- Page 1 Tape ® VariWhite Gaffer Kit Specifications Part No.: 2932200BICLR – RoscoLED VariWhite Gaffer Kit External Dimensions: 14” L x 12” W x 5.4” H (35.6 cm L x 30.5 cm W X 13.7 cm H) Weight: 8 lb (3.6 kg)
-
Page 2: Table Of Contents
Information and specifications in this document are subject to change without notice. Rosco assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. RoscoLED VariWhite Gaffer Kit User Guide v1 Copyright ©2018 by Rosco... -
Page 3: Introduction
INTRODUCTION Congratulations on your purchase of a RoscoLED Gaffer Kit. Designed to meet the needs of today’s Chief Lighting Technicians and Cinematographers, the RoscoLED VariWhite Gaffer Kit provides a quick and versatile solution for the most challenging lighting situations. Combining durable color-correct and tunable LED strips and tiles with simple plug-and-play connections offers filmmakers fast, easy set-up that minimizes downtime between takes. - Page 4 PREVENTING ELECTRIC SHOCK • This machine uses mains electrical power at 100-240VAC. When directly contacted, such voltages are hazardous to human life. Follow all local electrical codes and take precautions when using this product. • This product is designed to operate from three-wire power systems, where one of the wires is a safety ground.
- Page 5 MAINTAINING SAFE OPERATION • Use only Rosco spare parts and accessories so as to not void the system warranty. • RoscoLED DMX Controllers must only be serviced by a qualified technician. • RoscoLED Gaffer Kits are not intended for residential use. Use only in a professional studio or mobile video environment.
-
Page 6: Unpacking
Do not attempt to operate your RoscoLED Gaffer Kit if there are any signs of physical damage. In case of damage, contact your local Rosco dealer. Your RoscoLED Gaffer Kit will arrive with all components detached from the power supply and controllers. -
Page 8: Connecting Roscoled Tape
Each connector has a Male or Female gender, so there is no possibility of an incorrect connection. The RoscoLED Tape in your Gaffer Kit requires 12VDC input. Always use the Rosco supplied Power Adapter or alternate AA battery or Car Adapter to avoid damage to the system components and voiding the warranty. - Page 9 Basic Configuration: Power Supply Controller Extension Cables RoscoLED Tape (DMX or RF Remote) (Optional) (Strips or Tiles)
-
Page 10: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE SOLUTION Tape/Tile will not Barrel Connections incomplete Check all connections illuminate in Manual Not plugged into AC Mains Check AC Mains connection Stand-Alone mode Batteries charge depleted Check battery charge or replace CCT/DMX Controller set to DMX Confirm Controller is set to Manual mode mode... -
Page 11: Specifications
SPECIFICATIONS LED Configuration: 3 emitters/inch Heat Sink: 3 oz Copper Lumen Output: 38 lm/in (1500 lm/m) Color Temp. Range: 3000K – 5600K CRI: TLCI: Voltage: 12VDC Power Consumption: 12” VariWhite Strips = 5.8W/0.48A 24” VariWhite Strip = 11.6W/0.96A 3”x6” VariWhite Tiles = 19.2W/1.6A IP Rating: Strips: IP67 for use indoors and outdoors Tiles: IP43 for indoor use only... -
Page 12: Warranty
This warranty does not cover damage to the Rosco Product caused by parts not manufactured, distributed or certified by Rosco. Rosco is not obligated to provide warranty service should the Product fail to be properly maintained or fail to function properly as a result of misuse, abuse, improper installation, neglect, improper shipping, damage... - Page 13 www.rosco.com/roscoLEDvariwhiteGafferKit...
