Samsung SNC-C6225 Specifications

10x Zoom Mini SmartDome Network Camera
SNC-C6225/C7225
Features Specifications (Camera)
• Real-time 30(25) ips at High Resolution(D1)
Model
• 100x Zoom Control (Optical 10x, Digital 10x)
Camera Type Color/BW
• MPEG-4 & MJPEG Dual Encoding
• Rotating Speed : MAX. 360˚/sec Resolution
• Digital Image Stabilization S/N Ratio
Lens
• Day/Night Function (ICR)
• Smooth Manual speed : MIN. 0.05 °/sec
• Bi-directional Audio Support
• Endless 360˚ Pan Rotation
• Micro SD Memory Card Slot for Alarm Recording
• Shortest Path by Vector Drive Technology
• HTTPS security login support
Min. Scene
• Standard RTP/RTSP support (QuickTime, VLC Player)
Illumination
• Scheduled Preset Function
PAN/TILT
• Vandal Proof/ Weather Proof • IPv4/IPv6 support
• Fan/Heater for Outdoor Installation : SNC-C7225
Functions
Dimensions (unit:mm)
SNC-C6225
Environmental Fan / Heater
Conditions
Power
Physical
SNC-C7225
Specification Weight
NEW
SNC-C6225 SNC-C7225
Color
Sensor Device 1/4" Inter Line Transfer CCD
Horizontal Color : 520TVL BW : 570TVL
50dB (AGC off)
Focal Length 3.8 ~ 38mm
Zoom Ratio 10x Optical, 10x Digital
Aperature Ratio F1.8(W)
Viewing Angle Tele 5.58˚(H) x 4.27˚(V)
Wide 51.2˚(H) x 39.3˚(V)
Lens Drive Type DC Auto Iris
Mount Type Board-in type
Color 0.7 Lux (50 IRE)
B/W 0.02 Lux (50 IRE)
Speed Manual Pan 0.05 ~ 360˚/sec
Preset Pan 360˚/sec
Manual Tilt 0.05 ~ 360˚/sec
Preset Tilt 360˚/sec
Range Panning 0 ~ 360˚(endless)
Tilting 180˚
Number of Auto PAN 8 ea
Number of Preset 127 ea
Number of Pattern 4 ea
Number of Privacy Zone 4 ea
Day/Night Auto/Day/Night (ICR)
Digital Zoom Yes(~ 10x)
High Speed Shutter 1/60 ~ 1/12,000 sec
Sens Up Off/Auto
BLC Low/Middle/High/Off
AGC Normal/HighH/Off
White Balance Auto/Manual(Red,Blue Gain Adj.)
N/A Yes
Operating Temperature -10˚C ~ +50˚C -40˚C ~ +50˚C
Operating Humidity Less than 90%
Power Requirement DC12V
Power Consumption 12W Heater Off(12W)/On(24W)
Dimensions 165(ø) x 162(H) mm 200(ø) x 472(H) x 379(D) mm
1.8kg 2.4kg
Color Body Pearl White
SunSheild N/A Yes
Option Bracket SADT-937WM SADT-732WM(Wall)
SADT-732CM(Ceiling)
Anti Vandal Yes (Aluminum)
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
Specifications (Network)
Model
Network Board OS
Hardware Flash memory
RAM
Ethernet
Video Out / Audio
SD Memory Slot
Alarm Input / Output
Video Compression
Resolution D1
VGA
CIF
Frame Rate
Quality
Audio Compression
Bi-Directional Communication
DIS Digital Image Stabilization
Motion Detection Sensitivity and Area Setting
Protocol IP
Network Protocol IPv4
IPv6
Streaming
Security
DDNS
Connection Maximum User Access
User Access Level Administrator
Operator
User
Event Management Alarm Input
Motion Detection
Schedule
Web Browser Supported OS
Viewer(Default) Supported Browser
S/W upgrade
SDK HTTP API CGI Command
RTP/RTSP API
ActiveX SDK
SNC-C6225 / C7225
Embedded Linux
32M byte
256M byte
RJ-45 (10/100BASE-T)
VBS 1.0Vp-p / Line In / Line Out
Yes (Micro SD/SDHC)
2 ea / 1 ea
MPEG4 / MJPEG Dual Codec Simultaneous Full Frame Dual Streaming
NTSC : 720 x 480 / PAL : 720 x 576
640 x 480
NTSC : 352 x 240 / PAL : 352 x 288
NTSC : 30, 15, 8, 3, 1 fps / PAL : 25, 13, 6, 3, 1 fps
1 ~ 10 level
G.711
Yes
Yes
High, Medium, Low
IPv4 / IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP,
ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, VSIP
TCP/IP, HTTP, HTTPS, SSL, DHCP
Unicast, Multicast
HTTPS(SSL) Login Authentication Digest Login Authentication
Supporting Samsung DDNS and Public DDNS services
Max 10 Users at Unicast Mode / Max 20 Users at Multicast Mode
Live Monitoring, Alarm I/O control, OSD menu control, PTZ control, SD memory search, SETUP
Live Monitoring, PTZ control, Alarm I/O control
Live Monitoring
JPEG Image transfer : FTP / JPEG Image Recording : SD memory
Notification : notify to viewer or by E-mail (one image attachment), Alarm Out
JPEG Image transfer : FTP, E-mail / JPEG Image Recording : SD memory
Windows XP, VISTA
Internet Explorer 6.0 or Higher
Using Web viewer UI
Provides functionality to control cameras and set/retrieve internal parameter values.
Get JPEG image or MJPEG stream Alarm In/Out control
RTP Header, RTSP Command Document
ActiveX API for viewing data streams from IP camera.
