This installation manual describes how to mount the projector to a wall using the setting plate (model POA-CH-EX06). This setting plate is only for use with Sanyo projectors mentioned below. ¡ PDG-DWL2500, PDG-DXL2000 and other related models. (For details on available models, please contact your nearest Sanyo dealer.)
This symbol indicates an action that must not be done. This symbol indicates an action that should be done. This setting plate is only for use with specifi ed Sanyo projector. Do not use for any other equipment or purpose.
Page 3
Such an environment may damage the projector. Install the setting plate in a place free from excessive dust and humidity to prevent the lens or optical components of the projector from becoming dirty. POA-CH-EX06(IJAH).indb 2 POA-CH-EX06(IJAH).indb 2 Safety Instructions CAUTION 10.9.8 11:21:13 AM...
(for securing projector and adjustment unit). . 5 M8 x 20 mm hexagon socket head cap bolt (for securing setting plate and wall plate) . . . 4 POA-CH-EX06(IJAH).indb 3 POA-CH-EX06(IJAH).indb 3 M5 x 10 mm hexagon socket head cap bolt (for securing cover plates) .
M12 could cause the setting plate to fall. (The wall plate must be secured in at least four places.) ¡ Sanyo takes no responsibility for any damages or injury caused by incorrect installation. 0.27 inch 0.65 inch (68 mm)
Attach the left and right cover plates to the setting plate using the two M5 x 10 mm hexagon socket head cap bolts included. (Secure temporar- ily so that the adjustment mentioned on page 7 can be carried out.) POA-CH-EX06(IJAH).indb 5 POA-CH-EX06(IJAH).indb 5 Wall plate...
Tighten the four bolts which were loosened to secure the projector to the setting plate. Attach the two bolts (for drop-prevention) to the setting plate. POA-CH-EX06(IJAH).indb 6 POA-CH-EX06(IJAH).indb 6 Installation Procedure Adjustment unit Projector...
(3 mm). Adjustment knob * “A” marks appear on the setting plate to indicate the locations of the bolts and adjustment knob. POA-CH-EX06(IJAH).indb 7 POA-CH-EX06(IJAH).indb 7 Adjustment located inside the setting plate using a hexagon wrench (6 located on the left side of the setting plate to adjust the horizontal rotation.
Page 9
(3 mm). Screw * “C” marks appear on the setting plate to indicate the locations of the screws and adjustment knob. POA-CH-EX06(IJAH).indb 8 POA-CH-EX06(IJAH).indb 8 Installation Procedure located on the left top side of the setting plate to adjust the vertical tilt.
Secure the end of the wire at the bottom of the setting plate with the screw (M4 x 10) supplied with the setting plate as shown in the illustra- tion. POA-CH-EX06(IJAH).indb 9 POA-CH-EX06(IJAH).indb 9 Drop-prevention wire Screw (M4 x 10) 10.9.8 11:21:14 AM...
14.44" (36.7) 55" (4 : 3) 13.42" (34.1) show the distances from the projection surface. (If the projector screen is away from the wall, distances from the projector screen) POA-CH-EX06(IJAH).indb 10 POA-CH-EX06(IJAH).indb 10 6.85 inch (174 mm) 1.06 inch (27 mm)
POA-CH-EX06(IJAH).indb 11 POA-CH-EX06(IJAH).indb 11 Dimensions 18.23 (463) 13.51 (321) 1.06 (27) 6.45 (164) Center line of the projection surface Unit: inch (mm) 10.9.8 11:21:15 AM 10.9.8 11:21:15 AM...
