Samsung SW75USP User Manual

Samsung washing machine user manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

SW75USP

Washing Machine

user manual

imagine
the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/global/register
SW75USPIW-02459M_EN(ÀÓ½Ã).indd 1
2009-05-28 ¿ÀÈÄ 4:34:23

Advertisement

Table of Contents
loading

Related Manuals for Samsung SW75USP

Summary of Contents for Samsung SW75USP

  • Page 1: Washing Machine

    SW75USP Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register SW75USPIW-02459M_EN(ÀÓ½Ã).indd 1 2009-05-28 ¿ÀÈÄ 4:34:23...
  • Page 2 Easy-to-iron AIR TURBO is perfect for delicates and clothes made of synthetic fabrics. No more hanging and waiting. Simply iron straight-out-of-the washer, since AIR TURBO eliminates just enough moisture to keep clothes adequately damp for ironing.

  • Page 3: Safety Instructions

    Do not bend the power supply cord by force or press it with heavy things. • − An electric shock or a fire may take place. Do not install the washer nearby electric implement or don’t put a candle light or cigarette • light on the washer.
  • Page 4 • − An electric shock or a fire may take place if it catches flame. If the washer makes strange noise, smell or smoke, unplug it promptly and call service agent. • − An electric shock or a fire may take place.

  • Page 5: Table Of Contents

    SETTING UP YOUR WASHER MANUAL FUNCTIONS INSTALLATION & MAINTENANCE TROUBLESHOOTING WASHING MACHINE WON’T WORK? SW75USPIW-02459M_EN(ÀÓ½Ã).indd 5 Description of part Checking before washing and caring for garments How to wash automatically depends on the laundry Control Panel manual functions Environment...

  • Page 6: Setting Up Your Washer

    DESCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Filter Lint will be collected in the filter during washing. Fabric softener dispenser Pulsator...

  • Page 7: Checking Before Washing And Caring For Garments

    CHECKING BEFORE WASHING AND CARING FOR GARMENTS Must follow the checkpoints in order to avoid machine problems or damages on garments. If the below problems are caused by customer’s faults, separate service fee will be charged. • Checkpoints Before Starting Washing Check if the clothes are bleaching or not.

  • Page 8: Caring For Clothes Before Washing

    CARING FOR CLOTHES BEFORE WASHING Take out personal belongings from pockets. Caution, Check the pockets! Hairpins and coins cause damages to • clothes and washing machine. They make noise and problems to the machine. Must check the pocket.

  • Page 9: How To Wash Automatically Depends On The Laundry

    If the softener is inserted in the softener dispenser, it automatically adds in at the last rinsing • cycle. Put the laundry into the washer and add detergent, too. Be careful not to overload. Use right detergent for the fabrics you are washing. •...

  • Page 10: Control Panel

    CONTROL PANEL For more details, see control panel of your washing machine. POWER BUTTON MEMORY BUTTON START/HOLD BUTTON COURSE SELECT BUTTON DELAY START BUTTON FILTER CHECK SPIN BUTTON RINSE BUTTON 10_Setting up your washer SW75USPIW-02459M_EN(ÀÓ½Ã).indd 10 Press this button once to operate.
  • Page 11 WASH BUTTON SOAK BUTTON REMAINING TIME, DELAY START TIME, ERROR DISPLAY AIR-TURBO BUTTON WATER LEVEL BUTTON WATER SUPPLY BUTTON SW75USPIW-02459M_EN(ÀÓ½Ã).indd 11 Press this button to perform a wash only or to adjust the washing time. You can set the wash time from between 4 to 30 minutes. Press this button to perform a soak wash.

  • Page 12: Fuzzy Course

    FUZZY COURSE Selects the best washing course automatically. 1. Press the Power Button to “On”. 2. Press the Start/Hold button. Water level is selected automatically. Washing rinsing, and spinning follow. If you want to pause, press the Start/Hold button again. You can change the course when paused.

  • Page 13: Clean Tub Course

    CLEAN TUB COURSE Use this course to clean the tub. It will keep the tub clean and sanitary. 1. Press the Power button to “On”. 2. Press the Course select button three times. 3. Press the Start/Hold button. 4. Add a delicated detergent and close the lid Never place laundry in the tub when cleaning inside the tub, as this can cause discoloration or damage to the laundry.

  • Page 14: Super Clean Course

    SUPER CLEAN COURSE Use for cleaner washing. 1. Press the Power button to “On”. 2. Press the Course select button six times. 3. Press the Start/Hold button and put the proper amount of detergent into tub.

  • Page 15: Manual Functions

    manual functions Possible to select the function for each course. (Example) For a simple washing as the little dirt course : Power  Select the little dirt course  Wash  Start/Hold SW75USPIW-02459M_EN(ÀÓ½Ã).indd 15 SOAK FUNCTION (Including WASH, RINSE, SPIN) Press the Power button.

  • Page 16: Installation & Maintenance

    As plastic an electrical components are affected by direct heat, never place the washer near furnaces, boilers, etc. Do not place under direct sunlight. LEVELLING If the washer is not leveled with the ground, it makes the machine tremble more or be out of order. So, • make sure that the washer is leveled properly.
  • Page 17 ‘click’ sound. 5. Connect the other end of the water supply hose to the inlet water valve at the back of the washer. Screw the hose clockwise all the way in. 5-1. Connect the other end of the water supply hose to the inlet water valve at the top of the washer.

  • Page 18: Assembling The Rat Protection Panel

    HOW TO CONNECT THE DRAIN HOSE IN CASE OF PUMP-DRAINED WASHER Attach the drain hose to the rear of the washer. Install the • clamp on the drain hose and tighten to prevent leakage of water.

  • Page 19: How To Put The Detergent In

    HOW TO PUT THE DETERGENT IN 1. Open the detergent box by pulling in the direction of the arrow as shown in the figure and then put the powder detergent in the detergent box. 2. Put in one-time amount of detergent evenly so the detergent may not brim over the box.

  • Page 20: Cleaning The Filter

    3. Clean the Magic filter. HOW TO CLEAN THE PUMP FILTER 1. Place a rag under the washer filter not to wet the floor. 2. Rotate the filter counterclockwise and pull out the filter. 3. Remove dirts and rotate the filter clockwise until it locks in position.

  • Page 21: Troubleshooting

    4 minutes after the water supply has started, the buzzer rings and “4E” is displayed on the remaining time indicator. - Is the laundry spread out evenly in the washer? - In the washer set on a sturdy flat surface? - Restart after spinning.

  • Page 22: Washing Machine Won't Work

    SW75USPIW-02459M_EN(ÀÓ½Ã).indd 22 CHECK & SOLUTION Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord.  Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose.

  • Page 23: Specification

     If the water supply is suspended, turn off the faucet and power off. Check if the laundry is spread evenly in the washer.  Spread out the laundry evenly and start again. Check if the washing machine levels on a sturdy flat floor.
  • Page 24 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT AUSTRALIA 1300 362 603 www.samsung.com Code No. DC68-02447K_EN SW75USPIW-02459M_EN(ÀÓ½Ã).indd 24 2009-05-28 ¿ÀÈÄ 4:34:42...
