INSTRUCTION MANUAL

LCD TV
Before connecting, operating or adjusting this product, please read the manual completely.
Please keep this manual for future reference.
LCD-22XR9DA

Advertisement

loading

  Also See for Sanyo LCD-22XR9DA

  Summary of Contents for Sanyo LCD-22XR9DA

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL LCD TV Before connecting, operating or adjusting this product, please read the manual completely. Please keep this manual for future reference. LCD-22XR9DA...
  • Page 2: Important Information

    IMPORTANT INFORMATION If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: ! Using cabinets or stands recommended by the manufacturer of the television. ! Only using furniture that can safety support the television.
  • Page 3: Table Of Contents

    Table of Contents Important Safety Precautions...1 Important Notice...3 Preparations...4 Identification of Controls ...6 Connections...9 Basic Operations...12 Memorizing the Channels ...15 Channel and Program Selection...19 Picture Adjustment ...20 Sound Adjustment...21 System Setup ...23 Rating and Lock Setup ...24 Timer Setup...26 EPG Operation...28 Teletext &...
  • Page 4: Important Safety Precautions

    Important Safety Precautions Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD.
  • Page 5 Important Safety Precautions 15. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product.
  • Page 6: Important Notice

    Important Notice About Temperature About After-Image Cleaning and Maintenance Do not use in hot and cold rooms (locations) When the unit is used in rooms (locations) with low temperature, the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
  • Page 7: Preparations

    Preparations Using the Remote Control Use the remote control by pointing it towards the remote sensor window of the < set. Objects between the remote control and sensor window may prevent proper operation. Cautions regarding use of remote control Do not expose the remote control to shock. In addition, do not expose the remote <...
  • Page 8: Antenna Connection

    Preparations (continued) Antenna Connection INSTALL the unit in a room where direct light will not fall upon the screen. Total darkness or a reflection on the picture screen may cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing. Optimum reception of color requires a good signal and will generally mean that an outdoor antenna must be used.
  • Page 9: Identification Of Controls

    Identification of Controls Main Unit Remote Sensor Power Indicator 1. CH+/- Press these two buttons to directly change the TV channel. In OSD menu, press these buttons to choose the OSD items. 2. VOL+/- Press the VOL+ or VOL- button to directly increase or decrease the sound volume level; In OSD menu, press these buttons to adjust the value or setting of each item.
  • Page 10: Main Unit

    Identification of Controls Main Unit 1. HDMI interface 2. D-SUB input Connect to the D-SUB/AUDIO output jack on your computer. 3. S/PDIF digital audio out terminal (coaxial) Connect to the digital audio input of a digital audio component. 4. COMPONENT inputs Connect to the audio and component output jacks of a DVD player or Set-Top Box.
  • Page 11: Remote Control Unit

    Identification of Controls Remote Control Unit (Continued) POWER: Switches the TV power on or Standby. TV/Radio: Switches between TV and Radio mode. (DTV only) EPG: Displays the Electronic Program Guide (DTV only). FAV.LIST: Displays the favorite channel list. FAV+/ FAV–: Selects the favorite channel. 0 –...
  • Page 12: Connections

    Connections Cautions Before Connecting Carefully check the terminals for position and type before making any connections. The illustration of the external equipment may be different depending on your model. Loose connectors can result in image or color problems. Make sure that all connectors are securely inserted into their terminals.
  • Page 13: Connecting Component Video

    Connections (Continued) Connecting Component Video TV REAR To connect a device using component video: Connect the Component Video cable between the Y, Cb/Pb, Cr/Pr input jacks on the unit and Y, Cb/Pb, Cr/Pr output jacks on the device . Connect the Audio cable between the AUDIO input jacks on the unit and AUDIO output jacks on the device. To play component video from an external device: 1.
  • Page 14: Connecting An Hdmi Device

    Connections (Continued) Connecting an HDMI device How to connect a device using HDMI Connection: Connect the HDMI cable between the HDMI interface on the unit and HDMI output on the device. To play from the device using HDMI: 1. Turn on your TV, then press SOURCE button. The Input Source menu opens. 2.
  • Page 15: Basic Operations

    Basic Operations Main Menu Overview List of main menus to help you with operations PICTURE menu Picture Sound Time Option Picture Mode User Contrast Brightness Color Sharpness Tint Prev Page Next Page Select Move Menu TIME menu Picture Sound Time Option Clock 28/Sep /2008 15:30...
  • Page 16: Turning Off

    Basic Operations (Continued) Turning On/Off the Power Turning On Insert the power cord into the wall outlet. Press the Power Switch on the unit to power on. If the unit is in standby mode, press Power button on the unit or the remote control to turn on the unit, and you will be ready to use its features.
  • Page 17: Displaying The Information Banner

    Basic Operations (Continued) Selecting the Input Signal Source Press SOURCE button. Press 6 or 5 to select the input source. Options include: ! DTV — Watch the DTV signal. ! ATV — Watch the ATV signal. ! AV — Watch the signal from the AV input terminals. ! Component —...
  • Page 18: Memorizing The Channels

    Memorizing the Channels When you turn on the TV for the first time, you should perform an auto channel search to set up stations on your TV. Note: Be sure to select the proper input source (ATV/DTV) before operation. Auto Channel Search You should perform an auto channel search to search for all channels available and stores them in memory.
  • Page 19: Manual Fine Tuning

    Memorizing the Channels Manual Searching for ATV programs If desired analog programs cannot be searched by Auto Tuning, you can make use of ATV Manual Tuning to search programs manually. In Channel menu, press 6 item, then press4 or OK to access. Highlight Storage To item, press 3 position in which you want to store.
  • Page 20: Labeling Channels

    Memorizing the Channels Labeling Channels If required, you can give a name to the programs. Press MENU and the main menu screen displays. Press 3 to select Channel menu, press 6 Press 6 to select Programme Edit item, press 4 open the Programme Edit menu.
  • Page 21: Channel List Management

    Memorizing the Channels Channel List Management After auto search, a default channel list is created. You can make use of Programme Edit menu to select program, to skip unnecessary channels, to delete channels, to sort programs, and to create a favorite channel list. To skip unnecessary channels After auto search, you can skip unnecessary channels so that only the channels you want to watch can be selected by / CH .
  • Page 22: Channel And Program Selection

    Channel and Program Selection Please note: your new TV is capable of receiving both radio and TV broadcasts. And for TV reception, your new TV is capable of receiving both traditional analog channels and digital channels. When watching digital TV program and you want to listen to radio program, simply press TV/Radio button to switch.
  • Page 23: Picture Adjustment

    Picture Adjustment Customizing the Picture Press MENU and the main menu screen displays. Press 3 to select Picture menu, press 6 Within the menu, press 5 and press 5 to navigate through the options or adjust an option. Press MENU to return to previous menu. Press EXIT to exit the menu screen directly. Picture Sound Time...
  • Page 24: Sound Adjustment

    Sound Adjustment Adjusting the Volume Using the volume buttons (VOL+ and VOL – ) Press the VOL + or VOL- to increase or decrease the volume. Using the Mute Press the MUTE button to temporarily turn off all sound. To restore the sound, press the MUTE button again. Adjusting the Sound Press MENU and the main menu screen displays.
  • Page 25: Nicam Broadcast Selection

    Sound Adjustment Stereo/Bilingual Selection You can quickly select sound multiplex mode by using the STEREO button on the remote control. NICAM Broadcast Selection This enables the selection of the reception mode when receiving a NICAM signal. To let you enjoy NICAM broadcasting, this TV set receives NICAM system stereo, bilingual, and monaural broadcasts.
  • Page 26: System Setup

    System Setup System Setup You may change system settings such as Hearing impaired, SPDIF , Audio Preference, etc. by making use of Option menu. Press MENU and the main menu screen displays. Press 3 to select Option menu, press 6 Within the menu, press 5 or adjust an option.
  • Page 27: Rating And Lock Setup

    Rating and Lock Setup Password Setup The Password setup sub-menu is used to set a new system password or to change an existing system password. By default, the system password is 0000 and you may change it. To access Parental Guidance, to lock or unlock channels, to view locked channels, etc., the system password is required.
  • Page 28 Rating and Lock Setup Parental Guidance Setup (DTV only) Parental Guidance blocks programs according to their classification so that children can not view certain programs. Navigate to the Lock menu and input the correct password to access. Press 5 to highlight the Parental Guidance item. Use3 to select your desired rating.
  • Page 29: Timer Setup

    Timer Setup Time Zone Selection To obtain local time, you should first set local time zone, and it depends on your local station whether has broadcast time zone information. Press MENU and the main menu screen displays. Press 3 to select Time menu, press 6 Press 5 to select Time Zone item, and then press 3 select the appropriate one.
  • Page 30: Sleep Timer Setup

    Timer Setup (Continued) Off Timer Setup With Off Timer function On, the TV will automatically turn off at the preset time. Navigate to the Time menu, press 6 Press 5 to select Off Time item, press 4 the submenu. Now the Activate item will be highlighted automatically, press to select On .
  • Page 31: Epg Operation

    EPG Operation The Electronic Programme Guide (EPG) makes it possible for users to see details about the programme they are watching, other programmes and even a schedule of the next 7 days. The information available includes the number and name of the channel, the name and type of programme, the start and end time, and a summary.
  • Page 32: Teletext & Subtitle

    Teletext & Subtitle Teletext What Is Teletext? Your System receives Teletext signals broadcast by a TV network, and decodes them into graphical format for viewing. News, weather and sports information, stock exchange prices and programme previews are among the many services available.
  • Page 33: Screen Setup For D-Sub(Pc) Mode

    Screen Setup for D-SUB(PC) Mode Before adjusting the screen, make sure that you select the correct source (D-SUB). Screen Setup Press MENU and the main menu screen displays. Press 3 to select the Picture menu, press 6 Within the menu, press 5 or 6 item, then press 4 or OK to access.
  • Page 34: Hotel Mode Setup

    Hotel Mode Setup Hotel Mode Setup Press SOURCE button. The Input Source menu opens. Press number buttons: [ 1, 4, 7 ] to access the Hotel Mode screen. Within the menu, press 5 or adjust an option. Press OK to save the setting. Press MENU or EXIT to exit the menu screen directly.
  • Page 35: Troubleshooting

    Troubleshooting If, after reading these operating instructions, you have additional questions related to the use of your television, please call the services center in your local area. Before calling service, please check the symptoms and follow suggested solutions. Remote Control Problem Remote control does not operate Video and Audio...
  • Page 36 Troubleshooting General Problem One or some channels can’t be displayed Lost password Some items can’t be accessed TV cabinet creaks Some settings (such as volume setting, etc.)may not be memorized when the TV loses power or you press main Power Switch to turn off the TV.
  • Page 37: Specifications

    Specifications Type: LCD TV Display Size diagonal: 55cm Power Supply: AC220-240V 50/60Hz Power Consumption: Dimensions(mm): 526 (W) x 372 (H) x 180(D) Unit Weight(kg): TV System: Analogue: CCIR(PAL-B/G, NTSC(AV)) Digital: DVB-T(2K/8K OFDM) Note Design and specifications are subject to change without notice.
  • Page 38: Assembling The Stand And Removing The Stand Column

    Assembling the stand and removing the stand column(Option) If the stand is provided, please read these instructions thoroughly before attempting this installation. afety Precautions: 1.Please read these instructions thoroughly prior to attempting this installation. 2.Be sure to handle this product very carefully when attempting assembly. If you are unsure of your capability, or the use of tools necessary to complete this activity, refer to a professional installer or service personnel.
  • Page 39: Detaching The Stand

    Detaching the Stand 1.Place carefully the display on its front side with a soft cushion below, shake the stand forward or backward to adjust angle between the stand and the display, let the angle 2.Press the two tabs together and push inside properly, and pull out the stand at the same time to detach the stand.
  • Page 40 59440 Ver. 1.0...
