MECHANISM REPLACEMENT
1. TRAY AND BASE MECHANISM PART
3. TRAY PART
MOLYKOTE
EM-50L
FLOIL OIL
G-474B
GREASE
CDF-409
GREASE
CDF-409
2. Base mechanism mounting PART
SILICON GREASE
KS-64
MOLYKOTE
EM-50L
4. BASE MECHANISM PART
FLOIL OIL
G-2000B
Do not remove the pick-up from base mechanism because of
adjustment difficulty.
- 3 -
MOLYKOTE
EM-50L
MOLYKOTE
EM-50L
MOLYKOTE
EM-50L
FLOIL OIL
G-2000B
