Summary of Contents for Streacom DA2

  • Page 2: Table Of Contents

    Before we get into this super exciting user guide, we would just like to share a few words of appreciation ..In a market dominated by generic designs, marketing fads and RGB lighting, we are on a mission to create products that are not just different for the sake of it, but incorporate quality materials, superior finishing, and innovate at every level.
  • Page 3 Specification Form Factor: SFF Mini Tower Motherboard Support: Mini-ITX CPU Cooler Max Height: 145mm Water Cooling Support: 120 to 280mm PCI Support: Dual Slot, 330 x 150 x 50mm (LxWxH) Front Port: USB Type-C (3.0 ungradable to 3.1) Fan Support: 40 to 180mm, 92mm (Rear) Primary Material: Aluminium 6063 Drive Support: 3 x 3.5"...
  • Page 4 Remove the Side Panels The side panels are held in place with a simple rubber catch located on each edge (4 per side panel) that locks against the upper and lower frame of the case. To remove the side panel, pull the lower edge away from the case whilst applying pressure downwards to the upper edge.
  • Page 5 Motherboard Orientation (Optional) Not part of the standard installation procedure, but worth noting that the motherboard orientation can be flipped should that provide some specific advantage to your planned build. This is achieved by removing 4 screws which secure the back panel to the frame, rotating it 180 degrees, then replacing the 4 screws.
  • Page 6 Prepare the Motherboard Whilst it is possible to populate the motherboard with components once it’s fitted inside the case, it is generally easier to fit the CPU, RAM and cooler prior to this. Please refer to the user guides supplied with each component for exact installation procedure as the image below is just for reference. If using an AIO water cooler, we recommended installing it after all the other hardware has been fitted to the case.

  • Page 7: Introduction To The Universal Bracket

    Introduction to the Universal Bracket The universal bracket is a concept we originally introduced on the F12C and DB4 cases. The basic idea is that any and all hardware can be fitted to a universal bracket (hence the name universal) which can then be located anywhere along the frame of the case. This approach gives incredible flexibility to the component layout and improves hardware compatibility, but does require additional planning as the lack of dedicated bays can create component overlaps if not properly considered.

  • Page 8: Using The Universal Brackets

    Using the Universal Bracket The universal brackets are incredibly versatile and in principle, there is no wrong way to use them, the main limitation is the space available and how creative you want to get. Fan screws and washers are supplied but typically the hardware being mounted will be supplied with the correct screw thread and length. Below are just a few examples of what can be mounted using the vertical brackets, with the bottom row showing the horizontal bracket usage.

  • Page 9: Drive And Psu Brackets

    Drive and PSU Brackets In addition to the universal brackets, there are 2 dedicated brackets included, the PSU bracket which supports SFX/SFX-L, and the Drive bracket which can accommodate 3 x 3.5" or 6 x 2.5" drives and of course a mix of both (each 3.5" drives occupies the equivalent space of 2 x 2.5" drives). These additional brackets come fitted to the horizontal universal brackets using pre-defined mounting holes, but they can, of course, be re-arrange or mounted anywhere along the bracket and even fitted to the vertical bracket if needed.
  • Page 10 Fit the PSU and Drive Brackets Fit the PSU and drives to the brackets then install the completed assembly back into the case. Note that we recommend using a modular power supply as this will help with cable management in the confined space. Custom cables are also a great idea if possible to further improve the cable routing and airflow. Don’t forget to connect the IEC plug to the PSU and turn it on before you fit the assembly into the case as you will not have access to the socket or switch ones it has been fitted.
  • Page 11 Connect the Front I/O Power Switch / LED and USB Motherboard layout and pinout shown are for illustrative purposes only, these will vary between model and manufacturer, so please check the supplied user guide for exact connection details. When connecting the power LED, ensure correct polarity otherwise the light will not illuminate. The orientation/polarity of the power on/off switch (PSW) is not important and can be ignored, and the connectors are individual to allow for motherboards that use a 3 Pin layout.

  • Page 12: Installing A Pci Expansion Card

    Install a PCI Expansion Card The DA2 supports a full-length dual slot expansion card. To install a card, begin by removing the pre-installed PCI blanking plates which are secured to the PCI mount by a single screw for each plate. From the inside of the case remove the single screw which secures the PCI mount to the back of the case. The brackets and PCI mount will now be loose and can be removed from the case.

  • Page 13: Installing Vertical Bracket Hardware

    Install Vertical Bracket Hardware (AIO Cooler Example) The images on page 8 show some examples of hardware that can be fitted on the vertical brackets. For this specific example, will we demonstrate fitting a 240mm radiator, but the same principles apply to any other hardware being fitted.

  • Page 14: Cooling Strategy / Integrated Nets

    Cooling Strategy There is no single solution that is going to apply to every build, but there are general principles to consider when aiming for optimal cooling. Of course, a lot is going to depend on the CPU, GPU, cooling hardware and the application, so all these must also be factored in.
  • Page 15 Side Dust Net Vertical Frame The case also includes a side net which can be fitted depending on the airflow and cooling strategy you have implemented. We recommend only using the net if air is being drawn though it from the side panel as installing it will impede airflow and is not required or useful when air is being expelled from the case.
  • Page 16 Designed in Europe. Printed in China. Copyright © 2018. All Rights Reserved.
