General purpose INPUT - OUTPUT shield for Arduino
Features
• For use with Arduino Due™, Arduino Uno™, Arduino Mega™
• 6 analog inputs
• 6 digital input
• 6 relay contact outputs
• Indicator leds for relay outputs and digital inputs
Specifi cations
• Analog inputs: 0..+5VDC
• Digital inputs: dry contact or open collector
• Relays: 12V
• Relay contacts: NO/NC 24VDC/1A max.
• Dimensions: 68 x 53mm / 2.67 x 2.08"
®
