Sanyo AVM2425 Owner's Manual

Sanyo color tv owner's manual
Hide thumbs

Advertisement

Quick Links

WARRANTY
ONE-YEAR LIMITED WARRANTY
THIS LIMITED WARRANTY IS VALID ONLY ON SANYO TELEVISIONS PUR-
CHASED AND USED IN THE UNITED STATES OF AMERICA, CANADA, AND
PUERTO RICO, EXCLUDING THE UNITED STATES' OTHER TERRITORIES
AND PROTECTORATES. THIS LIMITED WARRANTY APPLIES ONLY TO THE
ORIGINAL PURCHASER, AND DOES NOT APPLY TO PRODUCTS USED FOR
INDUSTRIAL OR COMMERCIAL PURPOSES.
FOR ONE YEAR from the date of purchase, Sanyo Manufacturing Corporation
will replace any defective TV.
To insure proper warranty exchange, keep the original sales receipt for
evidence of purchase. Return the defective TV to the retailer along with the
receipt and the included accessories, such as the remote control. The
defective TV will be exchanged for the same model, or a replacement
model of equal value, if necessary. Replacement model will be contingent
on availability and at the sole discretion of Sanyo Manufacturing
Corporation.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
OBLIGATIONS
For one year from the date of purchase, Sanyo Manufacturing Corporation warrants this prod-
uct to be free from defects in material and workmanship under normal use and conditions.
Should replacement be necessary under this warranty for any reason due to manufacturing
defect or malfunction during the first year from date of original purchase, Sanyo Manufacturing
Corporation will provide a new TV via exchange at the retailer.
For customer assistance, whether during or out of the warranty
period, call toll free 1-800-877-5032.
Weekdays 7:30 AM – 7:00 PM Central Time
Saturday 7:30 AM – 4:00 PM Central Time
This warranty expresses specific contractual rights; retail purchasers may have additional
statutory rights which vary from state to state.
For your protection in the event of theft or loss of this product, please fill in the
information requested below and KEEP IN A SAFE PLACE FOR YOUR OWN
PERSONAL RECORDS.
Model No.__________________
Serial No.__________________
(Located on back of unit)
AS
Sanyo Manufacturing Corp.
3333 Sanyo Road, Forrest City, AR 72335

SPECIFICATIONS

PICTURE TUBE SIZE
(Measured Diagonally) . . . . . . 24-inches Screen
PICTURE RESOLUTION
Antenna Input . . . . . . . . . . . . . . . . . . 260 Lines
Video Input . . . . . . . . . . . . . . . . . . . . . . . 260 Lines
ANTENNA INPUT . . . . . . . UHF/VHF/CATV 75Ω
POWER REQUIREMENT . . . . . . . . 120VAC 60Hz
POWER . . . . . . . . . . . . . . . . . . . . . . . . 78 watts
HORIZONTAL DIM. (Width) . . . 24.4 in. (619mm)
VERTICAL DIM. (Height) . . . . 22.4 in. (570mm)
DEPTH DIM. (Thickness) . . . . 21.2 in. (538mm)
WEIGHT (Approx.) . . . . . . . . 60.6 lbs. (27.5 Kg.)
SOUND (1 Speaker) . . . . . . . . . . . . . Size: 8 cm
AMPLIFIER . . . . . . . . . . . . . Built-in with 1W/ch
AUDIO/VIDEO INPUT
JACKS (FRONT) . . . . . . . . . . . Video/Audio Input

BASIC SETUP AND CONNECTIONS

1.
Install batteries in remote control (2 AAA, not included).
2.
Connect signal. (See illustration below.)
3.
Plug in AC power cord.
4.
Press the POWER key to turn on TV.
5.
Follow on-screen instructions.
Cable Service
CATV FRANCHISE NOTE:
Cable companies, like public
utilities, are franchised by
local government authorities.
To receive cable programs,
even with equipment which is
Note: If you do not have a
capable of receiving cable
VCR, connect sig-
channels, the consumer must
nal directly to TV 75
subscribe to the cable com-
ohm terminal.
pany's service.
(EFFECTIVE: August 1, 2002)
Date of Purchase __________________
Purchase Price ____________________
Where Purchased__________________
CAUTION: FCC Regulations state that unauthorized
changes or modifications to this equip-
ment may void the user's authority to
operate it.
Care and Cleaning
1. Unplug the power cord
before cleaning the
television.
2. Clean the screen and cabinet
with a soft dry cloth.
Note: Never spray liquids on the screen because it
can
run
down
and
drip
onto
chassis. This may cause component failure
not covered under Warranty.
IMPORTANT NOTE:
Spent or discharged bat-
teries must be recycled or
disposed of properly in
compliance with all appli-
cable laws. For detailed
information, contact your
local County Solid Waste
Authority.
Satellite Receiver
RF Antenna
CATV IN
CH3
CH4
VIDEO
L-
AUDIO
-R
IN FROM
OUT TO TV
S-VIDEO
SAT.
VIDEO
L-
AUDIO
-R
VCR
IN
FROM ANT.
OUT
OUT TO TV
TV
UHF / VHF / CATV
75Ω
ENGLISH
Color TV
Owner's Manual
Welcome to the World of Sanyo
Thank you for purchasing a Sanyo Color Television. You made an excellent choice for Performance,
Styling, Reliability, and Value. This television is designed with easy-to-use on-screen set-up instructions and
operating features.
If you need assistance visit our Web site at
POSITIONING THE TV
Do not position the TV in a confined area. Allow space for
normal air circulation around electronic parts.
CHILD SAFETY
Sanyo is committed to making home entertainment safe
and enjoyable. Always use an appropriate table or stand
when positioning your TV. Use appropriate brackets,
braces, or straps to anchor your furniture in place. But
NEVER screw anything directly to the television.
Do not place televisions on dressers, shelves, desks,
carts, etc. where curious or excited children could pull,
push, or otherwise cause the unit to fall and cause
personal injury.
Never place toys or other items on top of the TV that
could pique children's curiosity causing them to climb
about the furniture.
Always use stands that are designed to support the size
and combined weight of your television and other
electronic devices.
This symbol on the nameplate means the product is Listed by Underwriters' Laboratories
Inc. It is designed and manufactured to meet rigid U.L. safety standards against risk of
fire, casualty, and electrical hazards.
Printed in U.S.A. SMC, August 2006
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING IN-
STRUCTIONS. BEFORE OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPER-
ATING INSTRUCTIONS. RETAIN THIS LITERATURE FOR REFERENCE. Follow all instructions...
Positioning the appliance
1. Do not place your appliance on an unstable cart, stand, shelf or
table. Serious injury to an individual, and damage to the appliance,
may result if it should fall. Your salesperson can
recommend approved carts and stands or shelf
and wall mounting instructions. An appliance and
cart combination should be moved with care.
the
Quick stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.
2. Slots and openings in the cabinet and in the back or bottom are pro-
vided for ventilation. To ensure reliable operation of the appliance and
to protect it from overheating, these openings must not be blocked or
covered. The openings should never be covered with a cloth or other
material, and the bottom openings should not be blocked by placing
the unit on a bed, sofa, rug, or other similar surface. This appliance
should never be placed near or over a radiator or heat register. This
appliance should not be placed in a built-in installation such as a book-
case unless proper ventilation is provided.
3. Do not expose the appliance to rain or use near water . . . for example,
near a bathtub, swimming pool, kitchen sink, in a wet basement, etc.
Hooking Up Outdoor Antenna
LIGHTNING PROTECTION FOR YOUR ANTENNA AND SET AS PER
NATIONAL ELECTRICAL CODE INSTRUCTIONS.
EXAMPLE OF ANTENNA GROUNDING ACCORDING TO
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ELECTRIC
SERVICE
EQUIPMENT
GROUND CLAMPS
GROUNDING CONDUCTORS
POWER SERVICE GROUNDING
(NEC SECTION 810-21)
ELECTRODE SYSTEM
NEC
(NEC ART 250, PART H)
- NATIONAL ELECTRICAL CODE
"Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article
820-40 of the NEC that provides guidelines for proper grounding and, in partic-
ular, specifies that the cable ground shall be connected to the grounding system
of the building, as close to the point of cable entry as practical."
4. If an outside antenna is connected to the receiver, be sure the
antenna system is grounded so as to provide some protection
against voltage surges and built up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA 70, provides information
with respect to proper grounding of the mast and supporting struc-
ture, grounding of the lead in wire to an antenna discharge unit,
size of grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements for the
grounding electrode.
An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where
it can fall into such power lines or circuits. When installing an outside
antenna system extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be fatal.
AS
Model No. :
AVM2425
www.sanyoctv.com
or call toll free 1-800-877-5032.
Part No.:
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTI-
TUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS
UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERAT-
ING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE
ACCOMPANYING THIS UNIT.
Plug in the power cord
5. This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of
power supply to your home, consult your product dealer or local
power company. This product is equipped with a polarized alternat-
ing current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your elec-
trician to replace your obsolete outlet. Do not defeat the safety pur-
pose of this polarized plug. Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can result in a
risk of fire or electric shock.
6. Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recepta-
cles, and the point where they exit from the product.
Cleaning
7. Before cleaning, unplug the unit from the wall outlet. Do not apply liquid
cleaners or aerosol cleaners directly to the unit. Use a dry cloth for
cleaning.
Service & Repair
8. Unplug the appliance from the wall outlet and refer servicing to qual-
ified service personnel under the following conditions:
A. If the power cord or plug is damaged or frayed.
ANTENNA
B. If liquid has been spilled into the appliance.
LEAD IN
WIRE
C. If the appliance has been exposed to rain or water.
GROUND
CLAMP
D. If the appliance has been dropped or the cabinet has been
damaged.
ANTENNA
DISCHARGE UNIT
E. If the appliance exhibits a distinct change in performance.
(NEC SECTION 810-20)
F. If the appliance does not operate normally by following the
operating instructions, adjust only those controls that are cov-
ered in the operating instructions. Improper adjustment of other
controls may result in damage and will often require extensive
work by a qualified technician to restore the appliance to
normal operation.
9. Upon completion of any service or repair, request the service tech-
nician's assurance that only Factory Authorized Replacement Parts
that have the same characteristics as the original parts were used,
and that routine safety checks have been performed to determine
that the appliance is in safe operating condition. Unauthorized sub-
stitutions may result in fire, electrical shock, or other hazards.
10. Never add accessories that have not been specifically designed for use
with this appliance as they may cause hazards.
11. For added protection during a lightning storm, or when the set is left
unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna. This will prevent damage to
the set due to lightning or power line surges.
12. Never push objects of any kind into this product through openings
as they may touch dangerous voltage points or short-out parts that
could result in a fire or electric shock. Never spill liquid of any kind
on the product.
AS
1JC6P1P0240– –

Advertisement

loading

  Related Manuals for Sanyo AVM2425

  Summary of Contents for Sanyo AVM2425

  • Page 1: Specifications

    Color TV Owner’s Manual Welcome to the World of Sanyo Thank you for purchasing a Sanyo Color Television. You made an excellent choice for Performance, Styling, Reliability, and Value. This television is designed with easy-to-use on-screen set-up instructions and operating features.
  • Page 2: Remote Control Operation

    Press MENU. Use the LM keys to highlight a feature. Use the – + keys to choose an option. Press MENU to exit. Items with submenus requires additional steps. Automatic Picture Adjustment Highlight Auto for normal viewing or Game for video game settings. Note: When you choose Game , the picture will automatically adjust to ideal game settings.
