NOTICE PURCHASER/INSTALLER before proceeding be sure to check the following: 1) Do you have a valid CT License? Proceed no further unless you have supplied STAC, INC. with a copy of your CT License. 2) This system must be installed and operated in accordance with all DOT regulations and according to the instructions contained inside this manual. - Page 3 The product supplied to the heat exchanger by a pressure line which is tee’d into the pressure discharge line. STAC, INC. provides an orifice fitting to be installed in the THERMAFLOW unit to limit the amount of product being pumped through the heat exchanger.
-
Page 4: Positioning & Mounting
DOT’s requirements on mounting of equipment that require roll-over-protection. NOTE: STAC, INC. does not assume any liability for its products if they are mounted or plumbed in a way that does not meet the DOT’s requirements. IN MOUNTING... -
Page 5: Hydraulic Plumbing
NOTE: When mounting the THERMAFLOW Model 500P across the frame rails and behind the cab, make sure that the suction and pressure hoses are properly plumbed and secured away from the driveline. STAC INC ST PAUL MN 800-334-7699 PAGE 4... -
Page 6: Product Line Plumbing
Product Inlet Port. Failure to use the orifice fitting provided could cause your THERMAFLOW cooler assembly to improperly cool the hydraulic oil. Please consult STAC, INC. with any questions regarding this orifice fitting. NOTE: Always use UP Approved hoses and fittings. -
Page 7: Final Assembly
This will ensure proper oil flow during extreme cold weather operation. Use of synthetic hydraulic oils is also recommended. Recommended Oil: MOBIL DTE 10-32 or equivalent. DIAGRAM C Filter assembly procedures for THERMAFLOW Model 500P STAC INC ST PAUL MN 800-334-7699 PAGE 6... -
Page 8: Start-Up Procedures
NOTE: If the hydraulic oil temperature is higher or lower than the 10-20°F rise, please consult STAC, INC. at 800-334-7699. DO NOT OPERATE THIS SYSTEM UNTIL AFTER YOU HAVE CONSULTED STAC, INC. -
Page 9: System Maintenance
Grease output shaft every 6 to 12 months depending on use. If PTO does not have a grease zerk on output shaft, remove direct mount hydraulic pump and grease the output shaft using a high quality gear lube. STAC INC ST PAUL MN 800-334-7699 PAGE 8... -
Page 10: Troubleshooting
Ensure suction line connections are tight. Ensure oil is free from water and contaminants. Drain and refill with recommended oil and replace filter. Ensure use of recommended oil type and weight. STAC INC ST PAUL MN 800-334-7699 PAGE 9... -
Page 11: Specifications
STAC INC ST PAUL MN 800-334-7699 PAGE 10... -
Page 12: Parts Breakdown
® INSTALLATION GUIDE, OPERATING PROCEDURES & PARTS BREAKDOWN MODEL 500P PARTS BREAKDOWN STAC INC ST PAUL MN 800-334-7699 PAGE 11... -
Page 13: Parts List
3000 PSI RELIEF VALVE 300708 12MJIC-12MORB 90° 300748 12MORB-12MORB ADJUSTABLE 500001 500P TANK 500030 500P LID 500032 SPACER 500130 MOUNTING BRACKET 500200 500P/100P SHOCK MOUNT 500412 6MSAE-6MP STRAIGHT 500418 6MSAE-08MP STRAIGHT 600332 BREATHER STAC INC ST PAUL MN 800-334-7699 PAGE 12... -
Page 14: Product Offering
Product Offering Fans Spal Multi-Wing Fittings Tompkins Stucci Ryco Heat Exchangers Thermal Transfer Flat Plate Hydraulic Motors Eaton/Charlynn Muncie Permco Hydro Leduc PTO’s Muncie Pumps Muncie Parker Permco Hydro Leduc STAC INC ST PAUL MN 800-334-7699 PAGE 13... - Page 15 THERMAFLOW WARRANTY The THERMAFLOW 500P Hydraulic Cooler & Tank Stabilizer is warranted against any defect in material and workmanship which existed at the time of sale by STAC, Inc. according to the following provisions, subject to the requirements that the Cooler must be used only in accordance with the catalogue and package instructions.
