Samsung SV-5000W Owner's Instructions Manual

Samsung video cassette recorder owner's instructions.
Hide thumbs

Advertisement

VIDEO
CASSETTE RECORDER
SV-5000W
Owner's Instructions
REC
/I STANDBY/ON
EJECT
RESET
LINE 1 IN
VIDEO
L
AUDIO
R
CHANNEL
STANDBY/ON
EJECT
INDEX
REC.SPEED CLK/COUNT
TIMER
STROBE
AUDIO
1
2
3
ART
INPUT
4
5
6
CH
9
7
8
100
CLR/RST
0
REC
STOP
P/STILL
DISPLAY
MONITOR
A.DUB
OUTPUT SYSTEM
THROUGH
INPUT
OUTPUT
SYSTEM
SYSTEM
NTSC
REW
F.F
OK
PAL
AUTO
MENU
SECAM
PAL-M
P/S
STOP
PAL-N

Advertisement

   Related Manuals for Samsung SV-5000W

   Summary of Contents for Samsung SV-5000W

  • Page 1

    VIDEO CASSETTE RECORDER SV-5000W Owner’s Instructions OUTPUT SYSTEM THROUGH /I STANDBY/ON EJECT NTSC RESET LINE 1 IN VIDEO AUDIO SECAM CHANNEL PAL-M PAL-N STANDBY/ON EJECT INDEX REC.SPEED CLK/COUNT PICTURE TIMER STROBE AUDIO INPUT CLR/RST STOP P/STILL DISPLAY MONITOR A.DUB INPUT...

  • Page 2: Table Of Contents

    Worldwide TV Color System... Multi-System VCR vs Worldwide VCR ... System Conversion with the Worldwide VCR... Tape Conversion with the Worldwide VCR ... Deciding How to Connect Up Your VCR ... Connecting Your VCR to the TV... ETTING IDEO ASSETTE ECORDER Inserting the Batteries in the Remote Control...

  • Page 3: Safety Instructions

    & RF ADAPTERS Your Owner’s Instructions contain much valuable information on setting up and using your VCR. Please take the time to read them as they will help you take full advantage of the VCR’s features. The booklet is organized as follows: The simple describing of Worldwide VCR.

  • Page 4: Background To The Worldwide Vcr

    Worldwide Broadcasting system is B/G, I, D/K, M, N, L. Multi-System VCR vs Worldwide VCR The Worldwide VCR is similar to the Multi-System VCR in that it will play back tapes recorded in any TV Broadcasting System. However, there are a few key differences:...

  • Page 5: System Conversion With The Worldwide Vcr

    PAL-N Tape Conversion with the Worldwide VCR One of the most useful functions of the Worldwide VCR is the combination of tape duplication and system conversion, more simply known as “Tape Conversion”. This allows the user to copy, for example, a SECAM tape and simultaneously convert it to PAL or NTSC. This is particularly useful for duplicating home video camcorder recordings and sending them to friends or relatives abroad.

  • Page 6: Deciding How To Connect Up Your Vcr

    IN FROM ANT. Rear coaxial STOP Whenever you connect an audio or video system to your VCR, ensure that all units are switched off. Refer to the documentation supplied with your equipment for detailed connection instructions and associated safety precautions.

  • Page 7: Connecting Your Vcr To The Tv

    Connect one end of the SCART cable to the EURO AV socket on AUDIO EURO AV the rear of the VCR, if your television is equipped with this type of connection. VIDEO Plug the other end (of the RCA cable or SCART cable) into the appropriate connector on the television.

  • Page 8: User Set1 Setting

    Select to go to USER SET1 page. # ❷ Setting the Date and Time Your VCR contains a 24-hour clock and calendar used to: preset your VCR to record a programme automatically. You must set the date and time when: you purchase the video cassette recorder.

  • Page 9: Displaying/hiding On-screen Information

    Displaying/Hiding On-Screen Information Your VCR displays most information both on the VCR and television. You can choose to display or hide this information on the television screen (except for the Index, Timer Programming function, which ** M E N U ** cannot be hidden).

  • Page 10: Setting The Vcr Rf Out System

    Setting the VCR RF out System The VCR RF out system and channel is used for TV connection with RF coaxial cable. The RF out system is automatically setted by country selection. If your selection of the country set is U.K., the RF out system is automatically setted U.K-I system.

  • Page 11: Setting The Rf Out Channel

    Setting the RF OUT CHANNEL The initial setting of RF Channel is 60CH. You can select the RF OUT CHANNEL for watching the VCR by TV channel. ** INSTALLATION ** Press MENU on the remote control. COUNTRY AUTO SET UP Result: The programming menu is displayed.

  • Page 12: Presetting The Stations Manually

    Presetting the Stations Manually Your VCR contains a built-in tuner used to receive television broadcasts. It can also receive cable television broadcasts. You must preset the stations received through the tuner. This can ** M E N U ** be done: automatically (see page 19) ;...

  • Page 13: Changing The Preset Station Table

    Changing the Preset Station Table You can rearrange the preset TV stations according to your own preferences: Programme number assigned to the station ** TV STATION TABLE ** Name assigned to the station NAME ❿ ---- ---- ---- ---- Press the MENU button on the remote control. ---- Result: The programming menu is displayed.

  • Page 14: Recording A Programme Immediately

    P/STILL ( ). start recording again P/STILL ( ) or REC. If the VCR is left in pause mode for more than five minutes, recording will be stopped automatically to protect the heads and the cassette. Recording a Programme with Automatic Stop This function enables you to record up to nine hours of programmes.

  • Page 15: Using The Timer Programming Feature

    Using the Timer Programming Feature The Timer Programming feature enables you to preset the VCR to record a programme up to one month before that programme is to be broadcast. Up to six programmes can be preset. Before presetting a recording, check that the date and time are correct.

  • Page 16: Modifying Videoplus+/showview Programming

    On completion, press MENU twice to exit the menu. NICAM is the stereo broadcast system of some countries. (Ex.: U.K., SPAIN, --) If the stereo broadcast system of your country is not NICAM, the SV-5000W can not receive NICAM. ** USER SET1 ** TAPE SELECT :E180/...

  • Page 17: Video

    Checking a Preset Recording You can check your preset recordings: when you have finished presetting the VCR ; or if you have forgotten which programmes will be REC.SPEED CLK/COUNT PICTURE TIMER recorded. STROBE AUDIO Press TIMER and select STANDARD TIMER.

  • Page 18: Sqpb (super Vhs Quasi Playback)

    SQPB (Super VHS Quasi Playback) This function is for playback of Super VHS format tapes only, not for recording. ** USER SET2 ** Press MENU on the remote control and select user set. NICAM COLOR Press the to select USER SET2. BLUE SCREEN ❿...

  • Page 19: Rewinding And Fast-forwarding A Cassette

    ) buttons to minimize this effect. AUTO MENU When you have been using the Slow Motion function for more than about five minutes, the VCR will automatically play to protect the: cassette ; and video heads. Playing a Sequence Frame by Frame You can: stop the cassette at a given frame (image) ;...

  • Page 20: Strobe

    STROBE STROBE AUDIO You can see discrete image in succession. INPUT Press the STROBE during playback, AV, LINE input or station mode received through the tuner. Result: “STROBE” is displayed in screen. Discrete image is displayed in screen like SLOW mode.

  • Page 21: Searching For A Specific Sequence

    Searching for a Specific Sequence Each time you record a cassette on this VCR, an “index” is automatically marked on the tape when recording starts. STANDBY/ON The Search function enables you to fast-forward or rewind to a specific index and start playback from that point. Depending on the direction selected, the indexes are numbered as follows.

  • Page 22: Using The Tape Counter

    Press the P/STILL button ( ) again as often as necessary to advance frame by frame, until the exact recording position is located. While the VCR is in still mode, press the REC button to activate the Assemble Edit function. Result:...

  • Page 23: Connecting Other Equipment To Your Vcr

    Connecting Other Equipment to Your VCR You can connect other audio and/or video equipment to your VCR in different ways. The following illustrations give a few examples of the connection possibilities. The LINE 1 input connectors on the front of the VCR are used for equipment such as camcorders, VCRs or stereo sound systems.

  • Page 24: Recording From Another Vcr Or Camcorder

    SECAM CHANNEL PAL-M STOP PAL-N Connect the VCR from which the cassette is to be copied to the appropriate RCA audio and video input connectors on the front of your VCR, as indicated on page 40, 41. STROBE AUDIO If the other video source does not supply stereo sound, connect only the left audio input (L).

  • Page 25: Convert Recording

    If you wish to convert from NTSC system signal recorded tape to PAL system signal, then insert the playback tape recorded NTSC AUDIO OUT (R) system signal into the sub VCR, which can playback NTSC system. AUDIO OUT (L) Press the INPUT button on the remote control to select the L1 VIDEO OUT input.

  • Page 26: Hi-fi Audio System

    To provide true Hi-Fi audio sound with video entertainment and, at the same time, compatibility with regular VHS tapes, your VCR employs a newly-developed audio recording system. Hi-Fi audio signals (2-channel) are recorded deep into the tape's magnetic coating and the video signal is recorded on top of the audio signals in a shallower layer.

  • Page 27: Audio Dubbing A Pre-recorded Cassette

    The FM Simulcast feature enables you to record: the picture received on the VCR’s tuner ; the sound received from an external source via the LINE 1 RCA input connectors on the front of the VCR. Example: You wish to record a concert transmitted simultaneously on the television and radio.

  • Page 28: Locking Your Vcr

    Result: The lock indicator (LOCK) is displayed. If a cassette is in the VCR when you lock it, the cassette will first be ejected. To unlock the VCR, hold down the P/STILL ( ) button again for approximately five seconds.

  • Page 29: Problems

    Problems and Solutions Before contacting the Samsung after-sales service, perform the following simple checks. Problem No power. Check that the power plug is connected to a wall outlet. Have you pressed the STANDBY/ON button? You cannot insert a video cassette.

  • Page 30: Display Indicators

    SQPB CONVERSION SLP VCR @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e...

  • Page 31

    Tel : 44-1952-292-262 Web site : http://www.samsungelectronics.co.uk North & Latin America France U.S.A (United States America) Tel : 33-10-4938-6569 Tel : 973-691-6200/1-800-Samsung Web site : http://www.samsung.fr Web site : http://www.sosimple.com Germany Canada Tel : 49-6196-66-1900 Tel : 905-819-5031/1-800-Samsung Web site : http://www.samsung.de Web site : http://www.samsungcanada.com...
