Model Identification

STB 06 2 3 C1
Sanyo 26" Thru the wall
Nominal Cooling Capacity
08: 8000BTU
10: 10000BTU
11: 11000BTU
12: 12000BTU
Wall Receptacles
Parallel
Tandem
115V.
230/208V.
15AMP
15AMP
Specification
Model Number
Voltage (V)
Cooling Capacity (BTU/h)
Cooling EER (BTU/hW)
Cooling Watts (W)
Cooling Amps (A)
Plug Type
Recommended Circuit Protection
(Time Delay) (A)
Dehumidication (Pints/h)
Indoor CFM (Hi / Lo)
Weight Ship / Net (lb)
Model Number
Voltage (V)
Cooling Capacity (BTU/h)
Cooling EER (BTU/hW)
Cooling Watts (W)
Cooling Amps (A)
Plug Type
Recommended Circuit Protection
(Time Delay) (A)
H/P CAPACITY (BTU/h)
H/P COP (W/W)
H/P Watts (W)
H/P Amperes (A)
Electric Heating Capacity (BTU/h)
Electric Heating Watts (kW)
Electric Heating Amperes (A)
Dehumidication (Pints/h)
Indoor CFM (Hi / Lo)
Weight (Ship / Net)
Warranty
• Full one-year warranty. Includes service on property. ( Parts and labor included.)
• Full five-year warranty on sealed system. Includes service on property. ( Parts and labor included.)
• 2nd-5th year limited parts warranty.
Q 3135
E 11583
The product is produced by
Sanyo Airconditioner Manufacturing(S)
Development Flag
Type
C: Cooling H: Heat Pump
Electric Heater size (See below)
0: No Electric Heater 1: 1.2kw 3: 3.4kw
:
Voltage
1: 115V
2: 230/208V
Wall Sleeve
Dimension
Perpendicular
230/208V.
20AMP
STB0810C1
115
8200
8.7
940
8.3
Parallel
15
2.0
270/240
93/82
COOLING & ELECTRIC HEATING MODEL
STB0811C1
115
8000
8.7
920
8.3
Parallel
15
-
-
-
-
4040
1350
12.0
2.0
250/220
93/82
*Please refer to warranty policy for more detail.
5
15
"
8
7
16
"
8
26"
COOLING ONLY MODEL
STB1010C1
STB1020C1
115
230/208
10200
9700/9500
8.5
8.5/8.5
1200
1140/1110
10.6
5.0/5.3
Parallel
Tandem
15
15
2.7
2.6
270/240
270/240
101/90
100/89
STB1023C1
STB1123C1
230/208
230/208
9500/9300
11300/11000
8.5/8.5
8.5/8.5
1120/1090
1330/1310
5.0/5.3
6.0/6.5
Perp.
Perp.
20
20
-
-
-
-
-
-
-
-
11250/9200
11250/9200
3550/2930
3550/2930
15.5/14.2
15.5/14.2
2.6
3.2
250/220
250/220
100/89
106/95
SANYO Fisher Company
A Division of SANYO North America Corporation
21605 Plummer Street Chatsworth, CA 91311 USA
Phone: 818-998-7322 Fax:818-717-2703
website: http://www.sanyohvac.com
Dimension of
Wall Opening
Wall opening of
26-1/8" x 15-3/4"
is required
Be sure to use lintel
to support the block
and brick above the
sleeve to retain the
weight of the unit
STB1220C1
230/208
11500/11300
8.5/8.5
1350/1330
6.1/6.6
Tandem
15
3.2
270/240
104/93
HEAT PUMP MODEL
STB0823H1
230/208
8000/7800
8.5/8.5
940/920
4.2/4.5
Perp.
20
7500/7400
2.5/2.5
880/870
4.0/4.3
11250/9200
3550/2980
15.5/14.2
2.0
250/220
101/90
Specifications subject to change without notice.
