Sanyo STB0810C1 Technical & Service Manual

26˝ through the wall air conditioners & heat pump
Hide thumbs Also See for STB0810C1:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
TECHNICAL & SERVICE MANUAL
STB0810C1
STB1010C1
STB1020C1
STB1220C1
SANYO 26˝ THROUGH THE WALL
AIR CONDITIONERS & HEAT PUMP
COOLING ONLY MODEL
Model No.
STB0810C1–S
STB1010C1–S
STB1020C1–S
STB1220C1–S
STB0811C1
STB1023C1
STB1123C1
STB0823H1
Product Code No.
1 851 005 66
1 851 005 65
1 851 005 68
1 851 005 67
STB0810C1
STB1010C1
STB1020C1
STB1220C1
FILE NO.
COOLING & ELECTRIC HEATING MODEL
Model No.
STB0811C1–S
STB1023C1–S
STB1123C1–S
HEAT PUMP MODEL
Model No.
STB0823H1–S
STB0811C1
STB1023C1
STB1123C1
STB0823H1
REFERENCE NO.
Destination: U.S.A.
Product Code No.
1 851 005 69
1 851 005 51
1 851 005 70
Product Code No.
1 851 005 52
SM
700487
