5 2 0 0 A N S I L U M E N S
PLC-XF30N/NL
XGA Digital Multimedia Projector
INCREDIBLY BRIGHT 5200 ANSI LUMENS
A pair of high-output 200 watt UHP lamps delivers an incredible
5200 ANSI lumens of brightness.
OUTSTANDING CONTRAST RATIO – 700:1
By employing a 10-bit digital gamma correction circuit ,
excessive whites in bright images and overwhelming blacks in
dark images are effectively suppressed.
CROSSTALK / GHOSTING PREVENTION
To eliminate the problem of ghosting on images, Sanyo's new
Crosstalk Canceling technology reduces signal interference
between the drive circuits on the LCD panels, while Line/Dot
inversion reduces signal interference between pixels.
INTELLIGENT DIGITAL SHARPNESS CONTROL
This high-performance image processing technology analyzes
the incoming signal and controls the sharpness of picture data
only, while text and other elements that are already sharp are
left unprocessed.
POWER LENS SHIFT
The power lens shift feature allows for greater placement
flexibility and easy alignment of images with virtually no
geometric distortion when twin-stacking projectors.
HDTV COMPATIBLE
The PLC-XF30N/NL is High Definition Television compatible,
accepting the 1080i, 1035i, 720p, 575p, 575i, 480p and 480i
HDTV resolution standards.
DIGITAL KEYSTONE CORRECTION
SANYO's digital keystone correction feature compensates for
angled projector placement by digitally altering the pixels to
produce undistorted images.
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax 818.717.2719
www.sanyolcd.com
Type
Short Fixed
Short Zoom
Part No.
LNS-W01
Zoom
No
Yes (power)
Throw Ratio
1.2:1
1.35 – 1.8:1
F Stop
2.5
Length
9.4"
Weight
12.8 lbs.
*Model PLC-XF30N comes equipped with Standard Zoom Lens 2 (LNS-S02). Model PLC-XF30NL does not include a lens.
T R U E X G A
l
L e n s
S p e c i f i c a t i o n s
On-Axis
Short Fixed
LNS-W02
LNS-W03
No
Yes (power)
0.8:1
2.5 – 2.9
2.6
8.34"
9.25"
5.5 lbs.
6.6 lbs
D I G I T A L M U L T I M E D I A P R O J E C T O R
l
S p e c i f i c a t i o n s
Resolution
Brightness
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Lens
Image Size (diagonal)
Aspect Ratio
Throw Distance
Zoom/Focus
Throw Ratio
Zoom Ratio
Power Lens Shift
Digital Keystone Correction
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
Voltage
BTU Rating
dB Rating
Power Consumption
Dimensions (WxHxD)
Net Weight
User Maintenance
Detachable Input Panels
POA-MD11DVI
POA-MD12VD1
POA-MD03VD2
Fixed Input/Output Panel
Included Accessories
Optional Accessories
Warranty
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
Standard
Standard
Zoom 1
Zoom 2*
LNS-S01
LNS-S02
Yes (power)
1.8 – 2.9:1
2.0 – 2.6:1
2.6 – 3.5
2.0 – 2.3
7.0"
8.2"
3.7 lbs.
4.2 lbs.
XGA (1024 x 768)
5200 ANSI Lumens
90% (corner to corner)
1.8" TFT polysilicon type x 3
2,359,296 (786,432 x 3)
700:1 (full on/off)
Standard Zoom 2 - F2.0-2.3 (PLC-XF30N only)
(Model PLC-XF30NL shipped without lens)
40"-600"
6.5' – 82.2'
Powered
2.0 – 2.6:1
Up/Down Ratio 10:0 – 0:10
200W UHP x 2
H Sync: 15-120kHz, V Sync: 50-120Hz
230MHz
PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
UXGA, SXGA, XGA, SVGA, VGA, MAC
100-240V AC
17.3"x9.1"x23.9"
PLC-XF30N – 49.4 lbs.
PLC-XF30NL – 45.2 lbs. (w/o lens)
Clean air filters, replace lamp assembly
Digital Visual Interface (DVI) Left & Right Audio
(RCA x 2) Control (Min DIN 8-pin)
RGB & Component (5-BNC) Left & Right Audio
(RCA x 2) Control (Min DIN 8-pin)
Composite & Y/C (2-BNC) S-Video
Left & Right Audio (RCA x 2)
Serial in & Serial out (D-Sub 9 x 2) Audio out
(RCA x 2) USB Wired RC jack (Stereo mini);
Wired/Wireless I/R Remote Control w/Mouse Pad
and Laser Pointer AC power cord VGA and
DVI Cable Wired remote cable PS/2, Serial,
MAC Mouse Control Cables Dust cover
MAC/VGA and DVI/VGA Adapter Lens cover
Light Block Sheets Owner's manual
POA-MD08HD - HD-SDI Input panel
POA-MD09VD3 - Faroudja
POA-MD04VGA - VGA (D-Sub 15) Input panel
POA-LLB02 - Lamp and Ballast Kit for
100W UHP lamps
Three years parts and labor; 90 days lamp;
Quick Repair Program under warranty
Standard
Semi-Long
Zoom 3
Zoom
LNS-S03
LNS-M01
Yes (power)
Yes (power)
2.6 – 3.5:1
3.5 – 4.6:1
1.7 – 2.6
2.0 - 2.6
13.8"
6.9"
8.2 lbs.
4.2 lbs.
4:3
1:1.3
+/- 40
1877
45.0
550W
Input panel
TM
Long Fixed
Long Zoom
LNS-T01
LNS-T02
NO
Yes (power)
7.0:1
4.6 – 6.0:1
2.0
2.0 – 2.9
8.6"
9.6"
8.4 lbs.
6.8 lbs.
Issued 11/01
