- Page 1 90120 90123 90122 90121 Bedienungsanleitung Deutsch 01-12 Instruction Manual English 13-24 Manuel d’utilisation Francais 25-36 Ersatzteile - Spare Parts - Pièces de rechange 37-40 Montage - Assembly - Assemblage 41-48 Garantie - Warranty - Garantie GM-Racing XXS Cars 4WD RTR...
-
Page 2: Saftey Precautions
INTRODUCTION Thank you for buying a XXS series car from GM-Racing. This introduction contains the basic instructions for the opera- tion of your new vehicle. The XXS-series cars are great for RC Beginners, but requires also a degree of craftsmanship and with drivers under 14 years, the guidance from the parents. -
Page 3: Guarantee Conditions
First screw the enclosed transmitter antenna into the mounting plate at the top of the transmitter. Place 8 AA batteries in the battery compartment of the transmitter and 4 fully charged AA-batteries in the battery holder of the vehicle. Pay attention to the polarity! Finally attach the battery retainer until it clicks into place. GM-Racing XXS Cars 4WD RTR... -
Page 4: Remote Control Transmitter
8. Charging socket: you may charge your rechargeable transmitter batteries by using a mitching charger 9. Antenna: Transmits signal to the model The remote control system of the XXS series is optimally adjusted by the factory. Nevertheless you should read the following chapter, maybe slight adjustments on the remote control should be necessary. -
Page 5: Let The Fun Begin
The contacts of the battery holder in the vehicle can fail by frequently changing the batteries. You recognize that in short breaks while driving. Slightly turn them into contact with a screwdriver so that they fi t correctly to the battery cells! GM-Racing XXS Cars 4WD RTR... -
Page 6: After The Ride
Set the steering dual rate to minimum fi rst. To set the desired steering level increase it again whilst dece- lerating your vehicle. WARNING: Do not turn too far, otherwise the steering hubs press against the front uprights which can damage the steering servo! AFTER THE RIDE GM-Racing XXS Cars 4WD RTR... - Page 7 (screw no. B, see parts list). 8. Secure the PCB mount with screws as shown 7. Cover the PCB mount after both battery mounts (screw no. J, see parts list). are installed. GM-Racing XXS Cars 4WD RTR...
- Page 8 3. The parts (servo saver and pin) are from 4. Use a needle nose pliers to fasten the pin part package 90120.6 and 90120.16 onto the servo saver. (see part list). GM-Racing XXS Cars 4WD RTR...
- Page 9 SERVICE AND REPAIR, SPARE PARTS For the XXS series all parts are available as spare parts. So if a part is defective or worn, you can identify these parts with the Exploded view, buy these parts and fi x the car yourself with the help of the assembly instruction (pages 42 - 48).
-
Page 10: Troubleshooting
Check, lube if necessary SPECIFICATIONS Length: 160 - 167 mm Width: 121 - 130 mm Height: 72 - 75 mm Wheelbase: 102 mm Ground clearance: 15 mm Motor: RC 131 Radio system: GM-Racing XG-2 (27Mhz AM) GM-Racing XXS Cars 4WD RTR... -
Page 11: Eg Declaration Of Conformity
EG DECLARATION OF CONFORMITY: We hereby declare that the following product: Main PCB plate XXS series order.-nr. 90120.28 confi rms with the essential protective requirements as laid down in the directive for harmonising the statuatory directives of the member states concerning electro-magnetic interference 2004/108/EC. - Page 12 CONTENT SPARE PARTS BAGS 90120.13 90120.14 90120.15 90120.22 GM-Racing XXS Cars 4WD RTR...
- Page 13 CONTENT SPARE PARTS BAGS 90120.17 90120.18 90120.16 90120.19 GM-Racing XXS Cars 4WD RTR...
- Page 14 90120.14 90120.15 Getriebegehäuse, Rammer Chassis, Servohalterung Halterung Akku - PCB-Einheit Bumpers, Gear Box Chassis, Servo Retainer Battery Compartment - PCB Plate Boîter de transmission, jupe de Châssis, support servo Support d‘accu - unité PCB protection GM-Racing XXS Cars 4WD RTR...
- Page 15 Pneu Monster Flash/Baja SC XXS collé 90120.28 90120.29 90120.30 Senderantenne XG-2 Schraubensatz XXS-Serie (140 Stück) Regler-Empfängereinheit XXS-Serie Transmitter Antenna XG-2 Screw Set XXS-Series Main PCB Plate XXS-Series Antenne d‘emetteur XG-2 Lot de visserie complet XXS-série Unité recepteur - variateur XXS-série GM-Racing XXS Cars 4WD RTR...
- Page 16 Quarzpaar Kanal 14 (27.095 Mhz) Quarzpaar Kanal 19 (27.145 Mhz) Quarzpaar Kanal 30 (27.255 Mhz) Crystals pair channel 14 Crystals pair channel 19 Crystals pair channel 30 Quartz paire canal 14 Quartz paire canal 19 Quartz paire canal 30 GM-Racing XXS Cars 4WD RTR...
- Page 17 Alu-Radträger hinten (2) Energy Set für Micro XXS-Serie Alum. Uprights/Hubs front Alum. Uprights rear Energy Set for Micro XXS series Alum. support de roues avant Alum. support de roues arrière Energy Set pour Micro XXS série GM-Racing XXS Cars 4WD RTR...
- Page 18 Schneidschraube mit Bund 2x6 mm Schneidschraube mit Bund 2.6x10 mm Flange Self Tapping screw 2x6 mm Flange Self Tapping screw 2.6x10 mm Vis à tête de ceinture 2x6 mm Vis à tête de centure 2.6x10 mm GM-Racing XXS Cars 4WD RTR...
- Page 19 Montage Stoßdämpfer - Lenkung Shock - Steering Assembly Assemblage amortisseurs - direction 90120.22 90120.22 90120.22 90120.9 90120.16 90120.16 90120.16 90120.3 90120.16 90120.5 90120.5 GM-Racing XXS Cars 4WD RTR...
- Page 20 (Leopard, Baja SC, Monster Flash XXS) 90120.19 90120.19 Vorne Front Avant 90120.19 Hinten Rear Arrière 90120.19 Karosseriehalter vorne/hinten - Body posts front/rear - Support carrosserie avant/arrière (Flash XXS) 90120.19 90120.19 Vorne Hinten Front Rear Avant Arrière GM-Racing XXS Cars 4WD RTR...
- Page 21 Included are 3 different pinions.Re-adjust the gear mesh between the spur gear and motor pinion when installing. Trois pignons différents joint le véhicule. Ajuster le jeu de flanc de dent entre pignons et le pignon après un changement. GM-Racing XXS Cars 4WD RTR...
- Page 22 Montage Lenkservo - Getriebe Steering Servo - Gearbox Assembly Assemblage servo de direction - transmission 90120.16 90120.16 90120.16 90120.8 90120.27 90120.13 90120.20 90120.13 90120.13 GM-Racing XXS Cars 4WD RTR...
- Page 23 Montage Heckfl ügel - Akkuhalterung Rear Wing - Battery Mount Assembly Assemblage aileron arrière - support d‘accu Heckflügelmontage - Rear Wing Assembly - Assemblage aileron arrière (Leopard, Flash XXS) 90120.19 90120.19 90120.19 90120.15 90120.15 90120.15 GM-Racing XXS Cars 4WD RTR...
- Page 24 90120.25 Monster Flash/Baja SC 90120.2 90120.20 90120.4 90120.19 Flash 90120 90120.19 90120.16 90120.22 90120.1 90120.21 90120.13 90120.22 90120.4 90120.22 Abweichungen vorbehalten. The images may vary from the actual parts. Les images peuvent varier des pièces réelles. GM-Racing XXS Cars 4WD RTR...
- Page 25 90120.17 90120.2 90120.18 90120.40 90120.22 90120.17 90120.45 90120.28 90120.15 90120.23 Flash 90120.24 Leopard 90120.7 90120.25 Monster Flash/Baja SC 90120.16 90120.16 90120.18 90120.18 90120.5 90120.15 90120.18 90120.23 Flash 90120.17 90120.24 Leopard 90120.25 Monster Flash/Baja SC 90120.17 GM-Racing XXS Cars 4WD RTR...
- Page 26 EN 300 220-1 2006 EN 300 220-2 V2.1.1 0678 Kirchheim, 03. Mai 2010 Hans Graupner, Geschäftsführer Hans Graupner, Managing Director Graupner GmbH & Co. KG Henriettenstraße 94-96 D-73230 Kirchheim/Teck Germany Tel: 07021/722-0 Fax: 07021/722-188 EMail: info@graupner.de GM-Racing XXS Cars 4WD RTR...
