WASHING MACHINE Owner’s Instructions SW-903(P)/SWT90C1(P)/SWT90C2(P) Before operating the washing machine, please read this manual thoroughly, and retain it for future reference. BEFORE USING THE WASHING MACHINE 1 PRECAUTIONS CONTROL PANEL DESCRIPTION AND CLEANING OF PART 2 WASHING PROCEDURE To Wash To Spin Dry To Rinsing Overflow rinse...
IF YOU NEED HELP. Do not hesitate to call your local Samsung Service Center. They will be pleased to help you. Be sure to give them your name, address, telephone number and the purpose of the call. SPECIFICATIONS DIMENSIONS SWT90C1(P)/SWT90C2(P)
BEFORE USING THE WASHING MACHINE Remove the cap-hose from the drain hose. In the case of pump drained washer, remove the cap-hose from the drain hole. PRECAUTIONS WHEN OPERATING Don't use excessively hot water. (50˚C or more) Plastic parts may be deformed or damaged. Also, clothing may be deformed or decolored.
DESCRIPTION AND /CLEANING OF PARTS INNER LID DRAIN HOSE (with pump) OVERFLOW FILTER LINT FILTER This is used for gathering the dregs made during washing. WASH TUB LID Be sure to keep the lid closed during washing and spinning. PULSATOR CONTROL LEG CLEANING THE LINT FILTER OVERFLOW FILTER...
WASHING PROCEDURE A - t y p e : SWT90C1(P)/SWT90C2(P)/WT10S0(P)/WT10S1(P)/WT10S2(P) TO WASH ( A - t y p e ) 1. Before starting to wash, proceed as follows, Connect the water supply hose and open the water tap. • Lay the drain hose down toward a sinkhole.
TO RINSING ( A - t y p e ) 1. Set the cycle selector KNOB to ‘WASH.RINSE’. Wash/Rinse Wash (In the case of drain Drain Rinse pump ‘WASH’) CYCLE SELECTOR CYCLE SELECTOR 2. Supply the proper amount of water so as not to delete one space overflow the top of the washing tub.
INSTALLATION LOCATION Leave some space of at least 15cm between the washing machine and the wall. Place the washing machine on a sturdy flat surface. If the washing machine is placed on an uneven or weak surface, noise or vibration may occur. (Allowable is 2˚) Never install the washing machine near water.
MAINTENANCE TO LOAD THE LAUNDRY INTO THE SPIN BASKET. Press the laundry evenly and put the safety cover into the spin basket as shown in the figure. TO RETRIEVE THE CLOTHING THAT HAS FALLEN BETWEEN THE BASKET AND TUB. For safety reason, pull the power supply plug out of the socket.
