are using a single...
Page 41 In Canada, the law requires that forward-facing child restraints have a top tether, and that the tether be attached. If the child restraint does not have the LATCH system, you will be using the safety belt to secure the child restraint in this position.
Page 42: Securing A Child Restraint In The Right Front Seat Position
1-38 Seats and Restraint System 5. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor. When installing a forward-facing child restraint, it may be helpful to use your knee to push down on...
Page 43 CAUTION A child in a rear-facing child restraint can be seriously injured or killed if the right front passenger airbag inﬂates. This is because the back of the rear-facing child restraint would be very close to the inﬂating airbag. A child in a forward-facing child restraint can be seriously injured or killed if the right front passenger airbag inﬂates and the...
Page 44 1-40 Seats and Restraint System You will be using the lap-shoulder belt to secure the child restraint in this position. Follow the instructions that came with the child restraint. 1. Move the seat as far back as it will go before securing the forward-facing child restraint.
Page 45: Airbag System
6. To tighten the belt, push down on the child restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor. When installing a forward-facing child restraint, it may be helpful to use your knee to push down on the child restraint as you tighten...
Page 46 1-42 Seats and Restraint System For frontal airbags, the word AIRBAG will appear on the middle part of the steering wheel for the driver and on the instrument panel for the right front passenger. With seat-mounted side impact airbags, the word AIRBAG will appear on the side of the seatback closest to the door.
Page 47 CAUTION Airbags inﬂate with great force, faster than the blink of an eye. Anyone who is up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Do not sit unnecessarily close to the airbag, as you would be if you were sitting on the edge of your seat or leaning forward.
Page 48: Where Are The Airbags
1-44 Seats and Restraint System Where Are the Airbags? The driver frontal airbag is in the middle of the steering wheel. The right front passenger frontal airbag is in the instrument panel on the passenger side. Driver Side shown, Passenger Side similar The seat-mounted side impact airbags for the driver and right front...
Page 49: When Should An Airbag Inﬂate
Driver Side shown, Passenger Side similar The roof-rail airbags for the driver, right front passenger, and second row outboard passengers are in the ceiling above the side windows. Seats and Restraint System CAUTION If something is between an occupant and an airbag, the airbag might not inﬂate properly or it might force the object into that person causing severe injury or...
Page 50 1-46 Seats and Restraint System Frontal airbags may inﬂate at different crash speeds. For example: • If the vehicle hits a stationary object, the airbags could inﬂate at a different crash speed than if the vehicle hits a moving object. •...
Page 51: What Makes An Airbag Inﬂate
is determined by the location and severity of the side impact. In a rollover event, roof-rail airbag deployment is determined by the direction of the roll. What Makes an Airbag Inﬂate? In a deployment event, the sensing system sends an electrical signal triggering a release of gas from the inﬂator.
Page 52: What Will You See After An Airbag Inﬂates
1-48 Seats and Restraint System What Will You See After an Airbag Inﬂates? After the frontal airbags and seat-mounted side impact airbags inﬂate, they quickly deﬂate, so quickly that some people may not even realize an airbag inﬂated. Roof-rail airbags may still be at least partially inﬂated for some time after they deploy.
Page 53: Passenger Sensing System
• The vehicle has a crash sensing and diagnostic module which records information after a crash. See Vehicle Data Recording and Privacy on page 7-14 and Event Data Recorders on page 7-14. • Let only qualiﬁed technicians work on the airbag systems. Improper service can mean that an airbag system will not work properly.
Page 54 1-50 Seats and Restraint System According to accident statistics, children are safer when properly secured in a rear seat in a correct child restraint for their weight and size. We recommend that children be secured in a rear seat, including: an infant or a child riding in a rear-facing child restraint;...
Page 55 If the vehicle does not have a rear seat that will accommodate a rear-facing child restraint, a rear-facing child restraint should not be installed in the vehicle, even if the airbag is off. The passenger sensing system is designed to turn off the right front passenger airbag and seat-mounted side impact airbag if: •...
Page 56 1-52 Seats and Restraint System For some children who have outgrown child restraints and for very small adults, the passenger sensing system may or may not turn off the right front passenger frontal airbag and seat-mounted side impact airbag, depending upon the person’s seating posture and body build.
Page 57 If the Off Indicator is Lit for an Adult-Size Occupant If a person of adult-size is sitting in the right front passenger seat, but the off indicator is lit, it could be because that person is not sitting properly in the seat. Seats and Restraint System If this happens, use the following steps to allow the system to detect...
Page 58: Servicing Your Airbag-Equipped Vehicle
1-54 Seats and Restraint System A thick layer of additional material, such as a blanket or cushion, or aftermarket equipment such as seat covers, seat heaters, and seat massagers can affect how well the passenger sensing system operates. We recommend that you not use seat covers or other aftermarket equipment except when approved by GM for your speciﬁc...
Page 59: Adding Equipment To Your Airbag-Equipped Vehicle
Adding Equipment to Your Airbag-Equipped Vehicle Is there anything I might add to or change about the vehicle that could keep the airbags from working properly? Yes. If you add things that change the vehicle’s frame, bumper system, height, front end or side sheet metal, they may keep the airbag system from working properly.
Page 60: Safety Belts
1-56 Seats and Restraint System Because I have a disability, I have to get my vehicle modiﬁed. How can I ﬁnd out whether this will affect my airbag system? If you have questions, call Customer Assistance. The phone numbers and addresses for Customer Assistance are in Step Two of the Customer Satisfaction Procedure in this manual.
Page 61: Replacing Restraint System Parts After A Crash
Replacing Restraint System Parts After a Crash CAUTION A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any...
Page 62 1-58 Seats and Restraint System ✍ NOTES...
Page 63 Features and Controls Keys Keys ...2-2 Remote Keyless Entry (RKE) System ...2-3 Remote Keyless Entry (RKE) System Operation ...2-4 Doors and Locks Door Locks ...2-6 Power Door Locks ...2-6 Delayed Locking ...2-6 Automatic Door Lock ...2-7 Automatic Door Unlock ...2-7 Rear Door Security Locks ...2-7...
Page 64 Features and Controls Storage Areas Glove Box ...2-37 Cupholders ...2-37 Sunglasses Storage Compartment ...2-37 ...2-37 Center Console Storage Driver Storage Compartment ...2-38 Rear Seat Armrest ...2-38 Convenience Net ...2-38 ...2-38 Cargo Cover Cargo Tie Downs ...2-39 Cargo Management System ...2-39 Keys CAUTION Leaving children in a vehicle with...
Page 65: Features And Controls
Notice: If you ever lock your keys in the vehicle, you may have to damage the vehicle to get in. Be sure you have spare keys. If you are locked out of the vehicle, contact Roadside Assistance. See Roadside Assistance Program on page 7-5 for more information.
Page 66: Remote Keyless Entry (Rke) System Operation
Features and Controls Remote Keyless Entry (RKE) System Operation The Remote Keyless Entry (RKE) transmitter functions work up to 65 feet (20 m) away from the vehicle. There are other conditions which can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System on page 2-3.
Page 67 Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer/ retailer. When the replacement transmitter is programmed to the vehicle, all remaining transmitters must also be programmed.
Page 68: Doors And Locks
Features and Controls Doors and Locks Door Locks CAUTION Unlocked doors can be dangerous. • Passengers, especially children, can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle will not open it. You increase the chance of being thrown out of the vehicle in a crash if the doors are not locked.
Page 69: Automatic Door Lock
Automatic Door Lock The doors are programmed to automatically lock when the shift lever is moved into a forward gear. The automatic door lock feature cannot be disabled. Automatic Door Unlock The doors will automatically unlock when the shift lever is moved into (P) Park.
Page 70: Windows
Features and Controls Liftgate CAUTION Exhaust gases may enter the vehicle if it is driven with the liftgate, trunk/hatch open, or with any objects that pass through the seal between the body and the trunk/hatch or liftgate. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled.
Page 71: Windows
Windows CAUTION Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 72: Sun Visors
2-10 Features and Controls To open or close a window, press or pull up on the switch. The power windows operate when the ignition is in ON/RUN or ACC/ACCESSORY, or while in Retained Accessory Power (RAP). See Retained Accessory Power (RAP) on page 2-15.
Page 73 To arm the theft-deterrent system, close all doors and press on the RKE transmitter. The security light comes on solid for approximately 30 seconds and then ﬂashes slowly. is pressed a second time, the theft-deterrent system activates immediately. The content theft deterrent alarm is not armed until the security light ﬂashes slowly.
Page 74: Theft-Deterrent Systems
2-12 Features and Controls ® PASS-Key III+ Electronic Immobilizer The PASS-Key III+ system operates on a radio frequency subject to Federal Communications Commission (FCC) Rules and with Industry Canada. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
Page 75 When trying to start the vehicle if the engine does not start and the security light on the instrument panel cluster comes on, there may be a problem with your theft-deterrent system. Turn the ignition off and try again. If the engine still does not start, and the key appears to be not damaged, wait about ﬁve minutes and try another ignition key and...
Page 76: Starting And Operating Your Vehicle New Vehicle Break-In
2-14 Features and Controls Starting and Operating Your Vehicle New Vehicle Break-In Notice: The vehicle does not need an elaborate break-in. But it will perform better in the long run if you follow these guidelines: • Do not drive at any one constant speed, fast or slow, for the ﬁrst 500 miles (805 km).
Page 77: Retained Accessory Power (Rap)
ACC (ACC/ACCESSORY): This is the position in which you can operate the electrical accessories or items plugged into the accessory power outlets. Use this position if the vehicle must be pushed or towed. ON/RUN: This position can be used to operate the electrical accessories and to display some instrument panel cluster warning and indicator lights.
Page 78: Your Vehicle
2-16 Features and Controls Operate the engine and transmission gently to allow the oil to warm up and lubricate all moving parts. The vehicle has a Computer-Controlled Cranking System. This feature assists in starting the engine and protects components. If the ignition key is turned to the START position, and then released when the engine begins cranking, the...
Page 79 Automatic Engine Start/Stop CAUTION There is something about the vehicle that can make it move suddenly, and you or others can be seriously injured. This can happen if the vehicle is in the Auto Stop mode, and the shift lever is in D (Drive). Because the vehicle has the Automatic Engine Start/Stop feature, the vehicle’s engine might seem to be shut off...
Page 80 2-18 Features and Controls The Engine Will Remain Running When: • The engine, transmission, or hybrid battery is not warmed up yet. • The outside temperature is high — usually above 95°F (35°C) and the climate control system is working to cool the vehicle in A/C mode (yellow light illuminated on A/C button) or if defrost is...
Page 81: Engine Coolant Heater
Engine Coolant Heater The engine coolant heater can provide easier starting and better fuel economy during engine warm-up in cold weather conditions at or below 0°F (−18°C). Vehicles with an engine coolant heater should be plugged in at least four hours before starting.
Page 82: Automatic Transmission Operation
2-20 Features and Controls Automatic Transmission Operation The shift lever is located on the console between the seats. There are several different positions for the automatic transmission. P (Park): This position locks the front wheels. It is the best position to use when you start the engine because the vehicle cannot move easily.
Page 83 N (Neutral): In this position, the engine does not connect with the wheels. To restart the engine when the vehicle is already moving, use N (Neutral) only. Also, use N (Neutral) when your vehicle is being towed. CAUTION Shifting into a drive gear while the engine is running at high speed is dangerous.
Page 84: Parking Brake
2-22 Features and Controls Manual Shift Mode (MSM) (Automatic Transmission) To use this feature, do the following: 1. Move the shift lever from D (Drive) rearward to the M (Manual Mode). The display will show a 3 for third gear. When coming to a stop in the manual position, the vehicle will automatically shift...
Page 85: Regenerative Braking
To release the parking brake, hold the brake pedal down. Pull the parking brake lever up until you can press the release button. Hold the release button in as you move the brake lever all the way down. Release the parking brake before driving the vehicle.
Page 86 2-24 Features and Controls 3. Turn the ignition key to LOCK/OFF. 4. Remove the key and take it with you. If you can leave the vehicle with the key, the vehicle is in P (Park). Leaving the Vehicle With the Engine Running CAUTION It can be dangerous to leave the...
Page 87: Shifting Out Of Park
Shifting Out of Park The vehicle has an electronic shift lock release system. The shift lock release is designed to: • Prevent ignition key removal unless the shift lever is in P (Park) with the shift lever button fully released. •...
Page 88: Engine Exhaust
2-26 Features and Controls Engine Exhaust CAUTION Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. Exposure to CO can cause unconsciousness and even death. Exhaust may enter the vehicle if: • The vehicle idles in areas with poor ventilation (parking garages, tunnels, deep snow that may block underbody...
Page 89: Mirrors
CAUTION Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. Never run the engine in an enclosed area that has no fresh air ventilation.
Page 90: Outside Power Mirrors
2-28 Features and Controls Outside Power Mirrors Controls for the outside power mirrors are located on the driver door. To adjust the power mirrors: 1. Turn the knob to choose the left (L) or the (R) right mirror. 2. Adjust each mirror so that you can see the side of your vehicle and the area behind your vehicle.
Page 91: Onstar ® System
® OnStar System OnStar uses several innovative technologies and live advisors to provide a wide range of safety, security, information, and convenience services. If the airbags deploy, the system is designed to make an automatic call to OnStar Emergency advisors who can request emergency services be sent to your location.
Page 92 2-30 Features and Controls • Remote Door Unlock/ Vehicle Alert • OnStar Vehicle Diagnostic Email • GM Goodwrench On Demand Diagnostics • OnStar Hands-Free Calling with 30 trial minutes • OnStar Virtual Advisor (U.S. Only) OnStar Services Included with Directions & Connections Plan •...
Page 93 OnStar Steering Wheel Controls This vehicle may have a Talk/Mute button that can be used to interact with OnStar Hands-Free Calling. See Audio Steering Wheel Controls on page 3-82 for more information. OnStar voice command does not work unless Personal Calling is activated.
Page 94: Universal Home Remote System
2-32 Features and Controls Your Responsibility Increase the volume of the radio if the OnStar advisor cannot be heard. If the light next to the OnStar buttons is red, the system may not be functioning properly. Press the OnStar button and request a vehicle diagnostic.
Page 95: Universal Home Remote System Operation
Universal Home Remote System Operation If there is one triangular Light Emitting Diode (LED) indicator light above the Universal Home Remote buttons, follow the instructions below. This system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices.
Page 96 2-34 Features and Controls To program up to three devices: 1. From inside the vehicle, press and hold down the two outside buttons at the same time, releasing only when the Universal Home Remote indicator light begins to ﬂash, after 20 seconds. This step will erase the factory settings or all previously programmed buttons.
Page 97 It may be helpful to have another person assist with the remaining steps. 6. After Steps 1 through 5 have been completed, locate inside the garage the garage door opener receiver (motor-head unit). Locate the “Learn” or “Smart” button. The name and color of the button may vary by manufacturer.
Page 98 2-36 Features and Controls If you live in Canada, or you are having difficulty programming a gate operator or garage door opener by using the “Programming Universal Home Remote” procedures, regardless of where you live, replace Step 3 under “Programming Universal Home Remote”...
Page 99: Universal Home Remote System
Reprogramming a Single Universal Home Remote Button To reprogram any of the three Universal Home Remote buttons, repeat the programming instructions earlier in this section, beginning with Step 2. For help or information on the Universal Home Remote System, call the customer assistance phone number under Customer Assistance Offices on page 7-5.
Page 100: Driver Storage Compartment
2-38 Features and Controls The top of the center console can extend forward. To adjust, hold the top of the lever up and pull the top of the center console forward. To open the cover of the the rear storage area, push the button located at the top.
Page 101: Cargo Tie Downs
Cargo Tie Downs Four cargo tie-downs are located in the rear compartment of the vehicle. The tie-downs can be used to secure small loads. Cargo Management System If the vehicle has a cargo management system in the rear of the vehicle, it will have rails with adapters and hooks.
Page 102 2-40 Features and Controls ✍ NOTES...
Page 103: Instrument Panel
Instrument Panel Instrument Panel Overview Instrument Panel Overview ...3-4 Hazard Warning Flashers ...3-5 Horn ...3-5 Tilt Wheel ...3-6 Turn Signal/Multifunction ...3-6 Lever Turn and Lane-Change Signals ...3-6 Headlamp High/ Low-Beam Changer ...3-7 Flash-to-Pass ...3-7 Windshield Wipers ...3-7 Rainsense™ II Wipers ...3-8 ...3-8 Windshield Washer...
Page 104: Driver Information Center (Dic)
Instrument Panel Tire Pressure Light ...3-29 Malfunction Indicator Lamp ...3-30 ...3-33 Oil Pressure Light Change Engine Oil Light ...3-33 Security Light ...3-33 Cruise Control Light ...3-33 Highbeam On Light ...3-34 Low Washer Fluid Warning Light ...3-34 Fuel Gage ...3-34 Low Fuel Warning Light ...3-34 Auto Stop Mode ...3-35...
Page 105 Instrument Panel ✍ NOTES...
Page 106: Instrument Panel Overview
Instrument Panel Instrument Panel Overview...
Page 107: Audio System(S)
The main components of the instrument panel are the following: A. Outlet Adjustment on page 3-22. B. Instrument Panel Brightness on page 3-14. C. Turn Signal/Multifunction Lever on page 3-6. D. Instrument Panel Cluster on page 3-23. E. Windshield Wipers on page 3-7. F.
Page 108: Tilt Wheel
Instrument Panel Tilt Wheel The tilt lever lets the steering wheel be adjusted. The tilt lever is located on the left side of the steering column. To adjust the steering wheel, hold the wheel and push the lever down. Then move the wheel to a comfortable position and pull the lever up ﬁrmly to lock the steering column in place.
Page 109: Headlamp High/Low-Beam Changer
Have the bulbs replaced. If a bulb is not burned out, check the fuse. See Fuses and Circuit Breakers on page 5-75 and for burned-out bulbs. Headlamp High/ Low-Beam Changer Headlamp High/Low Beam Changer: Push the turn signal/multifunction lever away from you to turn the high beams on.
Page 110: Rainsense™ Ii Wipers
Instrument Panel Heavy snow or ice can overload the wiper motor. A circuit breaker will stop the motor until it cools down. Rainsense™ II Wipers For vehicles with Rainsense™ II windshield wipers, the moisture sensor is located next to the inside rearview mirror and is mounted on the windshield.
Page 111: Rear Window Wiper/Washer
Rear Window Wiper/Washer The rear wiper and rear wash button is located on the instrument panel above the climate control system. (Rear Wiper/Washer): Press to wash and wipe the rear window. The rear window washer uses the same reservoir as the windshield washer.
Page 112 3-10 Instrument Panel Setting Cruise Control CAUTION If you leave your cruise control on when you are not using cruise, you might hit a button and go into cruise when you do not want to. You could be startled and even lose control.
Page 113 • To increase the speed in small amounts, press the thumbwheel up toward RES+ brieﬂy and then release it. Each time this is done, the vehicle goes about 1 mph (1.6 km/h) faster. • Use the accelerator pedal to reach the desired speed and press the thumbwheel towards −SET.
Page 114: Exterior Lamps
3-12 Instrument Panel Exterior Lamps The exterior lamp control is located on the instrument panel to the left of the steering wheel. The exterior lamp control can be turned to the following positions: (Off): Turns off the exterior lamps. The knob returns to the AUTO position after it is released.
Page 115: Daytime Running Lamps (Drl)
Daytime Running Lamps (DRL) Daytime Running Lamps (DRL) can make it easier for others to see the front of your vehicle during the day. Fully functional daytime running lamps are required on all vehicles ﬁrst sold in Canada. The DRL system makes the low-beam headlamps come on in daylight when the following conditions are met:...
Page 116: Instrument Panel Brightness
3-14 Instrument Panel Instrument Panel Brightness This feature controls the brightness of the instrument panel lights. The thumbwheel for this feature is located on the left side of the steering wheel next to the exterior lamps control. Turn the thumbwheel to the right or left to brighten or dim the lights.
Page 117: Battery Run-Down Protection
on the Driver Information Center (DIC), you may see the voltage move up or down. This is normal. If there is a problem, an alert will be displayed. The battery can be discharged at idle if the electrical loads are very high.
Page 118: Accessory Power Outlet(S)
3-16 Instrument Panel Accessory Power Outlet(s) The accessory power outlets can be used to connect electrical equipment, such as a cellular phone. The accessory power outlets are located on the rear of the center storage console and in the rear cargo compartment. There may be a power outlet located inside the instrument panel storage area below the climate controls.
Page 119: Climate Controls Automatic Climate Control System
Climate Controls Automatic Climate Control System The heating, cooling, and ventilation for the vehicle can be controlled with this system. A. Fan Control B. Temperature Control C. Air Delivery Mode Control D. Normal Air Conditioning E. Hybrid Air Conditioning F. Recirculation G.
Page 120 3-18 Instrument Panel Automatic Operation This climate control system automatically maintains the desired temperature inside the vehicle. Do not cover the sensor located on the top of the instrument panel near the windshield or the sensor grille below the climate control faceplate.
Page 121 Temperature Control: Turn clockwise or counterclockwise to increase or decrease the temperature. Typically, the best setting is near 75°F (23°C). Choosing the coldest or warmest temperature setting does not cause the system to heat or cool any faster. Air Delivery Mode Control: Turn clockwise or counterclockwise to change the direction of the airﬂow inside the vehicle.
Page 122 3-20 Instrument Panel (Normal Air Conditioning): Press to turn the air conditioning system on or off. An indicator light comes on to show that the air conditioning is on. Normal Air Conditioning (A/C) can be selected in any mode as long as the fan is on and the outside air temperature is above freezing.
Page 123 The rear window defogger stays on for about 10 minutes if the vehicle remains at slower vehicle speeds or until the button is pressed, or unless the ignition is turned to ACC/ACCESSORY or LOCK/OFF. If turned on again, the defogger only runs for about ﬁve minutes before turning off again.
Page 124: Outlet Adjustment
3-22 Instrument Panel Outlet Adjustment Use the louvers located on the air outlets to change the direction of the airﬂow. Operation Tips • Clear away any ice, snow, or leaves from the air inlets at the base of the vehicle that may block the ﬂow of air into the vehicle.
Page 125: Instrument Panel Cluster
Instrument Panel 3-23 Instrument Panel Cluster The instrument panel cluster is designed to indicate how the vehicle is running. It shows how fast the vehicle is going, about how much fuel the vehicle has left and many other things needed to drive safely and economically. United States cluster, Canada similar...
Page 126: Speedometer And Odometer
3-24 Instrument Panel Speedometer and Odometer The speedometer shows the vehicle’s speed in both miles per hour (mph) and kilometers per hour (km/h). The odometer shows how far the vehicle has been driven, in either miles or kilometers. If the vehicle needs a new odometer installed, the new one is set to the mileage total of the old odometer.
Page 127: Airbag Readiness Light
Passenger Safety Belt Reminder Light Several seconds after the engine is started, a chime sounds for several seconds to remind the front passenger to buckle their safety belt. This only occurs if the passenger airbag is enabled. See Passenger Sensing System on page 1-49 for more information.
Page 128: Passenger Airbag Status Indicator
3-26 Instrument Panel If the airbag readiness light stays on after the vehicle is started or comes on while driving, the airbag system may not work properly. Have the vehicle serviced right away. The airbag readiness light should ﬂash for a few seconds when the engine is started.
Page 129: Charging System Light
CAUTION If the airbag readiness light ever comes on and stays on, it means that something may be wrong with the airbag system. To help avoid injury to yourself or others, have the vehicle serviced right away. See Airbag Readiness Light on page 3-25 for more information, including important safety information.
Page 130: Antilock Brake System (Abs) Warning Light
3-28 Instrument Panel Antilock Brake System (ABS) Warning Light For vehicles with the Antilock Brake System (ABS), this light should come on brieﬂy as the engine is started. If it does not come on have the vehicle serviced by your dealer/retailer. If the ABS light stays on longer than a few seconds after engine is started, or comes on and stays on...
Page 131: Engine Coolant Temperature Warning Light
TCS and/or StabiliTrak system automatically turns off and vehicle needs service. When this light is on, the TCS system does not limit wheel spin and/or the StabiliTrak system does not assist with vehicle control. When the Traction Control system and/or StabiliTrak system are turned off, the light comes on.
Page 132: Malfunction Indicator Lamp
3-30 Instrument Panel Warnings and Messages on page 3-42 for more information. Stop and check the tires as soon as it is safe to do so. If underinﬂated, inﬂate to the proper pressure. See Tires on page 5-38 for more information.
Page 133 Notice: Modiﬁcations made to the engine, transmission, exhaust, intake, or fuel system of the vehicle or the replacement of the original tires with other than those of the same Tire Performance Criteria (TPC) can affect the vehicle’s emission controls and can cause this light to come on.
Page 134 3-32 Instrument Panel • Make sure to fuel the vehicle with quality fuel. Poor fuel quality causes the engine not to run as efficiently as designed and may cause: stalling after start-up, stalling when the vehicle is changed into gear, misﬁring, hesitation on acceleration, or stumbling on acceleration.
Page 135: Maintenance Schedule
Oil Pressure Light CAUTION Do not keep driving if the oil pressure is low. The engine can become so hot that it catches ﬁre. Someone could be burned. Check the oil as soon as possible and have the vehicle serviced. Notice: Lack of proper engine oil maintenance can damage the engine.
Page 136: Highbeam On Light
3-34 Instrument Panel Highbeam On Light The highbeam on light comes on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 3-7 for more information. Low Washer Fluid Warning Light The low washer ﬂuid warning light comes on when the windshield washer ﬂuid is low.
Page 137: Auto Stop Mode
This light also comes on when the fuel tank is low on fuel. When fuel is added, the light should go off. If it does not, have the vehicle serviced. Auto Stop Mode United States Canada This mark on the tachometer signiﬁes that the engine is in Auto Stop mode which is a fuel saving operation.
Page 138: Driver Information Center (Dic)
3-36 Instrument Panel Driver Information Center (DIC) Your vehicle has a Driver Information Center (DIC). All information appears in the DIC display located in the instrument panel cluster. The DIC comes on when the ignition is on. After a short delay, the DIC displays the information that was last displayed before the engine was turned off.
Page 139 (Vehicle Information): Press this button to display the oil life, units, tire pressure readings for vehicles with the Tire Pressure Monitor System (TPMS), Remote Keyless Entry (RKE) transmitter programming, economy light on/off, compass zone setting, and compass recalibration on vehicles with this feature.
Page 140 3-38 Instrument Panel amount of fuel is in the fuel tank. This is because different driving conditions produce different fuel economies. Generally, freeway driving produces better fuel economy than city driving. Fuel range cannot be reset. If the vehicle is low on fuel, the FUEL LEVEL LOW message will be displayed.
Page 141 oil life system monitoring the oil life, additional maintenance is recommended in the Maintenance Schedule in this manual. See Scheduled Maintenance on page 6-3 for more information. Units Press the vehicle information button until UNITS displays. This display allows you to select between English or Metric units of measurement.
Page 142: Dic Compass
3-40 Instrument Panel 4. To match additional transmitters at this time, repeat Step 3. Each vehicle can have a maximum of eight transmitters matched to it. 5. To exit the programming mode, you must cycle the key to LOCK/OFF. Compass Zone Setting This display allows for setting the compass zone.
Page 143 2. Find the vehicle’s current location and variance zone number on the map. Zones 1 through 15 are available. 3. Press and hold the set/reset button to scroll through and select the appropriate variance zone. 4. Press the trip/fuel button until the vehicle heading, for example, N for North, is displayed in the DIC.
Page 144: Dic Warnings And Messages
3-42 Instrument Panel 3. Press the set/reset button to start the compass calibration. 4. The DIC will display CALIBRATING COMPASS: TURN IN CIRCLES. Drive the vehicle in tight circles at less than 5 mph (8 km/h) to complete the calibration. The DIC will display COMPASS CALIBRATION COMPLETE for a few seconds when the calibration is complete.
Page 145 Acknowledging this message will not reset the OIL LIFE REMAINING display. That must be done at the OIL LIFE screen. See “OIL LIFE” under DIC Operation and Displays on page 3-36 and Engine Oil Life System on page 5-14 for more information.
Page 146 3-44 Instrument Panel ENGINE HOT A/C (Air Conditioning) OFF This message displays when the engine coolant becomes hotter than the normal operating temperature. To avoid added strain on a hot engine, the air conditioning compressor is automatically turned off. When the coolant temperature returns to normal, the A/C operation automatically resumes.
Page 147 FUEL LEVEL LOW This message displays when your vehicle is low on fuel. Reﬁll the fuel tank as soon as possible. See Fuel Gage on page 3-34 and Filling the Tank on page 5-7 for more information. HOOD OPEN This message displays on some vehicles when the hood is not closed properly.
Page 148 3-46 Instrument Panel REMOTE KEY LEARNING COMPLETE This message displays while matching a Remote Keyless Entry (RKE) transmitter to your vehicle. See “MATCHING TRANSMITTERS TO YOUR VEHICLE” under Remote Keyless Entry (RKE) System Operation on page 2-4 and DIC Operation and Displays on page 3-36 for more information.
Page 149 SERVICE STABILITRAK This message displays if there has been a problem detected with ® StabiliTrak . A warning light also appears on the instrument ® panel cluster. See StabiliTrak Traction Control System (TCS) Warning Light on page 3-28. See ® StabiliTrak System on page 4-7 for more information.
Page 150 3-48 Instrument Panel STABILITRAK NOT READY If your vehicle has StabiliTrak, this message may display and the StabiliTrak indicator light on the instrument panel cluster may be on after ﬁrst driving the vehicle and exceeding 20 mph (32 km/h) for 30 seconds. The StabiliTrak system is not functional until the light ®...
Page 151: Dic Vehicle Customization
Any of the following conditions may cause the TCS to turn off: • The TCS is turned off by pressing the TCS/StabiliTrak button. See ® StabiliTrak System on page 4-7 for more information. • The battery is low. • There is a TCS failure. See your dealer/retailer for service.
Page 152 3-50 Instrument Panel To change customization preferences, use the following procedure. Entering the Feature Settings Menu 1. Turn the ignition on and place the vehicle in P (Park). To avoid excessive drain on the battery, it is recommended that the headlamps are turned off. 2.
Page 153 AT VEHICLE SPEED: The doors will automatically lock when the vehicle speed is above 8 mph (13 km/h) for three seconds. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/reset button while the desired setting is displayed on the DIC.
Page 154 3-52 Instrument Panel Press the customization button until PRESS TO SET REMOTE DOOR LOCK appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: VERIFICATION OFF: There will be no feedback when you press the lock button on the RKE transmitter.
Page 155 VERIF NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/reset button while the desired setting is displayed on the DIC. DELAY DOOR LOCK On vehicles with a crew cab, this feature allows you to select whether or not the locking of the vehicle’s doors will be delayed.
Page 156 3-54 Instrument Panel NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/reset button while the desired setting is displayed on the DIC. APPROACH LIGHTING This feature allows you to select whether or not to have the exterior lights turn on brieﬂy during low light periods after unlocking...
Page 157 FACTORY SETTINGS This feature allows you to set all of the customization features back to their factory default settings. Press the customization button until PRESS TO RESTORE FACTORY SET appears on the DIC display. Press the set/reset button once to access the settings for this feature.
Page 158: Audio System(S)
3-56 Instrument Panel Audio System(s) Determine which radio the vehicle has and read the following pages to become familiar with its features. CAUTION Taking your eyes off the road for extended periods could cause a crash resulting in injury or death to you or others.
Page 159 4. To increase the time or date do one of the following: • Press the softkey located below the selected tab. ¨ • Press SEEK, or FWD. • Turn clockwise. 5. To decrease the time or date do one of the following: ©...
Page 160: Radio(S)
3-58 Instrument Panel To change the time default setting from 12 hour to 24 hour or to change the date default setting from month/day/year to day/month/year: 1. Press MENU, and then the softkey below the tab. The HR, MIN, MM, DD, YYYY displays.
Page 161 the radio features to work improperly. If this happens, contact the radio station. Playing the Radio (Power/Volume): Press to turn the system on and off. Turn to increase or decrease the volume. Finding a Station BAND: Press to switch between AM, FM, or XM™...
Page 162 3-60 Instrument Panel The number of favorites pages can be setup using the MENU button. To setup the number of favorites pages: 1. Press the MENU button to display the radio setup menu. 2. Press the pushbutton located below the FAV 1-6 label. 3.
Page 163 Turn the knob clockwise or counterclockwise to adjust the highlighted setting. The highlighted setting can also be adjusted by pressing either SEEK arrow, FWD, or REV until the desired levels are obtained. To quickly adjust balance or fade to the middle position, press the pushbutton positioned under the BAL or FADE label for more than two seconds.
Page 164 3-62 Instrument Panel Removed categories can be restored by pressing the pushbutton under the Add tab when a removed category is displayed or by pressing the pushbutton under the Restore All tab. The radio does not allow categories to be removed or added while the vehicle is moving faster than 5 mph (8 km/h).
Page 165 To insert multiple CDs: 1. Press and hold the button for two seconds. A beep sounds and Load All Discs displays. 2. Follow the displayed instruction on when to insert the discs. The CD player takes up to six CDs. 3.
Page 166 3-64 Instrument Panel EJECT: To eject the CD that is currently playing, press and release this button. A beep sounds and Ejecting Disc displays. Once the disc is ejected, Remove Disc displays. The CD can be removed. If the CD is not removed, after several seconds, the CD automatically pulls back into the player and begins playing.
Page 167 Press the CD/AUX button again and the system begins playing audio from the connected portable audio player. If a portable audio player is not connected, “No Input Device Found” displays. Playing an MP3 CD-R or CD-RW Disc The vehicle’s radio system may have the MP3 feature.
Page 168: Using An Mp3
3-66 Instrument Panel (Power/Volume): Turn to increase or decrease the volume of the portable player. Additional volume adjustments might have to be made from the portable device if the volume is not loud or soft enough. BAND: Press to listen to the radio when a portable audio device is playing.
Page 169 • Make sure playlists have a .mp3 or .wpl extension, other ﬁle extensions may not work. • Minimize the length of the ﬁle, folder or playlist names. Long ﬁle, folder, or playlist names, or a combination of a large number of ﬁles and folders, or playlists can cause the player to be unable to play up to the maximum number...
Page 170 3-68 Instrument Panel Order of Play Tracks recorded to the CD-R or CD-RW are played in the following order: • Play begins from the ﬁrst track in the ﬁrst playlist and continues sequentially through all tracks in each playlist. When the last track of the last playlist has played, play continues from the ﬁrst track of the ﬁrst playlist.
Page 171 CD-RW is not removed, after several seconds, the CD-R or CD-RW automatically pulls back into the player and begins playing. For the Six-Disc CD player, press and hold this button for two seconds to eject all discs. (Tune): Turn to select MP3 ﬁles on the CD-R or CD-RW currently playing.
Page 172 3-70 Instrument Panel (Music Navigator): Use the music navigator feature to play MP3 ﬁles on the CD-R or CD-RW in order by artist or album. Press the pushbutton located below the music navigator label. The player scans the disc to sort the ﬁles by artist and album ID3 tag information.
Page 173: Xm Radio Messages
XM Radio Messages XL (Explicit Language Channels): These channels, or any others, can be blocked at a customer’s request, by calling 1-800-852-XMXM (9696). XM Updating: The encryption code in the receiver is being updated, and no action is required. This process should take no longer than 30 seconds.
Page 174: Bluetooth
3-72 Instrument Panel Check XM Receivr: If this message does not clear within a short period of time, the receiver could have a fault. Consult with your dealer/retailer. XM Not Available: If this message does not clear within a short period of time, the receiver could have a fault.
Page 175 Bluetooth functions before pairing the cell phone. If a Bluetooth phone is not connected, calls will be ® made using OnStar Hands-Free Calling, if available. Refer to the OnStar owner’s guide for more information. Pairing Information: • Up to ﬁve cell phones can be paired to the in-vehicle Bluetooth system.
Page 176 3-74 Instrument Panel Listing All Paired and Connected Phones 1. Press and hold two seconds. The system responds with “Ready” followed by a tone. 2. Say “Bluetooth”. The system responds with “Bluetooth ready” followed by a tone. 3. Say “List”. The system lists all the paired Bluetooth devices.
Page 177 Using the Store Command The store command allows a phone number to be stored without entering the digits individually. 1. Press and hold two seconds. The system responds with “Ready” followed by a tone. 2. Say “Store”. The system responds with “Store, number please”...
Page 178 3-76 Instrument Panel 3. Say the ﬁrst digit to be stored. The system will repeat back the digit it heard followed by a tone. Continue entering digits until the number to be stored is complete. • If an unwanted number is recognized by the system, say “Clear”...
Page 179 3. Say the name tag to be deleted. The system responds with “Would you like to delete, <name tag>? Please say yes or no”. • If the name tag is correct, say “Yes” to delete the name tag. The system responds with “OK, deleting <name tag>, returning to the main menu.”...
Page 180 3-78 Instrument Panel Using the Digit Dial Command 1. Press and hold two seconds. The system responds with “Ready” followed by a tone. 2. Say “Digit Dial”. The system responds with “Digit dial using <phone name>, please say the ﬁrst digit to dial” followed by a tone.
Page 181 Once connected, the person called will be heard through the audio speakers. Receiving a Call When an incoming call is received, the audio system mutes and a ring tone is heard in the vehicle. • Press and begin speaking to answer the call. Press −...
Page 182 3-80 Instrument Panel Transferring a Call Audio can be transferred between the in-vehicle Bluetooth system and the cell phone. To Transfer Audio to the Cell Phone During a call with the audio in the vehicle: 1. Press . The system responds with “Ready”...
Page 183 3. Say the number to send. • If the system clearly recognizes the number it responds with “OK, Sending Number” and the dial tones are sent and the call continues. • If the system is not sure it recognized the number properly, it responds “Dial Number, Please say yes or no?”...
Page 184: Theft-Deterrent Feature
3-82 Instrument Panel This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference received, including interference that may cause undesired operation of the device.
Page 185: Radio Reception
Radio Reception Frequency interference and static can occur during normal radio reception if items such as cell phone chargers, vehicle convenience accessories, and external electronic devices are plugged into the accessory power outlet. If there is interference or static, unplug the item from the accessory power outlet.
Page 186: Fixed Mast Antenna
3-84 Instrument Panel Fixed Mast Antenna The ﬁxed mast antenna can withstand most car washes without being damaged as long as it is securely attached to the base. If the mast becomes slightly bent, straighten it out by hand. If the mast is badly bent, replace it.
Page 187: Driving Your Vehicle
Driving Your Vehicle Your Driving, the Road, and the Vehicle Driving Your Vehicle ...4-1 Driver Behavior ...4-2 Driving Environment ...4-2 Vehicle Design ...4-2 Driving for Better Fuel Economy ...4-3 Defensive Driving ...4-3 Drunk Driving ...4-4 Control of a Vehicle ...4-4 Braking ...4-5 Antilock Brake...
Page 188: Driving Your Vehicle
Driving Your Vehicle Driver Behavior The single most important thing is this: everyone in the vehicle, including the driver, should buckle up. See Safety Belts: They Are for Everyone on page 1-10. In fact, most serious injuries and fatalities to unbelted occupants can be reduced or prevented by the use of safety belts.
Page 189: Driving For Better Fuel Economy
Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. • Avoid fast starts and accelerate smoothly. • Brake gradually and avoid abrupt stops. • Avoid idling the engine for long periods of time.
Page 190: Drunk Driving
Driving Your Vehicle Drunk Driving CAUTION Drinking and then driving is very dangerous. Your reﬂexes, perceptions, attentiveness, and judgment can be affected by even a small amount of alcohol. You can have a serious — or even fatal — collision if you drive after drinking.
Page 191: Braking
Braking See Brake System Warning Light on page 3-27. Braking action involves perception time and reaction time. Deciding to push the brake pedal is perception time. Actually doing it is reaction time. Average reaction time is about three-fourths of a second. But that is only an average.
Page 192: Antilock Brake System (Abs)
Driving Your Vehicle Antilock Brake System (ABS) This vehicle has the Antilock Brake System (ABS), an advanced electronic braking system that helps prevent a braking skid. When the engine is started and the vehicle begins to drive away, ABS checks itself. A momentary motor or clicking noise might be heard while this test is going on, and it might even be noticed that...
Page 193: Stabilitrak System
® StabiliTrak System The vehicle has a vehicle stability enhancement system called StabiliTrak which combines antilock brake, traction and stability control systems and helps the driver maintain directional control of the vehicle in most driving conditions. StabiliTrak activates when the computer senses a discrepancy between the intended path and the direction the vehicle is actually...
Page 194: Traction Control System (Tcs)
Driving Your Vehicle It is recommended to leave the system on for normal driving conditions, but it may be necessary to turn the system off if the vehicle is stuck in sand, mud, ice or snow, and you want to “rock” the vehicle to attempt to free it.
Page 195: Steering
attempt to free it. See Rocking Your Vehicle to Get It Out on page 4-17 and If Your Vehicle is Stuck in Sand, Mud, Ice, or Snow on page 4-17 for more information. ® The TCS/StabiliTrak button is located on the instrument panel. Press and release this button to turn off TCS.
Page 196: Off-Road Recovery
4-10 Driving Your Vehicle Try to adjust the speed so you can drive through the curve. Maintain a reasonable, steady speed. Wait to accelerate until out of the curve, and then accelerate gently into the straightaway. Steering in Emergencies There are times when steering can be more effective than braking.
Page 197: Passing
Ease off the accelerator and then, if there is nothing in the way, steer so that the vehicle straddles the edge of the pavement. Turn the steering wheel 3 to 5 inches, 8 to 13 cm, (about one-eighth turn) until the right front tire contacts the pavement edge.
Page 198: Driving At Night
4-12 Driving Your Vehicle If the vehicle starts to slide, ease your foot off the accelerator pedal and quickly steer the way you want the vehicle to go. If you start steering quickly enough, the vehicle may straighten out. Always be ready for a second skid if it occurs.
Page 199: Driving In Rain And On Wet Roads
Driving in Rain and on Wet Roads Rain and wet roads can reduce vehicle traction and affect your ability to stop and accelerate. Always drive slower in these types of driving conditions and avoid driving through large puddles and deep-standing or ﬂowing water. CAUTION Wet brakes can cause crashes.
Page 200: Before Leaving On A Long Trip
4-14 Driving Your Vehicle Before Leaving on a Long Trip To prepare your vehicle for a long trip, consider having it serviced by your dealer/retailer before departing. Things to check on your own include: • Windshield Washer Fluid: Reservoir full? Windows clean —...
Page 201: Winter Driving
CAUTION Coasting downhill in N (Neutral) or with the ignition off is dangerous. The brakes will have to do all the work of slowing down and they could get so hot that they would not work well. You would then have poor braking or even none going down a hill.
Page 202 4-16 Driving Your Vehicle Blizzard Conditions Being stuck in snow can be a serious situation. Stay with the vehicle unless there is help nearby. If possible, use the Roadside Assistance Program on page 7-5. To get help and keep everyone in the vehicle safe: •...
Page 203: If Your Vehicle Is Stuck In Sand, Mud, Ice, Or Snow
Repeat this until help arrives but only when you feel really uncomfortable from the cold. Moving about to keep warm also helps. If it takes some time for help to arrive, now and then when you run the engine, push the accelerator pedal slightly so the engine runs faster than the idle speed.
Page 204: Loading The Vehicle
4-18 Driving Your Vehicle Loading the Vehicle It is very important to know how much weight your vehicle can carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo, and all nonfactory-installed options. Two labels on your vehicle show how much weight it may properly carry, the Tire and Loading...
Page 205 The Tire and Loading Information label also shows the size of the original equipment tires (C) and the recommended cold tire inﬂation pressures (D). For more information on tires and inﬂation see Tires on page 5-38 and Inﬂation - Tire Pressure on page 5-43.
Page 206 4-20 Driving Your Vehicle Example 1 Vehicle Capacity Weight for Example 1 = 1,000 lbs (453 kg). Subtract Occupant Weight 150 lbs (68 kg) × 2 = 300 lbs (136 kg). Available Occupant and Cargo Weight = 700 lbs (317 kg). Example 2 Vehicle Capacity Weight for Example 2 = 1,000 lbs...
Page 207 Certiﬁcation/Tire Label Label Example A vehicle speciﬁc Certiﬁcation/Tire label is attached to the lower area of the center pillar (B-Pillar). The label shows the gross weight capacity of your vehicle. This is called the Gross Vehicle Weight Rating (GVWR). The GVWR includes the weight of the vehicle, all occupants, fuel, cargo, and trailer tongue weight, if the vehicle is pulling a...
Page 208: Towing Your Vehicle
4-22 Driving Your Vehicle If you put things inside your vehicle — like suitcases, tools, packages, or anything else, they will go as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, they will keep going.
Page 209: Recreational Vehicle Towing
Recreational Vehicle Towing Recreational vehicle towing means towing the vehicle behind another vehicle – such as behind a motorhome. The two most common types of recreational vehicle towing are known as dinghy towing and dolly towing. Dinghy towing is towing the vehicle with all four wheels on the ground.
Page 210 4-24 Driving Your Vehicle 3. Shift the transmission to N (Neutral). 4. Turn fog lamps and all accessories off. 5. To prevent the battery from draining while the vehicle is being towed, remove the 2 amp IGN SW fuse from the instrument panel fuse block and store it in a safe location.
Page 211 Dolly Towing (Front-Wheel-Drive Vehicles) To tow the vehicle from the front with the rear wheels on the ground, do the following: 1. Put the front wheels on a dolly. 2. Move the shift lever to P (Park). 3. Set the parking brake. 4.
Page 212: Towing A Trailer
4-26 Driving Your Vehicle Towing a Trailer CAUTION The driver can lose control when pulling a trailer if the correct equipment is not used or the vehicle is not driven properly. For example, if the trailer is too heavy, the brakes may not work well — or even at all.
Page 213 Pulling A Trailer Here are some important points: • There are many different laws, including speed limit restrictions, having to do with trailering. Make sure the rig will be legal, not only where you live but also where you will be driving.
Page 214 4-28 Driving Your Vehicle Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total gross weight of the vehicle. The Gross Vehicle Weight (GVW) includes the curb weight of the vehicle, any cargo carried in it, and the people who will be riding in the vehicle.
Page 215 The weight at the rear axle could be 850 lbs (386 kg) X 1.5 = 1,275 lbs (578 kg). Since the rear axle already weighs 2,700 lbs (1 225 kg), adding 1,275 lbs (578 kg) brings the total to 3,975 lbs (1 803 kg). This is very close to, but within the limit for RGAWR as well.
Page 216 4-30 Driving Your Vehicle • Will any holes be made in the body of the vehicle when the trailer hitch is installed? If so, be sure to seal the holes when the hitch is removed. If they are not sealed, deadly carbon monoxide (CO) from the engine’s exhaust can get into the vehicle.
Page 217 CAUTION (Continued) • Adjust the Climate Control system to a setting that brings in only outside air and set the fan speed to the highest setting. See Climate Control System in the Index. For more information about carbon monoxide, see Engine Exhaust on page 2-26.
Page 218 4-32 Driving Your Vehicle Turn Signals When Towing a Trailer The arrows on the instrument panel ﬂash whenever signaling a turn or lane change. Properly hooked up, the trailer lamps also ﬂash, telling other drivers the vehicle is turning, changing lanes or stopping. When towing a trailer, the arrows on the instrument panel ﬂash for turns even if the bulbs on the trailer...
Page 219 Parking on Hills CAUTION Parking the vehicle on a hill with the trailer attached can be dangerous. If something goes wrong, the rig could start to move. People can be injured, and both the vehicle and the trailer can be damaged.
Page 220 4-34 Driving Your Vehicle ✍ NOTES...
Page 221: Service And Appearance Care
Service and Appearance Care Service Service ...5-3 Accessories and Modiﬁcations ...5-3 California Proposition 65 Warning ...5-3 California Perchlorate Materials Requirements ...5-4 Doing Your Own Service Work ...5-4 Adding Equipment to the Outside of the Vehicle ...5-4 Fuel Fuel ...5-5 Gasoline Octane ...5-5 Gasoline Speciﬁcations ...5-5...
Page 222: Vehicle Identiﬁcation
Service and Appearance Care Tires Tires ...5-38 Tire Sidewall Labeling ...5-39 Tire Terminology and Deﬁnitions ...5-41 ...5-43 Inﬂation - Tire Pressure Tire Pressure Monitor System ...5-45 Tire Pressure Monitor Operation ...5-46 Tire Inspection and Rotation ...5-50 When It Is Time for New Tires ...5-51 Buying New Tires...
Page 223: Service
Service For service and parts needs, visit your dealer/retailer. You will receive genuine Saturn parts and Saturn-trained and supported service people. Genuine Saturn parts have one of these marks. Service and Appearance Care Accessories and Modiﬁcations When non-dealer/non-retailer accessories are added to the vehicle,...
Page 224: California Perchlorate Materials Requirements
Service and Appearance Care California Perchlorate Materials Requirements Certain types of automotive applications, such as airbag initiators, seat belt pretensioners, and lithium batteries contained in remote keyless transmitters, may contain perchlorate materials. Special handling may be necessary. For additional information, see www.dtsc.ca.gov/hazardouswaste/ perchlorate.
Page 225: Fuel
Fuel Use of the recommended fuel is an important part of the proper maintenance of this vehicle. To help keep the engine clean and maintain optimum vehicle performance, we recommend the use of gasoline advertised as TOP TIER Detergent Gasoline. Gasoline Octane Use regular unleaded gasoline with a posted octane rating of 87 or...
Page 226: Fuels In Foreign Countries
Service and Appearance Care For customers who do not use TOP TIER Detergent Gasoline regularly, one bottle of GM Fuel System Treatment PLUS, added to the fuel tank at every engine oil change, can help clean deposits from fuel injectors and intake valves. GM Fuel System Treatment PLUS is the only gasoline additive recommended by General Motors.
Page 227: Filling The Tank
Filling the Tank CAUTION Fuel vapor burns violently and a fuel ﬁre can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the pump island. Turn off the engine when you are refueling.
Page 228: Filling A Portable Fuel Container
Service and Appearance Care This would allow fuel to evaporate into the atmosphere. See Malfunction Indicator Lamp on page 3-30. CAUTION If a ﬁre starts while you are refueling, do not remove the nozzle. Shut off the ﬂow of fuel by shutting off the pump or by notifying the station attendant.
Page 229: Checking Things Under The Hood
Checking Things Under the Hood CAUTION An electric fan under the hood can start up and injure you even when the engine is not running. Keep hands, clothing, and tools away from any underhood electric fan. CAUTION Things that burn can get on hot engine parts and start a ﬁre.
Page 230: Engine Compartment Overview
5-10 Service and Appearance Care Engine Compartment Overview When you open the hood, you will see the following:...
Page 231: Engine Oil
A. See Engine Air Cleaner/Filter on page 5-15. B. Remote Negative (−) Terminal. See Jump Starting on page 5-28. C. Engine Oil Fill Cap. See Engine Oil on page 5-11. D. Engine Coolant Surge Tank. See Cooling System on page 5-17. E.
Page 232 5-12 Service and Appearance Care When to Add Engine Oil If the oil is below the MIN (minimum) mark, add at least one quart/liter of the recommended oil. This section explains what kind of oil to use. For engine oil crankcase capacity, see Capacities and Speciﬁcations on page 5-81.
Page 233 • GM6094M Use only an oil that meets GM Standard GM6094M. • SAE 5W-30 SAE 5W-30 is best for the vehicle. These numbers on an oil container show its viscosity, or thickness. Do not use other viscosity oils such as SAE 20W-50.
Page 234: Engine Oil Life System
5-14 Service and Appearance Care Engine Oil Life System When to Change Engine Oil This vehicle has a computer system that indicates when to change the engine oil and ﬁlter. This is based on engine revolutions and engine temperature, and not on mileage. Based on driving conditions, the mileage at which an oil change is indicated can vary considerably.
Page 235: Engine Air Cleaner/Filter
What to Do with Used Oil Used engine oil contains certain elements that can be unhealthy for your skin and could even cause cancer. Do not let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner.
Page 236 5-16 Service and Appearance Care How to Inspect the Engine Air Cleaner/Filter To inspect the air cleaner/ﬁlter remove the ﬁlter from the vehicle and lightly shake the ﬁlter to release loose dust and dirt. If the ﬁlter remains caked with dirt, a new ﬁlter is required.
Page 237: Automatic Transmission Fluid
Automatic Transmission Fluid It is not necessary to check the transmission ﬂuid level. A transaxle ﬂuid leak is the only reason for ﬂuid loss. If a leak occurs, take the vehicle to your dealer/retailer service department and have it repaired as soon as possible. Change the ﬂuid and ﬁlter at the intervals listed in Additional Required Services on page 6-5, and...
Page 238 5-18 Service and Appearance Care CAUTION Heater and radiator hoses, and other engine parts, can be very hot. Do not touch them. If you do, you can be burned. Do not run the engine if there is a leak. If you run the engine, it could lose all coolant.
Page 239 CAUTION Adding only plain water to the cooling system can be dangerous. Plain water, or some other liquid such as alcohol, can boil before the proper coolant mixture will. The vehicle’s coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but you would not get the overheat warning.
Page 240: Engine Coolant
5-20 Service and Appearance Care 3. Fill the coolant surge tank with ® the proper DEX-COOL coolant mixture, to between the MIN and MAX lines. 4. With the coolant surge tank pressure cap off, start the engine and let it run until you can feel the upper radiator hose getting hot.
Page 241 • Protect against rust and corrosion. • Help keep the proper engine temperature. • Let the warning lights and gages work as they should. Notice: Using coolant other than ® DEX-COOL can cause premature engine, heater core, or radiator corrosion. In addition, the engine coolant may require changing sooner, at the ﬁrst maintenance service after each 30,000 miles...
Page 242: Coolant Surge Tank Pressure Cap
5-22 Service and Appearance Care Checking Coolant The surge tank is located on the driver side of the engine compartment. See Engine Compartment Overview on page 5-10 for more information on location. CAUTION Turning the surge tank pressure cap when the engine and radiator are hot can allow steam and scalding liquids to blow out and burn you badly.
Page 243: Engine Overheating
Engine Overheating There is a coolant temperature warning light on your vehicle’s instrument panel. See Engine Coolant Temperature Warning Light on page 3-29. If Steam Is Coming From Your Engine CAUTION Steam from an overheated engine can burn you badly, even if you just open the hood.
Page 244: Windshield Washer Fluid
5-24 Service and Appearance Care If you no longer have the overheat warning, you can drive. Just to be safe, drive slower for about ten minutes. If the warning does not come back on, you can drive normally. If the warning continues and you have not stopped, pull over, stop, and park your vehicle right away.
Page 245: Brakes
Brakes Brake Fluid The brake master cylinder reservoir is ﬁlled with either DOT-3 or DOT-4 brake ﬂuid as indicated on the reservoir cap. See Engine Compartment Overview on page 5-10 for the location of the reservoir. There are only two reasons why the brake ﬂuid level in the reservoir might go down: •...
Page 246 5-26 Service and Appearance Care Always clean the brake ﬂuid reservoir cap and the area around the cap before removing it. This helps keep dirt from entering the reservoir. CAUTION With the wrong kind of ﬂuid in the brake hydraulic system, the brakes might not work well.
Page 247: Battery
Brake Adjustment Every time the brakes are applied, with or without the vehicle moving, the brakes adjust for wear. Replacing Brake System Parts The braking system on a vehicle is complex. Its many parts have to be of top quality and work well together if the vehicle is to have really good braking.
Page 248: Jump Starting
5-28 Service and Appearance Care Extended Storage: For extended storage of the vehicle, remove the 12-volt battery black, negative (−) cable from the battery or use a battery trickle charger. This helps maintain the charge of the battery over an extended period of time. Remember to reconnect the battery when ready to drive the vehicle.
Page 249 Notice: Ignoring these steps could result in costly damage to the vehicle that would not be covered by the warranty. Trying to start the vehicle by pushing or pulling it will not work, and it could damage the vehicle. 1. Check the other vehicle. It must have a 12-volt battery with a negative ground system.
Page 250 5-30 Service and Appearance Care A. Remote Negative (-) B. Remote Positive (+)
Page 251 5. The remote negative (−) terminal is a stud on the driver side near the underhood fuse block. CAUTION Using a match near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a ﬂashlight if you need more light.
Page 252 5-32 Service and Appearance Care 9. Now connect the black negative (−) cable to the negative (−) terminal of the good battery. Use a remote negative (−) terminal if the vehicle has one. Do not let the other end touch anything until the next step.
Page 253: Headlamp Aiming
Headlamp Aiming The headlamp aiming system has been preset at the factory. If the vehicle is damaged in an accident, the aim of the headlamps may be affected and adjustment may be necessary. It is recommended that a dealer/retailer adjust the headlamps. To re-aim the headlamps yourself, use the following procedure.
Page 254 5-34 Service and Appearance Care 4. At the wall measure from the ground upward (A) to the recorded distance from Step 3 and mark it. 5. Draw or tape a horizontal line (B) on the wall the width of the vehicle at the height of the mark in Step 4.
Page 255: Bulb Replacement
Bulb Replacement For the proper type of replacement bulbs, see Replacement Bulbs on page 5-37. For any bulb changing procedure not listed in this section, contact your dealer/retailer. Halogen Bulbs CAUTION Halogen bulbs have pressurized gas inside and can burst if you drop or scratch the bulb.
Page 256: Front Turn Signal And Parking Lamps
5-36 Service and Appearance Care Front Turn Signal and Parking Lamps To replace a front turn signal or parking lamp bulb: 1. Follow Steps 1 through 6 under Headlamps on page 5-35 to access the front turn signal or parking lamp. 2.
Page 257: License Plate Lamp
1. Open the liftgate. 2. Remove the two screws holding in the taillamp assembly. 3. Slide the taillamp assembly rearward and away from the vehicle. 4. Turn the bulb socket being replaced counterclockwise to disconnect it. 5. Pull the bulb out of the bulb socket.
Page 258: Windshield Wiper Blade Replacement
5-38 Service and Appearance Care Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear and cracking. See Scheduled Maintenance on page 6-3 for more information. Replacement blades come in different types and are removed in different ways. For proper type and length, see Maintenance Replacement Parts on page 6-12.
Page 259: Tire Sidewall Labeling
CAUTION (Continued) • Underinﬂated tires pose the same danger as overloaded tires. The resulting accident could cause serious injury. Check all tires frequently to maintain the recommended pressure. Tire pressure should be checked when your vehicle’s tires are cold. See Inﬂation - Tire Pressure on page 5-43.
Page 260 5-40 Service and Appearance Care The TIN is molded onto both sides of the tire, although only one side may have the date of manufacture. (E) Tire Ply Material The type of cord and number of plies in the sidewall and under the tread.
Page 261: Tire Terminology And Deﬁnitions
Tire Terminology and Deﬁnitions Air Pressure The amount of air inside the tire pressing outward on each square inch of the tire. Air pressure is expressed in pounds per square inch (psi) or kilopascal (kPa). Accessory Weight This means the combined weight of optional accessories.
Page 262 5-42 Service and Appearance Care Intended Outboard Sidewall The side of an asymmetrical tire, that must always face outward when mounted on a vehicle. Kilopascal (kPa) The metric unit for air pressure. Light Truck (LT-Metric) Tire tire used on light duty trucks and some multipurpose passenger vehicles.
Page 263: Inﬂation - Tire Pressure
Traction The friction between the tire and the road surface. The amount of grip provided. Tread The portion of a tire that comes into contact with the road. Treadwear Indicators Narrow bands, sometimes called wear bars, that show across the tread of a tire when only 1/16 inch (1.6 mm) of tread remains.
Page 264 5-44 Service and Appearance Care This label shows your vehicle’s original equipment tires and the correct inﬂation pressures for your tires when they are cold. The recommended cold tire inﬂation pressure, shown on the label, is the minimum amount of air pressure needed to support your vehicle’s maximum load carrying capacity.
Page 265: Tire Pressure Monitor System
Tire Pressure Monitor System The Tire Pressure Monitor System (TPMS) uses radio and sensor technology to check tire pressure levels. The TPMS sensors monitor the air pressure in your vehicle’s tires and transmit tire pressure readings to a receiver located in the vehicle. Each tire, including the spare (if provided), should be checked monthly when cold and inﬂated to the...
Page 266: Tire Pressure Monitor Operation
5-46 Service and Appearance Care Federal Communications Commission (FCC) and Industry and Science Canada The Tire Pressure Monitor System (TPMS) operates on a radio frequency and complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
Page 267 At the same time a message to check the pressure in a speciﬁc tire appears on the Driver Information Center (DIC) display. The low tire pressure warning light and the DIC warning message come on at each ignition cycle until the tires are inﬂated to the correct inﬂation pressure.
Page 268 5-48 Service and Appearance Care TPMS Malfunction Light and Message The TPMS will not function properly if one or more of the TPMS sensors are missing or inoperable. When the system detects a malfunction, the low tire warning light ﬂashes for about one minute and then stays on for the remainder of the ignition cycle.
Page 269 You have two minutes to match each tire and wheel position. If it takes longer than two minutes to match any tire and wheel position, the matching process stops and you need to start over. The TPMS matching process is outlined below: 1.
Page 270: Tire Inspection And Rotation
5-50 Service and Appearance Care Tire Inspection and Rotation We recommend that you regularly inspect the vehicle’s tires, including the spare tire, for signs of wear or damage. See When It Is Time for New Tires on page 5-51 for more information.
Page 271: When It Is Time For New Tires
When It Is Time for New Tires Various factors, such as maintenance, temperatures, driving speeds, vehicle loading, and road conditions inﬂuence when you need new tires. One way to tell when it is time for new tires is to check the treadwear indicators, which will appear when the tires have only 1/16 inch (1.6 mm) or less of tread remaining.
Page 272 5-52 Service and Appearance Care GM’s exclusive TPC Spec system considers over a dozen critical speciﬁcations that impact the overall performance of your vehicle, including brake system performance, ride and handling, traction control, and tire pressure monitoring performance. GM’s TPC Spec number is molded onto the tire’s sidewall near the tire size.
Page 273: Different Size Tires And Wheels
You may increase the chance that you will crash and suffer serious injury. Only use Saturn speciﬁc wheel and tire systems developed for your vehicle, and have them properly installed by a Saturn certiﬁed technician.
Page 274: Uniform Tire Quality Grading
5-54 Service and Appearance Care Uniform Tire Quality Grading Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A The following information relates to the system developed by the United States National Highway Traffic Safety Administration (NHTSA), which grades tires by...
Page 275: Wheel Alignment And Tire Balance
Temperature – A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a speciﬁed indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life,...
Page 276 If you need to replace any of your wheels, wheel bolts, or wheel nuts, replace them only with new Saturn original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, and wheel nuts for your vehicle.
Page 277: Tire Chains
This could lead to a crash. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new Saturn original equipment wheel nuts. Notice: Improperly tightened wheel nuts can lead to brake pulsation and rotor damage.
Page 278: If A Tire Goes Flat
5-58 Service and Appearance Care If a Tire Goes Flat This vehicle has a tire sealant and compressor kit. See Tire Sealant and Compressor Kit on page 5-59. There is no spare tire, no tire changing equipment, and no place to store a tire.
Page 279: Tire Sealant And Compressor Kit
Tire Sealant and Compressor Kit CAUTION Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains Carbon Monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death.
Page 280 5-60 Service and Appearance Care If the tire has been separated from the wheel, has damaged sidewalls, or has a large puncture, the tire is too severely damaged for the tire sealant and compressor kit to be effective. See Roadside Assistance Program on page 7-5.
Page 281 Using the Tire Sealant and Compressor Kit to Temporarily Seal and Inﬂate a Punctured Tire When using the tire sealant and compressor kit during cold temperatures, warm the kit in a heated environment for 5 minutes. This will help to inﬂate the tire faster. Service and Appearance Care Always do a safety check ﬁrst.
Page 282 5-62 Service and Appearance Care 8. Press the on/off (D) button to turn the tire sealant and compressor kit on. The compressor will inject sealant and air into the tire. The pressure gage (E) will initially show a high pressure while the compressor pushes the sealant into the tire.
Page 283 14. Replace the sealant/air hose (F), and the power plug (C) back in their original location. 15. If the ﬂat tire was able to inﬂate to the recommended inﬂation pressure, remove the maximum speed label from the sealant canister (B) and place it in a highly visible location.
Page 284 5-64 Service and Appearance Care Using the Tire Sealant and Compressor Kit without Sealant to Inﬂate a Tire (Not Punctured) To use the air compressor to inﬂate a tire with air only and not sealant: Always do a safety check ﬁrst. See If a Tire Goes Flat on page 5-58.
Page 285 12. Press the on/off button (D) to turn the tire sealant and compressor kit off. Be careful while handling the tire sealant and compressor kit as it could be warm after usage. 13. Unplug the power plug (C) from the accessory power outlet in the vehicle.
Page 286: Tire Sealant And Compressor Kit Storage
5-66 Service and Appearance Care Tire Sealant and Compressor Kit Storage To access the tire sealant and compressor kit: 1. Open the liftgate. See Liftgate on page 2-8. 2. Push in the levers and lift the load ﬂoor up. 3. Turn the retainer counterclockwise and remove the tire sealant and compressor kit.
Page 287 When cleaning the vehicle’s interior, only use cleaners speciﬁcally designed for the surfaces being cleaned. Permanent damage may result from using cleaners on surfaces for which they were not intended. Use glass cleaner only on glass. Remove any accidental over-spray from other surfaces immediately.
Page 288: Fabric/Carpet
5-68 Service and Appearance Care Fabric/Carpet Use a vacuum cleaner with a soft brush attachment frequently to remove dust and loose dirt. A canister vacuum with a beater bar in the nozzle may only be used on ﬂoor carpet and carpeted ﬂoor mats.
Page 289: Instrument Panel, Vinyl, And Other Plastic Surfaces
Instrument Panel, Vinyl, and Other Plastic Surfaces A soft cloth dampened with water may be used to remove dust. If a more thorough cleaning is necessary, a clean soft cloth dampened with a mild soap solution can be used to gently remove dust and dirt.
Page 290: Cleaning Exterior Lamps/Lenses
5-70 Service and Appearance Care Do not wash the vehicle in direct sunlight. Use a car washing soap. Do not use cleaning agents that are petroleum based or that contain acid or abrasives, as they can damage the paint, metal or plastic on the vehicle.
Page 291: Windshield And Wiper Blades
Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, chemicals from industrial chimneys, etc., can damage the vehicle’s ﬁnish if they remain on painted surfaces. Wash the vehicle as soon as possible.
Page 292: Aluminum Wheels
5-72 Service and Appearance Care Aluminum Wheels Notice: Chrome wheels and other chrome trim may be damaged if the vehicle is not washed after driving on roads that have been sprayed with magnesium, calcium or sodium chloride. These chlorides are used on roads for conditions such as ice and dust.
Page 293: Sheet Metal Damage
Sheet Metal Damage If the vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to parts repaired or replaced to restore corrosion protection. Original manufacturer replacement parts will provide the corrosion protection while maintaining the vehicle warranty.
Page 294: Vehicle Identiﬁcation Vehicle Identiﬁcation Number (Vin)
5-74 Service and Appearance Care Vehicle Identiﬁcation Vehicle Identiﬁcation Number (VIN) This is the legal identiﬁer for the vehicle. It appears on a plate in the front corner of the instrument panel, on the driver side. It can be seen through the windshield from outside the vehicle.
Page 295: Add-On Electrical Equipment
Add-On Electrical Equipment Notice: Do not add anything electrical to the vehicle unless you check with your dealer/retailer ﬁrst. Some electrical equipment can damage the vehicle and the damage would not be covered by the vehicle’s warranty. Some add-on electrical equipment can keep other components from working as they should.
Page 296: Instrument Panel Fuse Block
5-76 Service and Appearance Care Instrument Panel Fuse Block The instrument panel fuse block is located on the passenger side of the lower console. Pull the latch of the fuse box cover straight back to access the fuses. Fuses Usage PWR SEAT Power Seat PASS Passenger Side...
Page 297: Underhood Fuse Block
Fuses Usage Inside Rearview ISRVM Mirror Instrument Panel CLUSTER Cluster AIR BAG Airbag System Outside Rearview OSRVM Mirror Key Capture KEY CAP Solenoid Steering Wheel WHL S/W Switch Front Driver Door F/DR LCK Lock Accessory Power APO2 Outlet 2 Body Control BCM (VB3) Module (BCM) (VB3)
Page 298 5-78 Service and Appearance Care Fuses Usage FAN MAIN Cooling Fan Main REAR/WPR Rear Wiper Motor Cooling Fan FAN AUX Auxiliary Fuses Usage Engine Control Module/Transmission Control ECM/TCM/ Module/Serial Data SGCM Gateway Communication Module Fuses Usage Engine Control Module ENG-3 Engine 3 ENG-2 Engine 2...
Page 299 Fuses Usage Ampliﬁer HORN Horn Antilock Brake System Module Instrument Panel I/P BEC Bussed Electrical Center FRT FOG Front Fog Lamps Instrument Panel I/P BEC Bussed Electrical Center Daytime Running Light T/LAMP RT Right Turn and Parking Lamps T/LAMP LT Left Turn and Parking Lamps TRLR Trailer Parking...
Page 300 5-80 Service and Appearance Care Fuses Usage HYBRID Hybrid Pumps PUMPS HILL HOLD Hill Hold Valves VLVS Auxiliary Transmission TRANSPUMP Pump Relays Usage HILL HOLD Hill Hold Valves VLVS Auxiliary Transmission TRANSPUMP Pump...
Page 301: Capacities And Speciﬁcations
Capacities and Speciﬁcations Application Air Conditioning Refrigerant R134a Cooling System Engine Oil with Filter Fuel Tank Transmission (Bottom Pan Removal) Wheel Nut Torque All capacities are approximate. When adding, be sure to ﬁll to the approximate level, as recommended in this manual.
Page 302 5-82 Service and Appearance Care ✍ NOTES...
Page 303: Maintenance Requirements
Maintenance Schedule Maintenance Schedule Introduction ...6-1 Maintenance Requirements ...6-1 Your Vehicle and the Environment ...6-2 Using the Maintenance Schedule ...6-2 Scheduled Maintenance ...6-3 Additional Required Services ...6-5 Maintenance Footnotes ...6-7 Owner Checks and Services ...6-8 ...6-8 At Each Fuel Fill At Least Once a Month ...6-9 At Least Once a Year...
Page 304: Maintenance Schedule
Maintenance Schedule Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep the vehicle in good working condition, but also helps the environment. All recommended maintenance is important. Improper vehicle maintenance can even affect the quality of the air we breathe.
Page 305: Scheduled Maintenance
When you go to your dealer/retailer for service, trained and supported service technicians will perform the work using genuine parts. To purchase service information, see Service Publications Ordering Information on page 7-13. Owner Checks and Services on page 6-8 tells what should be checked, when to check it, and what can easily be done to help keep the vehicle in good condition.
Page 306 Maintenance Schedule Maintenance I — Use Maintenance I if the Change Engine Oil light displays within 10 months since the vehicle was purchased or Maintenance II was performed. Change engine oil and ﬁlter. See Engine Oil on page 5-11. Reset oil life system.
Page 307: Additional Required Services
Inspect wiper blades. See footnote (d). Inspect restraint system components. See footnote (e). Lubricate body components. See footnote (f). Replace passenger compartment air ﬁlter. See footnote (k). Inspect throttle system. See footnote (g). Additional Required Services The following services should be performed at the ﬁrst maintenance service (I or II) after the indicated miles (kilometers) shown for each item.
Page 308 Maintenance Schedule Service and Miles (Kilometers) Change automatic transmission ﬂuid (normal service). Replace spark plugs. An Emission Control Service. Engine cooling system service (or every ﬁve years, whichever occurs ﬁrst). An Emission Control Service. See footnote (i). Inspect engine accessory drive belt. An Emission Control Service.
Page 309: Maintenance Footnotes
Maintenance Footnotes (a) Visually inspect brake lines and hoses for proper hook-up, binding, leaks, cracks, chaﬁng, etc. Inspect disc brake pads for wear and rotors for surface condition. Inspect other brake parts, including calipers, parking brake, etc. (b) Visually inspect front and rear suspension and steering system for damaged, loose, or missing parts or signs of wear.
Page 310: Owner Checks And Services
Maintenance Schedule See Engine Coolant on page 5-20 for what to use. Inspect hoses. Clean radiator, condenser, pressure cap, and ﬁller neck. Pressure test the cooling system and pressure cap. (j) A ﬂuid loss in any vehicle system could indicate a problem. Have the system inspected and repaired and the ﬂuid level checked.
Page 311: At Least Once A Month
Windshield Washer Fluid Level Check Check the windshield washer ﬂuid level in the windshield washer ﬂuid reservoir and add the proper ﬂuid if necessary. At Least Once a Month Tire Inspection and Inﬂation Check Inspect the vehicle’s tires for wear and make sure they are inﬂated to the correct pressures.
Page 312 6-10 Maintenance Schedule shift lever moves out of P (Park), contact your dealer/retailer for service. Ignition Transmission Lock Check While parked, and with the parking brake set, try to turn the ignition to LOCK/OFF in each shift lever position. • The ignition should turn to LOCK/OFF only when the shift lever is in P (Park).
Page 313: Recommended Fluids And Lubricants
-VI Automatic Transmission Fluid. Multi-Purpose Lubricant, Superlube (GM Part No. U.S. 12346241, in Canada 10953474). Lubriplate Lubricant Aerosol (Saturn Part No. 21038869 or GM Part No. U.S. 12346293, in Canada 992723) or lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Page 314: Maintenance Replacement Parts
Passenger Side – 16 in (40.0 cm) Rear – 12.0 in (30.0 cm) Fluid/Lubricant Lubriplate Lubricant Aerosol (Saturn Part No. 21038869 or GM Part No. U.S. 12346293, in Canada 992723) or lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Page 315: Engine Drive Belt Routing
Maintenance Schedule 6-13 Engine Drive Belt Routing The engine drive belt on this hybrid vehicle is under a higher tension than the engine drive belt on a non-hybrid vehicle and requires a special tool to service. See your dealer/retailer for service.
Page 316: Maintenance Record
6-14 Maintenance Schedule Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. See Maintenance Requirements on page 6-1. Any additional information from Owner Checks and Services on page 6-8 can be added on the following record pages. You should retain all maintenance receipts.
Page 317 Maintenance Schedule 6-15 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 318 6-16 Maintenance Schedule Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 319: Customer Assistance Information
Saturn vehicle, for total customer satisfaction. We call this the Saturn Difference. Normally, any concerns with the sales transaction or the operation of the vehicle are resolved by the retailer’s sales or service...
Page 320: Customer Assistance And Information
Saturn vehicle. However, if you continue to remain unsatisﬁed after following the procedure outlined in Steps One and Two, Saturn and its retailers offer the additional assistance of a neutral party through our voluntary participation in...
Page 321 This program is available in all 50 states and the District of Columbia. Eligibility is limited by vehicle age, mileage and other factors. Saturn Corporation reserves the right to change eligibility limitations and/or discontinue its participation in this program. Customer Assistance Information...
Page 322: Online Owner Center
— all in one convenient place. • Digital owner manual, warranty information, and more • Online service and maintenance records • Find Saturn retailers for service nationwide • Exclusive privileges and offers • Recall notices for your speciﬁc vehicle ® •...
Page 323: Customer Assistance Offices
Customer Assistance Offices Saturn encourages customers to call the toll-free number for assistance. If a customer wishes to write to Saturn, the letter should be addressed to: Saturn Customer Assistance Center P.O. Box 33173 Detroit, MI 48232-5173 1-800-553-6000 1-800-833-6000 (For Text...
Page 324 Roadside Assistance is not a part of the New Vehicle Limited Warranty. Saturn and General Motors of Canada Limited reserve the right to make any changes or discontinue the Roadside Assistance program at any time without notiﬁcation.
Page 325: Scheduling Service Appointments
• Mounting, dismounting or changing of snow tires, chains, or other traction devices. • Towing or services for vehicles driven on a non-public road or highway. Services Speciﬁc to Canadian Purchased Vehicles • Fuel delivery: Reimbursement is approximately $5 Canadian. Diesel fuel delivery may be restricted.
Page 326: Courtesy Transportation
Transportation Options Warranty service can generally be completed while you wait. However, if you are unable to wait, Saturn helps to minimize your inconvenience by providing several transportation options. Depending on the circumstances, your retailer can offer you one of the...
Page 327: Collision Damage Repair
All Courtesy Transportation arrangements will be administered by appropriate retailer personnel. Saturn reserves the right to unilaterally modify, change or discontinue Courtesy Transportation Customer Assistance Information at any time and to resolve all questions of claim eligibility pursuant...
Page 328 7-10 Customer Assistance Information may not perform properly in subsequent collisions. Aftermarket parts are not covered by your GM New Vehicle Limited Warranty, and any vehicle failure related to such parts are not covered by that warranty. Repair Facility We recommend that you choose a collision repair facility that meets your needs before you ever need collision repairs.
Page 329 • If you need roadside assistance, call GM Roadside Assistance. See Roadside Assistance Program on page 7-5 for more information. • If your vehicle cannot be driven, know where the towing service will be taking it. Get a card from the tow truck operator or write down the driver’s name, the service’s name, and the phone number.
Page 330: Reporting Safety Defects To The United States Government
National Highway Traffic Safety Administration (NHTSA), in addition to notifying Saturn Corporation. If NHTSA receives similar complaints, it could open an investigation, and if it ﬁnds that...
Page 331: Reporting Safety Defects To Saturn
Customer Assistance Information Service Publications Ordering Information Service Manuals A variety of publications are available to you. Saturn service manuals are written for trained technicians, and in some cases, specialized tools and equipment are necessary to complete certain repairs. However, the manuals are...
Page 332: Vehicle Data Recording And Privacy
Most bulletins apply to conditions affecting a small number of vehicles. Your Saturn retailer or a qualiﬁed technician may have to determine if a speciﬁc bulletin applies to your vehicle. To order Saturn bulletins,...
Page 333: Onstar
EDR. Customer Assistance Information Saturn will not access this data or share it with others except: with the consent of the vehicle owner or, if the vehicle is leased, with the consent of the lessee;...
Page 334 7-16 Customer Assistance Information ✍ NOTES...
Page 335 About Driving Your Vehicle ... ii Accessories and Modiﬁcations ... 5-3 Accessory Power Outlets ... 3-16 Adding Equipment to Your Airbag-Equipped Vehicle ... 1-55 Additives, Fuel ... 5-5 Add-On Electrical Equipment ... 5-75 Air Cleaner/Filter, Engine ... 5-15 Air Conditioning ... 3-17 Airbag Passenger Status Indicator ...
Page 336 INDEX Audio System(s) ... 3-58 Auto Stop Mode ... 3-35 Automatic Climate Control System ... 3-17 Automatic Door Lock ... 2-7 Automatic Door Unlock ... 2-7 Automatic Headlamp System ... 3-13 Automatic Transmission Fluid ... 5-17 Operation ... 2-20 Battery ... 5-27 Electric Power Management ...
Page 337 Procedure ... 7-1 INDEX Customer Assistance Information (cont.) GM Mobility Reimbursement Program ... 7-5 Reporting Safety Defects to Saturn ... 7-13 Reporting Safety Defects to the Canadian Government ... 7-12 Reporting Safety Defects to the United States Government ... 7-12 Roadside Assistance Program ...
Page 338 INDEX Door Automatic Door Lock ... 2-7 Automatic Door Unlock ... 2-7 Delayed Locking ... 2-6 Locks ... 2-6 Power Door Locks ... 2-6 Rear Door Security Locks ... 2-7 Driver Seat Height Adjuster ... 1-4 Driver Behavior ... 4-2 Driver Information Center (DIC) ...
Page 339 Filter Engine Air Cleaner ... 5-15 Finish Damage ... 5-73 Fixed Mast Antenna ... 3-84 Flashers, Hazard Warning ... 3-5 Flash-to-Pass ... 3-7 Flat Tire ... 5-58 Fluid Automatic Transmission ... 5-17 Windshield Washer ... 5-24 Folding Rear Seat ... 1-9 Folding Seatback, Passenger ...
Page 340 INDEX Ignition Positions ... 2-14 Infants and Young Children, Restraints ... 1-25 Inﬂation - Tire Pressure ... 5-43 Inﬂator Kit, Tire ... 5-59 Instrument Panel Brightness ... 3-14 Cluster ... 3-23 Overview ... 3-4 Intermediate Voltage Devices and Wiring ... 5-74 Jump Starting ...
Page 341 Lower Anchors and Tethers for Children ... 1-31 Lumbar Manual Controls ... 1-5 Maintenance Schedule Additional Required Services ... 6-5 At Each Fuel Fill ... 6-8 At Least Once a Month ... 6-9 At Least Once a Year ... 6-9 Introduction ...
Page 342 System, Operation ... 2-4 Replacement Bulbs ... 5-37 Replacement Parts, Maintenance ... 6-12 Reporting Safety Defects Canadian Government ... 7-12 Saturn ... 7-13 United States Government ... 7-12 Restraint System Check Checking the Restraint Systems ... 1-56 Replacing Restraint System Parts After a Crash ...
Page 343 Routing, Engine Drive Belt ... 6-13 Running the Vehicle While Parked ... 2-26 Safety Belt Reminders ... 3-24 Safety Belts Care of ... 5-69 How to Wear Safety Belts Properly ... 1-13 Lap-Shoulder Belt ... 1-17 Safety Belt Extender ... 1-22 Safety Belt Use During Pregnancy ...
Page 344 i-10 INDEX Storage Areas (cont.) Cupholders ... 2-37 Driver Storage Compartment ... 2-38 Glove Box ... 2-37 Rear Seat Armrest ... 2-38 Sunglasses Storage Compartment ... 2-37 Storing the Tire Sealant and Compressor Kit ... 5-66 Stuck in Sand, Mud, Ice, or Snow ...
Page 345 Uniform Tire Quality Grading .. 5-54 Universal Home Remote System ... 2-32 Operation ... 2-33 Vehicle Control ... 4-4 Design ... 4-2 Loading ... 4-18 Running While Parked ... 2-26 Symbols ... iii Vehicle Customization, DIC ... 3-49 Vehicle Data Recording and Privacy ...
Page 346 i-12 INDEX XM Radio Messages ... 3-71 XM™ Satellite Radio Antenna System ... 3-84 Your Driving, the Road and Your Vehicle ... 4-1 Your Vehicle and the Environment ... 6-2...

Saturn 2009 VUE Green Line Hybrid Owner's Manual

Table of Contents

Seats and

Seats and Restraint System

Head Restraints

Front Seats Manual Seats

Rear Seats Split Folding Rear Seat

Safety Belts

Child Restraints Older Children

Airbag System

How Does an Airbag Restrain

Restraint System Check Checking the Restraint Systems

Features and Windows

Features and Controls

Doors and Locks Door Locks

Theft-Deterrent Systems

Starting and Operating Your Vehicle New Vehicle Break-In

Onstar System

Universal Home Remote System

Storage Areas Glove Box

Warning Lights, Gages, and Indicators

Instrument Panel

Driver Information Center (DIC)

Instrument Panel Overview

Instrument Panel Brightness

Climate Controls Automatic Climate Control System

Warning Lights, Gages, and Indicators

Center (DIC)

Driver Information Center (DIC)

Driving Your Vehicle 4-1 Driving Your Vehicle Your Driving, the

Driving Your Vehicle

Your Driving, the Road

Loading the Vehicle

Towing

Service and

Service and Appearance Care

Checking Things under the Hood

Windshield Wiper Blade Replacement

Appearance Care Interior Cleaning

Vehicle Identiﬁcation Vehicle Identiﬁcation Number (VIN)

Electrical System Intermediate Voltage Devices and Wiring

Capacities and Speciﬁcations

Quick Links

Chapters

Related Manuals for Saturn 2009 VUE Green Line Hybrid

Summary of Contents for Saturn 2009 VUE Green Line Hybrid
