Mattel DLV45 Instructions

Troubleshooting

Trimming Section

4 Trim Buttons
Note: When Hover Board veers to one side in hovering stage, press the trim
Press to stabilize Hover Board's balance.
button of the opposite side to stabilize Hover Board's direction as needed.
C C
Hints for charging
Note: Recharge Hover Board when battery is low, it may take 90 to 120 minutes.
LED ashing quickly- Low battery.
Mattel, Inc., 636 Girard Avenue, East Aurora, NY 14052, U.S.A. Consumer Services 1-800-524-8697. Mattel U.K. Ltd., Vanwall Business
CONSUMER INFORMATION
Park, Maidenhead SL6 4UB. Helpline 01628 500303. Mattel Australia Pty., Ltd., Richmond, Victoria. 3121.Consumer Advisory Service -
Need Assistance? Visit service.mattel.com or call 1-800-524-8697
(US and Canada only). 1300 135 312. Mattel East Asia Ltd., Room 503-09, North Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. Tel.: (852)
SERVICE.MATTEL.COM
3185-6500. Diimport & Diedarkan Oleh: Mattel Southeast Asia Pte. Ltd. , No 19-1, Tower 3 Avenue 7, Bangsar South City, No 8, Jalan
Kerinchi, 59200 Kuala Lumpur, Malaysia. Tel: 03-78803817, Fax: 03-78803867.
4

SET UP

1

CHARGING WITH THE USB CABLE

Must charge hover board before rst use. Charge time is approximately 120 minutes or more. Connect the Controller to a powered USB port with the supplied USB cable.
Attach power cable located inside Controller to Hover Board. Hold the charging plug and gently pull it out of the socket.
Note: NEVER pull on the cable as this may cause the cable to break.
2
Hover Board is powered by a LiPo battery that is permanently installed.
Set Hover Board to "OFF" position and Controller in "Charging" position before charging.
ON ON OFF OFF
Charging (90-120 minutes Or More)
Check cable connection
3

Controller Battery Installation

Unscrew the battery cover with a Phillips head screwdriver (not included). Insert new 3 AAA (LR03) alkaline batteries
(not included) with polarity (+/-) as shown inside the battery compartment. Replace battery cover and tighten screw.
Use either "AAA" alkaline batteries or equivalent. For longer life, use only alkaline batteries. When exposed to an electrostatic
source, the product may malfunction. If this problem occurs, reset the product by reinstalling the batteries. Replace batteries
in Controller if the Hover Board runs slowly after a recharge or if you see a green light ashing on the Controller.
2
A A
D
D
B B
B B
D D C C
A A
Computer not included.
ON ON
charging
Note: When Hover Board is charging, Red LED of Controller will be "ON".
Fully charged
0890
INSTRUCTIONS INSTRUCTIONS
Includes one 3.7V Rechargeable LiPo Battery Pack for Hover board.
Requires 3 AAA alkaline batteries (not included) for the Controller.
Dispose of batteries safely. Call or go to website for replacement propeller installation instructions.
Safety Information and Notes
CAUTION: To prevent entanglement, keep hair away from propellers.
CAUTION: Do not attempt to grab the rotating propeller.
CAUTION: If propeller(s) are damaged, do not y Hover Board. Flying with damaged propellers may lead to injury.
IMPORTANT: Please read all instructions before operating your Hover Board.
Only use the product under the supervision of an adult. Take care to ensure during use that there is a su ciently large space between people, animals and objects.
Do not put objects into the propeller.
This product is not recommended for use on loose dirt or wet surfaces. Do not immerse in water.
IMPORTANT: DO NOT touch Hover Board with metallic objects. The product might short circuit causing damage.
Stay at least 3 to 6 feet away from the Hover Board. That goes for anyone watching as well.
Always keep an eye on the Hover Board. If it looks like it's going to crash into you, your friends or anything else, release the throttle joystick and step out of the way.
Never disassemble or attempt to modify the product.

LiPo Battery Information

DO NOT RECHARGE THE HOVER BOARD IF IT FEELS HOT. ALLOW IT TO COOL BEFORE RECHARGING.
DO NOT ATTEMPT TO USE OR CHARGE THE HOVER BOARD IF IT SHOWS SIGNS OF LEAKAGE OR CORROSION.
DO NOT DISASSEMBLE THE HOVER BOARD PERMANENTLY INSTALLED LIPO (LITHIUM POLYMER) BATTERY. THE LIPO BATTERY IS A SEALED LIPO BATTERY.
IF THE HOVER BOARD AND/OR CONTROLLER ARE WET, THOROUGHLY DRY BEFORE USING OR CHARGING.
REGULARLY EXAMINE ALL CONNECTORS. IN THE EVENT OF DAMAGE, DO NOT USE.
REPLACE BATTERIES IN CONTROLLER IF HOVER BOARD CANNOT PERFROM PROPERLY AFTER THE HOVER BOARD FULLY CHARGED.
When exposed to an electrostatic source or the Hover Board malfunctions, turn the power OFF and ON again. This should reset your Hover Board and let it resume normal operation.
To avoid accidental operation, always turn switches OFF and remove all batteries for storage.
ADULT NOTE: To remove LiPo battery for disposal: turn o unit, cut out battery from the foam casing, use scissors to cut wire, wrap wire end with tape to isolate it, repeat with remaining wires.
Dispose of LiPo battery in accordance with your local laws.
Contents: Please remove everything from the package and compare to the contents shown here. If any items are missing, please contact your local Mattel office. Keep these instructions for future
reference as they contain important information.
© 2016 Mattel. All Rights Reserved.
1

PLAY

1
Switch ON and pair Hover Board to Controller. Remember to disconnect the USB cable from the Controller before play.
1 1
A Switch ON the Hover Board, green LED will ash slowly. B Switch ON the Controller, green LED will ash slowly.
ON ON OFF OFF
"Beep"
If green LED keeps ashing, please switch OFF Hover Board and Controller, repeat step #1A.
2

About the Controller.

Launch/Land

Press to launch.
Press again to land.
360° Spin
Keep pressing to make Hover Board spin in
clock-wise direction. Release button to stop.
3
Press launching / landing button (in blue) once to launch. Allow Hover Board to stabilize and hover for a few seconds.
3 3
A Place the Hover Board on the oor with doll B
facing away from you.
NOTE: Doll ies in the direction she is facing.

Directional Control

3
8+ 8+
DLV45
INDOOR USE ONLY.
Adult assembly required to
attach replacement propellers.
DLV45-0970
1100979139-DOM
Green LED on Controller stops ashing and
"Beep" sounds, indicating devices are paired.
OFF OFF ON ON
charging
F/B/L/R
Push joystick as needed.
Release joystick to stop.
Height control switch
Adjust up/down
Press once to launch.
Press again to land.
Hint: If Hover Board doesn't function properly,
turn "OFF" Hover Board and Controller,
repeat the PLAY steps. If malfunction continues,
check if battery is low.
