- Page 1 RFID USER GUIDE (Alien C1 UHF) PN 9001147B...
- Page 2 SATO America, Inc. 10350A Nations Ford Road Charlotte, NC 28273 Main Phone: (704) 644.1650 Technical Support Hotline: (704) 644.1660 Technical Support Fax: (704) 644.1661 E-Mail: satosales@satoamerica.com techsupport@satoamerica.com www.satoamerica.com...
- Page 3 All “e” series, plug-in interfaces may be used with the RFID print engine, including Ethernet and 802.11b wireless interfaces. The following process details the steps involved in writing to the EPC tag: SATO RFID User Guide PN 9001147B Page 1...
- Page 4 Transmission Output Control Communications Protocol Source Voltage Demand Current Electrostatic Voltage Resistance SATO RFID User Guide 85.47 x 53.98 x 7.62 mm (sealed in a shield case) 16 x 118 x 1.6 mm ALR-9930 (module by Alien Technology) 902-928 MHz...
- Page 5 Vcc - +5V Frame Ground NOTE: If backfeed is set to occur “After Print”, the RFID tag will be in the improper location relative to the antenna and the tag will not be programmed. SATO RFID User Guide DESCRIPTION PN 9001147B DIRECTION...
- Page 6 The following LCD menus are specific to RFID operation: RFID MENUS DISPLAY SATO RFID User Guide DESCRIPTION Sets the number of times the printer will attempt to re-encode and re-print data following a Tag Error. The printer will enter the error mode when the entered number of retries has been met.
- Page 7 Click on the menu scroll-down arrow and select the RFID printer driver relative to the printer of use. Make other screen selections as deemed necessary and then click on the NEXT button until the Label Dimensions screen appaers. The Label Dimensions screen is shown below. SATO RFID User Guide PN 9001147B Page 5...
- Page 8 Label Gallery screen will appear with a blank label present. Click on DATA of the upper task bar and then select the RF DATA option. The following RF TAG screen will appear. SATO RFID User Guide PN 9001147B Page 6...
- Page 9 EPC encoding translators may also be used by selecting that relative box on the screen. When checked, select the type of EPC encoding you wish to use and then fill in the data values which show up as shown on the following screen. SATO RFID User Guide PN 9001147B Page 7...
- Page 10 Click on the OK button when complete and the label will show up on the next screen with the RFID inlay outlined around the label. Refer to the screen below. SATO RFID User Guide PN 9001147B Page 8...
- Page 11 Populate the label with label fields. Refer to the Label Galley Manual’s Help Files for assistance as required. Once complete, click on FILE on the upper task bar, select the Print option and then enter the desired print quantity. The Print screen is displayed below. SATO RFID User Guide PN 9001147B Page 9...
- Page 12 FORMAT RETURN STATUS LIST EXAMPLE NOTES SATO RFID User Guide Writes EPC code in RFID supply that supports EPC code. <ESC>IP0n.nnn n = Data to be written (16 bytes fixed for 64 bit inlays) or (24 bytes fixed for 96 bit inlays).
