Sanyo 30KS32A Specifications

SUBMITTAL SHEET
S
YSTEM
INDOOR/OUTDOOR
30KS32A
KS3032/C3032A
WALL MOUNTED AIR CONDITIONER
GENERAL DATA(AT 230V)
POWER V/PH/HZ
Circuit Ampacity, Min. (A)
Fuse size, Max. (A)
COMPRESSOR
No. used
R.L. Amps - L.R. Amps (A)
Crankcase Heater
OUTDOOR FAN - TYPE
Dia. (in.) - No. used
Type Drive - No. speeds
No. Poles - RPM (High)
No. Motors ñ HP
CFM (High)
F.L. Amps. (A)
OUTDOOR COIL - TYPE
Fin Type - Pipe Type
Rows - F.P.I.
Face Area (sq.ft.)
Tube Size (in.)
INDOOR FAN - TYPE
Dia. & Length (in.) - No. used
No. speeds
No. Poles -RPM (High)
No. Motors - WATTS
CFM (HI/MED/LOW)
F.L. Amps (A)
INDOOR COIL - TYPE
Fin Type - Pipe type
Rows - F.P.I.
Face Area (sq. ft.)
Tube Size (in.)
Drain Connection Size (in.)
REFRIGERANT
Lbs. - R22 (O.D. Unit)
Control
Connection
Line Length, Max (ft.)
Lift difference, Max (ft.)
Line Size - in. O.D. Discharge
Line Size - in. O.D. Suction
DIMENSIONS (in.) H
Indoor Unit -Uncrated 4- 9/16 x 59- 1/16 x 9- 7/16
-Crated 18- 3/16x 62- 9/16 x 11-5/8
Outdoor Unit -Uncrated 48- 5/8 x 37
-Crated 52- 7/32 x 40
WEIGHT INDOOR
Net (lbs.) 64.0
Shipping(lbs.) 82.0
Shipping Volume (cu.ft.) 7.7
230/208/1/60
30
30
Rotary-Hermetic
1
10.6 ñ 77.0
-
Propeller
18-3/32 - 2
Direct ñ 2 (AUTO)
6 - 879
2 - 110
3,670
1.8
Aluminum Fin & Copper Pipe
Slit Plate - Inner Bared
2 - 12.7
11.63
3/8
Cross - Flow
4 -13/18 & 46-1
3 & Auto
4 -1,260
1 - 40
840/740/620
0.6
Aluminum Fin & Copper Pipe
Slit Plate - Inner Riffled
2-12.7
3.33
3/8
1 - 1/4
R22
8.6
Capillary Tube
Flare
165
100
3/8
3/4
x W x D
x 13-3/8
x 16- 3/8
OUTDOOR
198.0
223.0
19.8
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H)
Sensible Capacity (BTU/H)
Latent Capacity (BTU/H)
SEER
Dehumidification (Pints/H)
Amps (A)
Power Inputs (W)
Outdoor Sound Rating(bels)
FEATURE
Controls
Remote Controller
Temperature Control
Timer
Night Setback
Air Louver (Horizontal)
(Vertical)
Power Failure Automatic Restart
Self Diagnosis
OPTION
Refrigerant Line Set
Low Ambient Control
Fresh Air Intake
Central Remote ON-OFF Control
Airduct Extension
Indoor Frame Extension
Condensate Drain Pump
Non-Removable Remo-con Bracket
Wire Remote Controller
OPERATING RANGE
Cooling Indoor Air
Intake Temp.
Maximum 95 F DB/71 F WB
Minimum 67 F DB/57 F WB
CERTIFICATION
AIRCONDITIONING PRODUCTS
SS30KS32-2
30,000/29,000
18,800/18,200
11,200/10,800
10.4/10.7
10.0/10.9
13.0/13.6
2,880/2,770
7.9
Microprocessor
LCD Wireless type
IC Thermostat
ON/OFF, 24 hours
Built-In
Manual
Automatic
Built-In
N/A
AP3210BH (30 ft)
AP3215BH (50 ft)
Available
N/A
Available
N/A
N/A
Available
RCS5PS4B
RCS-102WD/RDS-302WD
Outdoor Air
Intake Temp.
115 F DB
67 F DB
30KS32A
