Page 1
5.2 Instructions for the installer 5.3 Cable replacement 5.4 Positioning TRANSLATION OF THE ORIGINAL INSTRUCTIONS We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com...
Instructions 1 Instructions • Do not allow children younger than 8 years old to come near the 1.1 General safety instructions appliance when in operation. • Cleaning and maintenance must Risk of personal injury not be carried out by unsupervised •...
Page 3
Instructions • DO NOT USE OR STORE • Switch off the burners or the FLAMMABLE MATERIALS NEAR electric hot plates of the cooktop, THE APPLIANCE. if installed above the appliance, during the pyrolytic process • NEVER USE AEROSOL CANS (where available). NEAR THE APPLIANCE WHILE IT IS IN OPERATION.
Page 4
Instructions • Do not use plastic kitchenware or Installation and maintenance containers when cooking food. • THIS APPLIANCE MUST NOT BE • Do not put sealed tins or INSTALLED IN BOATS OR containers in the oven. CARAVANS. • Remove all trays and racks which •...
Instructions • If the power supply cable is 1.3 Manufacturer liability damaged, contact technical The manufacturer declines all liability support immediately and they will for damage to persons or property replace it. caused by: • Before carrying out any work on •...
Instructions To dispose of the appliance: 1.7 How to read the user manual • Cut the power supply cable and remove This user manual uses the following reading it along with the plug. conventions: Power voltage Instructions Danger of electrocution General information on this user manual, on safety and final •...
Description 2 Description 2.1 General Description 1 Control panel 5 Fan 2 Oven light 6 Oven light 3 Seal Frame shelf 4 Door 2.2 Control panel 2 Display 1 Return knob Displays the current time, the cooking Using this knob you can return to the parameters, and all the appliance’s appliance’s previous menu item.
Description Cooling fan 3 Control knob The fan cools the appliance and comes into This knob allows you to turn the appliance operation during cooking. on and off and select the various available The fan causes a steady outflow of air from functions.
Description 2.4 Available accessories Rack Tray rack Useful for supporting containers with food during cooking. To be placed over the top of the oven tray; for cooking foods which may drip. Some models are not provided with all accessories. Deep tray The accessories intended to come into contact with food are made of materials that comply with the...
Page 10
3 Use High temperature inside the oven during use 3.1 Instructions Danger of fire or explosion Improper use • Do not spray any spray products near Risk of damage to surfaces the appliance. • Do not use or leave flammable materials •...
3.3 Using the accessories Racks and trays Racks and trays have to be inserted into the Tray rack side guides until they come to a complete The tray rack has to be inserted into the tray. stop. In this way fat can be collected separately The mechanical safety locks that prevent the from the food which is being cooked.
3.4 Using the oven Reactivating the display If the Eco-Light mode is active (see “Eco- First use Light” in the “Settings” section), the display will switch off 2 minutes after the appliance was last used. To reactivate the display when it is off: •...
Page 13
Favourites 3. Select YES if you wish to delete the favourites. Press the return knob from the clock screen to display the last preset programs or personal recipes used. Cooking functions Deleting favourites 1. On the clock screen, press the control If you wish to delete the favourites: knob to access the main menu.
Page 14
4. Turn the control knob to select the When the preheating stage is over a required function. buzzer will sound to indicate that the food can be placed inside the oven. 5. Press the control knob to confirm the selection. Interrupting a function For safety reasons, it is only To interrupt a cooking function:...
Page 15
List of cooking functions Grill The heat coming from the grill This low energy consumption element gives perfect grilling results function is particularly suitable for above all for thin and medium cooking on a single shelf. thickness meat and, in combination Ideal when cooking meat, fish and with the rotisserie (where fitted), vegetables.
Page 16
Fan grill Supercook The air produced by the fan softens The combination of fan assisted the strong heatwave generated by cooking and traditional cooking the grill, grilling perfectly even very allows different foods to be cooked thick foods. Perfect for large cuts of on several levels extremely quickly meat (e.g.
Page 17
Timer during a function Timed cooking Timed cooking is the function This function only activates the which allows a cooking operation buzzer, without stopping cooking. to be started and then ended after a specific length of time set by the 1.
Page 18
3. A few seconds after the required duration is set, the symbol stops Turn the control knob to add some flashing and timed cooking starts. minutes of cooking time. To extend the cooking time manually, press the control knob again. The appliance will resume its normal operation with the previously selected cooking settings.
Page 19
Programmed cooking 4. After a few seconds the symbols stop flashing. The appliance Programmed cooking is the waits for the delay start time. function that allows cooking to stop at a time set by the user, after which the oven will switch off automatically.
Page 20
7. At the end of the cooking cycle, “function Modifying the data set during ended” appears on the display and a programmed cooking buzzer sounds. After modifying the cooking 8. To turn off the buzzer, press or turn one of duration, the end of cooking time the two knobs or open the door.
3.5 Cooking advice Advice for cooking desserts/pastries and biscuits General advice • Use dark metal moulds: They help to • Use a fan assisted function to achieve absorb the heat better. consistent cooking at several levels. • The temperature and the cooking time •...
• To defrost meat, use the rack placed on 3.6 Special functions the second level and a tray on the first Some functions such as the oven level. In this way, the liquid from the off timer, defrost or cleaning defrosting food drains away from the functions are grouped in the food.
Page 23
List of special functions Sabbath mode Timer This function allows food to be This function sounds a buzzer when cooked in accordance with the the time set has elapsed. provisions of the Jewish religion day of rest. Defrost by weight This function defrosts foods on the ECO pyrolytic basis of the type and weight of the...
Page 24
Timer 4. If you leave the timer setting screen, the symbol will be displayed at the top 1. Turn the control knob to the right or left to select timer from the “special functions” left, indicating that a timer is active. menu.
Page 25
Defrost by weight 5. Turn the control knob to select the weight (in kilograms) of the food to defrost. 1. Place the food inside the appliance. 2. Turn the control knob to the right or left to select defrost by weight from the “special functions”...
Page 26
8. When finished, “function ended” Defrost by time appears on the display and a buzzer 1. Place the food inside the appliance. sounds. 2. Turn the control knob to the right or left to 9. To turn off the buzzer, press or turn one of select defrost by time from the “special the two knobs or open the door.
Page 27
5. Press the control knob to confirm the set Proving parameters. For successful proving, a container of water should be placed at the bottom of the oven cavity. 1. Position the dough to prove on the second level. 2. Turn the control knob to the right or left to select proving from the “special functions”...
Page 28
5. The appliance will begin preheating. 7. Press the control knob to make the required changes. 6. It will then proceed with the selected function. Unless otherwise set, the proving will have a maximum duration of 13 hours. The light inside the oven will remain off during the proving function.
Page 29
Food warming 4. Press the control knob to activate the function, or turn it to adjust the pre-set 1. Put the tray on the first shelf and place the temperature (from 40° to 80°). plates to be warmed on it. Do not stack plates too high.
Page 30
6. It will then proceed with the selected 7. Press the control knob to make the function. required changes. 8. When finished, “function ended” appears on the display and a buzzer While the function is in progress, it is sounds. possible to set a timer for a maximum of 4 hours (see “Timer during a function”), a 9.
Page 31
2. Press the control knob to confirm. Sabbath mode This function results in the appliance operating in a particular way: • Cooking can proceed indefinitely, it is not possible to set any cooking duration. • No preheating will be performed. 3.
3.7 Preset programs Starting a program 1. Turn the control knob to the right or left to This mode allows you to select a select the required type of dish from the previously stored program for “preset programs” menu. cooking food. The appliance will 2.
Page 33
4. Select the type of cooking (where It is now possible to start the selected possible, depending on the dish chosen) program, permanently modify the settings, and press the control knob to confirm. or use the delayed cooking function. 5. Turn the control knob to select the dish 6.
Page 34
7. A message will indicate when to place End of program the food in the oven and enable the start 1. When the preset program has finished, of cooking. the appliance will warn the user with buzzers and the symbol flashing. 8.
Page 35
Making permanent changes to a 5. Turn the control knob to the right or left to program select the weight to associate with the preset program. 1. Inside the selected preset program, turn the control knob to the left or right to select change from the menu of the selected dish.
Page 36
9. Turn the control knob to the right or left to 13. Pressing the control knob again will select the temperature to associate with return to point 2 of the change sequence. the preset program. You must press the return knob to save the preset program.
Page 37
Preset program table MEAT Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) rare Roast beef medium well done Pork loin medium Lamb well done Veal Pork spare ribs 10 + 6 Pork chops 14 + 4 Pork sausages 7 + 5 Bacon 4 + 2...
Page 38
FISH Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) Fresh fish Frozen fish Firm fish Delicate fish Snapper Flounder VEGETABLES Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) grilled 15 + 8 Mixed vegetables roasted roasted Potatoes frozen When you grill food, it is recommended to cook it on both sides referring to the times...
Page 39
DESSERTS/PASTRIES Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) Ring cake Biscuits Muffins Profiteroles Meringues Sponge cake Strudel Tarts Brioche bread Croissants BREAD Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) Leavened bread Focaccia Pan baked pizza...
Page 40
PIZZA Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) fresh Stone baked pizza (2) (3) frozen The stone must be placed on the bottom of the oven cavity. Frozen pizzas of different weights cooked on the stone do not require different cooking times.
Page 41
SLOW COOKING Weight Temp. Time Subcategory Cooking Level Function (Kg) (°C) (minutes) Veal rare Beef well done Pork Lamb The cooking times in the tables refer to the food indicated in the recipe. They are a guide only and may vary depending on personal taste.
3.8 Personal recipes Adding a recipe 1. Select add from the “personal recipes” This menu allows you to enter a menu. personal recipe with the parameters you wish to use. On first use, the appliance will only offer you to add a new recipe. After storing your personal recipes, they will be available in the relative menu.
Page 43
3. Press the control knob to confirm. 7. Press the control knob to confirm. 4. Turn the control knob to the right or left to 8. Turn the control knob to the right or left to select the weight to associate with the select the temperature to associate with recipe.
Page 44
12. Pressing the control knob again will 14. After entering the name of your recipe, return to point 2 of the change sequence. press the return knob to confirm or cancel You must press the return knob to save the information you have entered. Select the recipe.
Page 45
Using a personal recipe Cooking will start with the parameters that were previously set for the recipe. 1. Turn the control knob to the right or left to select a previously stored personal recipe from the “personal recipes” menu (in the example, the recipe test has been stored).
Page 46
Changing a personal recipe Deleting a personal recipe 1. Turn the control knob to the right or left to 1. Turn the control knob to the right or left to select a previously stored personal select a previously stored personal recipe from the “personal recipes”...
Page 47
5. Confirm the deletion. Select YES to Delayed cooking delete the recipe permanently. 1. Turn the control knob to the right or left to select a previously stored personal recipe from the “personal recipes” menu (in the example, the recipe test has been stored).
5. Turn the control knob to the right or left to 3.9 Settings select the cooking end time with the The product’s configuration can be control knob. The symbol flashes. set using this menu. 1. On the clock screen, press the control knob to access the main menu.
Page 49
Language Clock Sets the interface language from those Sets the time displayed. available. 1. Turn the control knob to the right or left to select language from the “settings” menu. 1. Turn the control knob right or left to set the hour.
Page 50
Control lock Demo mode (for showrooms only) Allows the appliance to automatically lock This mode allows the appliance to the controls after one minute of normal deactivate all heating elements, while operation without any intervention from the keeping the control panel active. user.
Page 51
Eco-Logic (on some models only) Sound This mode allows the appliance to limit the Whenever one of the knobs is pressed, the appliance beeps. This setting disables these power used. Suitable for simultaneous use sounds. with further home appliances. If this option is enabled, the symbol will appear on the display.
Page 52
Keep warm Eco-Light This mode allows the appliance to keep For greater energy savings, the light is cooked food warm (at low temperatures) turned off automatically one minute after the after cooking finishes with a cooking cycle start of cooking. for which a duration has been set (if this is not manually interrupted), without altering the taste and aromas obtained during...
Page 53
Digital clock Displays the time in digital format. If the Eco-Light function is set to OFF, the appliance is in standby and displays the current time dimly. If the Eco-Light function is set to OFF, the appliance consumes more energy when it is in standby mode.
Cleaning and maintenance 4 Cleaning and maintenance Ordinary daily cleaning Always use only specific products that do 4.1 Instructions not contain abrasives or chlorine-based acids. Improper use Pour the product onto a damp cloth and Risk of damage to surfaces wipe the surface, rinse thoroughly and dry with a soft cloth or a microfibre cloth.
Cleaning and maintenance 4.3 Cleaning the door 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure Removing the door that grooved sections A are resting completely in the slots. Lower the door For easier cleaning, it is recommended to and once it is in place remove the pins remove the door and to place it on a tea...
Page 56
Cleaning and maintenance Removing the internal glass panels 5. Remove the intermediate glass panels by lifting them upwards. For easier cleaning, the internal glass panels of the door can be removed. 1. Open the door. 2. Insert the locking hooks into the holes on the hinges to prevent the door from being closed by accident.
Cleaning and maintenance 4.4 Cleaning the oven Removing rack/tray support frames In order to keep your oven in the best Removing the rack/tray support frames possible condition, clean it regularly after enables the sides to be cleaned more letting it cool down. easily.
Cleaning and maintenance 4.5 Pyrolytic • Completely remove all accessories from inside the oven. The pyrolytic function consists of an • Remove the rack/tray support frames. automatic high-temperature • Remove the upper guard (if present). cleaning procedure which causes • Close the door. dirt to dissolve.
Page 59
Cleaning and maintenance 2. Turn the control knob to set the duration 3. Press the control knob. The symbol of the cleaning cycle from a minimum of will now be lit solidly. The display shows 2 hours to a maximum of 3 hours (except a warning to remove accessories from for the function, the duration of...
Page 60
Cleaning and maintenance Pyrolytic 2. At the end of the pyrolytic cycle, the door remains locked until the temperature 1. The display shows “cleaning in progress” inside the oven cavity returns to a safe and the remaining time to indicate that level.
Page 61
Cleaning and maintenance 4. Wait for the appliance to cool down and Setting of programmed pyrolytic cycle collect the residues deposited inside It is possible to program the pyrolytic cycle using a damp microfibre cloth. start time. 1. After selecting the pyrolytic cycle During the first pyrolytic cycle, duration, press the control knob.
Cleaning and maintenance 4.6 Extraordinary maintenance 4. Slide out and remove the light bulb. Replacing the internal light bulb Live parts Danger of electrocution • Unplug the appliance from the power supply. The oven cavity is fitted with a Do not touch the halogen lamp 40W light bulb.
Page 63
Cleaning and maintenance What to do if... The display shows “Error 4”: • The door lock has not properly attached The display is completely off: to the door. This might be because the • Check the mains power supply. door was accidentally opened during •...
Installation 5 Installation Fixed connection Fit the power line with an omnipolar circuit 5.1 Electrical connection breaker in compliance with installation regulations. Power voltage The circuit breaker should be located near Danger of electrocution the appliance and in an easily reachable position.
Installation 5.3 Cable replacement 5.4 Positioning Power voltage Heavy appliance Danger of electrocution Crushing hazard • Disconnect the mains power supply. • Position the appliance into the cabinet cutout with the help of a second person. 1. Unscrew the 4 screws on the rear casing. Pressure on the open door Risk of damage to the appliance •...
Page 66
Installation Fastening bushings 4 Secure the appliance to the piece of furniture using screws. 1. Mount the appliance into the recess. 2. Open the door completely. position of covers (front view) 3 Remove the bushing covers from the front of the oven. 5 Cover the bushings with the previously removed covers.
Page 67
Installation Front panel seal Appliance overall dimensions (mm) When installing under a worktop, the seal provided must be glued to the back of the front panel to prevent water or other liquids leaking in from the worktop above. Install a wooden bar underneath the worktop.
Page 68
Installation Mounting under worktops (mm) Make sure that the piece of furniture rear/bottom part has an opening of approx. 60 mm.
Page 69
Installation Mounting under cooktops Whenever a cooktop is installed above the oven, a wooden separator has to be installed at a minimum distance of 20 mm from the top of the oven to prevent overheating when the two appliances are used at the same time.
Page 70
Installation Mounting into a column (mm) Make sure that the piece of furniture top/rear part has an opening approx. 35-40 mm deep.
