SALES NETWORK
SAMSUNG TECHWIN CO., LTD.
•
145-3, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-120, Korea
TEL : +82-31-740-8132~6 FAX : +82-31-740-8144
SAMSUNG OPTO-ELECTRONICS UK, LTD.
•
Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Surrey KT16 OPS
TEL : +44-1932-45-5308 FAX : +44-1932-45-5325
www.samsungtechwin.com
www.samsungcctv.com
Supreme Image
560TVL, 128x WDR
High Resolution WDR V/F Dome Camera SID-560
Thank you for purchasing a SAMSUNG CCD CAMERA.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
P/No. : Z6806083201B
VAN 07. 11
User's Manual
ENGLISH
Advertisement
Table of Contents
Related Manuals for Samsung SID-560
Summary of Contents for Samsung SID-560
- Page 1 145-3, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-120, Korea TEL : +82-31-740-8132~6 FAX : +82-31-740-8144 SAMSUNG OPTO-ELECTRONICS UK, LTD. • Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Surrey KT16 OPS TEL : +44-1932-45-5308 FAX : +44-1932-45-5325 www.samsungtechwin.com www.samsungcctv.com Supreme Image...
- Page 2 Before operating the camera, confirm the camera model and proper input power voltage. In order to that you can understand this manual thoroughly, we'll introduce our model description. ■ SID-560 SERIES • NTSC MODEL • PAL MODEL SID-560N SID-560P ■ MODEL DESCRIPTION •...
- Page 3 B/W mode so as to obtain better picture definition. - PAL : English, French, German, Spanish, Italian, Chinese Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark...
-
Page 4: Table Of Contents
Contents Precautions Components and Accessories Overview Installation Installation Adjust the panning and tilting, rotating while watching the monitor Connection Connecting To Monitor Connecting To Power RS-485 communication control Operating Your Camera Menu Configuration Menu Setup LENS EXPOSURE WHITE BALANCE BACKLIGHT SSNR DAY/NIGHT IMAGE ADJ... -
Page 5: Precautions
Precautions Do not install the camera in Do not install or use the camera in an extreme temperature conditions. environment where the humidity is high. Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. -
Page 6: Components And Accessories
Components and Accessories Overview 1. SID-560 2. Instruction Manual 3. M4 Tapping Screw 4EA 4. M4 Machine Screw 4EA 5. Adapter plate 6. Installation Video Output Cable COLOR CCD CAMERA User’s Manual COLOR CCD CAMERA User’s Manual... -
Page 7: Overview
Overview Pan Base control panning angle of camera Rotate Base control rotating angle of camera X2.5 Vari-focal Lens Module Rotate Base Holding Screw fix rotated position Pan Base Holding Screws (Color : Silver) fix panned position RS-485 Control Cable : The detailed description refers to p18 Power Input Jack Video Output Jack Function Setup Button... -
Page 8: Installation
Installation When installing on a adapter plate 1) Place the bracket provided on the installation surface and fix it with the M4 An arrow for installing directions tapping screws (provided). (Select either 85X85 or 83.5X46) adapter plate 2) When placing the camera body on the plate, insert the plate pin into the mounting hole on the body as shown in figure-1 and fix it by turning clockwise. -
Page 9: Connection
Connection Connecting to Monitor Connect the VIDEO-OUT jack to the VIDEO-IN jack of monitor. CCTV Camera • As the connecting method varies with the instruments, refer to the manual supplied with the instrument. • If necessary, you can connect the monitor to the REMOTE jack on the back of your camera. -
Page 10: Rs-485 Communication Control
Notes • When you construct external control systems for a camera control, please use to the SAMSUNG TECHWIN PROTOCOL or PELCO-D PROTOCOL. • When you connecting to RS-485 control cable, please peel off the outer skin inside the RS-485 control cable. -
Page 11: Menu Setup
Operating Your Camera Menu Setup Use the five buttons on back of the camera. SET button LEFT RIGHT DOWN button button button button 1. Press the SET button. • Main setup menu is displayed on the monitor screen. MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL... -
Page 12: Exposure
Operating Your Camera DC : Select Auto Iris Lens • When DC is selected, you can control screen brightness. The range of brightness control is between 1 and 70. Adjust the brightness appropriately for optimal screen brightness. EXPOSURE MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL... -
Page 13: White Balance
Operating Your Camera RETURN : Select this to save the changes in the EXPOSURE menu and return to the SETUP menu. Notes • If you press the SET button in ‘AUTO’ mode, You can adjust brightness by increasing or decreasing the shutter speed. (X2~X256) •... -
Page 14: Backlight
Operating Your Camera BACKLIGHT This camera is designed so that it delivers a distinctive subject and background at the same time, even when the subject is in backlight, unlike conventional cameras, by adopting a proprietary SV-IV DSP chip. 1. When the SETUP menu screen is displayed, select ‘BACKLIGHT’ by using the Up and Down buttons so that the arrow indicates BACKLIGHT . -
Page 15: Ssnr
Operating Your Camera SSNR This function reduces the background noise in a low luminance environment. 1. When the SETUP menu screen is displayed, select ’SSNR’ by using the Up and Down buttons so that the arrow indicates ’SSNR’ . MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL... -
Page 16: Image Adj
Operating Your Camera EXTERN : This mode allows you to apply a desired filter to external signals. Notes • When using a Video Auto Iris Lens, if you set the lens level to low, automatic switching between Color and Black & White may not occur. •... - Page 17 Operating Your Camera SPECIAL 1. When the SETUP menu screen is displayed, select ‘SPECIAL’ by using the Up and Down buttons so that the arrow indicates ‘SPECIAL’. MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ 8.SPECIAL 9.EXIT 2.
- Page 18 Operating Your Camera Enter a title, move the cursor to ’POS’ and press the SET button. The entered title appears on the screen. Select the position to display the title on the screen by using the 4 direction buttons and press the SET button. When the position is determined, select ’END’...
-
Page 19: Exit
Operating Your Camera COMM ADJ (Communication Adjustment): This function sets up the camera communication status when controlling the camera through an external control device. When the SPECIAL menu screen is displayed, press the Up and Down buttons so that the arrow indicates ‘COMM ADJ’. Set up the mode using the 4 direction buttons. -
Page 20: Specification
Troubleshooting Problem Solution The Motion Detection • Check that MOTION DEF of SPECIAL SETUP menu function does not is ‘OFF’. work. Color is not correct. • Check the setting of WHITE BAL SETUP menu . The screen flickers • Check that direction of camera turns toward the continually. -
Page 21: Dimension
Model Name Beginning Serial NO. Year of Manufacture Conformance to We, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s). Manufacturer SAMSUNG TECHWIN CO., LTD Signature Full Name YOUNG TAEK SON Position QUALITY CONTROL MANAGER Place... - Page 22 MEMO...
