- Page 1 Continental Automotive GmbH B&S S2 User Manual Fobik of the Continental Radio Frequency Transmitter Type S180227001 S180227002 S180227006 S180227007 S180227008 S180227010 S180227012...
- Page 2 Continental Automotive GmbH B&S S2 Functional description of Fobik for RF Test This document gives an overview of the different device operation modes and the RF transmissions performance of the key with specifical Software for Homologation. In this document the device is referenced as "key", even if the mechanical backup key might be separated from it.
-
Page 3: Button Functions
Continental Automotive GmbH B&S S2 2. Button functions The validation of the accurate frequency deviation and the measurement of the transmission function of the key are implemented basing on RF test software. The graphic below shows the functionality of the buttons. First Button Second comments... - Page 4 Continental Automotive GmbH B&S S2 3. Button Actions 3.1 Carrier Wave Measurement To perform radiated pattern or control the Level on GTEM you can pass the KeyFob with RF Test Software on CW emitting. Push Unlock button to start the CW Transmission Re-Push Unlock Button to stop the CW Transmission 30 kHz Att 0 dB...
- Page 5 Continental Automotive GmbH B&S S2 To perform Occuped BandWidth pattern you can pass the KeyFob with RF Test Software on Continuous ASK burst emitting (Real Data Manchester) Push Unlock button to start the DATA Transmission Re-Push Unlock Button to stop the DATA Transmission 30 kHz 3 MHz Att 10 dB...
