Sanyo Twicell HR-SCC Specifications

23.0 mm
D
Dimensions
(with tube)
H
Typical Characteristics
Charge
1.8
1.7
1.6
1.5
1.4
1.3
1.2
Charge : 2100mA (- V=10mV)
Ambient Temp. : 0°C,20°C,40°C
1.1
1.0
0 10 20 30
Charge Time (min)
Type : Nickel-Metal Hydride Battery
Capacity
Nominal Voltage
Charging Current x Time
43.0 mm
Ambient Temp.
Internal Impedance
(after discharge to E.V.=1.0V)
Weight
Size
1)Single cell capacity under the following condition.
23.0 mm
2)Use recommended charging system.
43.0 mm
3)After a few charge and discharge cycles under the above 1) condition.
4)With tube.
0°C
20°C
40°C
40 50 60 70 80
Cell Type HR-SCC

Specifications

Typical
1)
Minimum
Fast Charge
Charge
Fast Charge
Condition
Discharge Condition
Less than
30days
Storage
Less than
Condition
90days
Less than
1year
3)
4)
:(Diameter) x (Height)
4)
Charge : 210mA×16h, Discharge : 420mA(E.V.=1.0V) at 20°C
Discharge
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
Charge : 210mA x 16h
Rest : 1h
0.8
Discharge : 600mA, 2100mA, 6A,
0.7
15A
Ambient Temp. : 20°C
0.6
0.5
0
Size : SC
2100mAh
1900mAh
1.2V
2100 mA x about 1.1h
2)
0°C - 40°C
2)
0°C - 50°C
-20°C - 50°C
-20°C - 40°C
-20°C - 30°C
About 7mΩ(at 1000Hz)
About 59 g
23.0(D) x 43.0(H) mm
600mA
2100mA
6A
500 1000 1500 2000
Discharge Capacity (mAh)
15A
2500
