PARTS LIST
Specifications
Power source
: AC 120 V 60 Hz
Power consumption
: 6.0 A
Motor revolution
: 31,200 r.p.m.
Vacuum
: 17,500 Pa
Dimensions
: 13 - 19/32" x 9 - 17/32" x 10 - 1/4"
L X W X H
Net weight
: 5 lbs. 8 ozs. ( 2.5 Kg )
Attachment
: Suction hose, Floor tool,
Wiring Diagram
Motor
Stator
Carbon brush
Rotor
Stator
Vacuum Cleaner
(345 x 242 x 260 mm)
Rotary bend, Connection pipe,
Crevice tool, Upholstery brush
Switch
Black
Black
Yellow
SC-240
PRODUCT CODE NO.
A C
REFERENCE NO.
- 1 -
FILE No.
(U.S.A.)
1 - 326 730 01 ( L )
PL6510288-00
