MR F57W
MR F57B
Class-D Fixed Mount VHF Radio
Nothing Comes Close to a Cobra
®
MRF57_CVR.indd 1
Introduction
Thank you for purchasing a CobraMarine
Properly used, this Cobra
many years of reliable service.
Owner's Manual
How Your CobraMarine VHF Radio Works
This radio is a VHF transceiver for fixed mounting on your boat. It gives you 2-way
vessel-to-vessel and vessel-to-shore station communications, primarily for safety and
secondarily for navigation and operational purposes. With it, you can call for help, get
information from other boaters, talk to lock or bridge tenders and make radiotelephone
calls to anywhere in the world through a marine operator.
Besides 2-way communications, in the U.S.A., the radio can provide quick
access to receive eight NOAA (National Oceanographic and Atmospheric
Administration) and two Canadian weather channels for alerting you to weather
emergencies with a tone on a weather channel you can tune in for your area.
Customer Assistance
Customer Assistance
Should you encounter any problems with this product, or not understand
its many features, please refer to this owner's manual. If you require further
assistance after reading this manual, Cobra Electronics offers the following
customer assistance services:
For Assistance In The U.S.A.
English only, automated.
24 hours a day, 7 days a week 773-889-3087
English and Spanish 8:00 a.m. to 5:30 p.m. Central Time Mon. through Fri. (except
holidays) 773-889-3087 (phone).
English and Spanish. Faxes can be sent to 773-622-2269
English only. www.cobra.com/support
English and Spanish. productinfo
For Assistance Outside The U.S.A.
Contact your local authorized Cobra Electronics Dealer
A1 English
English
Our Thanks To You And
Customer Assistance
VHF radio.
®
product will give you
®
cobra.com
@
©2018 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
2/28/18 5:14 PM
