Page 1: User Manual
DIGITAL COLOR DOME CAMERA user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsungsecurity.com SCC-B5366 SCC-B5368 SCC-B5366S SCC-B5368S... -
Page 2: Safety Information
Safety information CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit. - Page 3 fi re or electric shock. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifi cations or attempted repair.) When cleaning, do not spray water directly onto parts of the product.
- Page 4 Safety information FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation. Caution This equipment has been tested and found to comply with the limits for a Class A digital device, pursu- ant to part 15 of FCC Rules.
-
Page 5: Important Safety Instructions
Important Safety Instructions WARNING Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifi... -
Page 6: Table Of Contents
Contents 6 – DIGITAL COLOR DOME CAMERA Introduction Features Product & Accessories Part Names and Functions Installation Before installation Installation procedure Adjusting the camera direction How to use OSD Menu Using Icons in the Menu Main Menu Profi le Camera Setup Intelligence Privacy zone Setup Other Set... -
Page 7: Features
FEATURES ❖ High Resolution • This camera has realized high resolution of 600 lines using the top-notch full digital image processing and special algorithm technologies. ❖ Intelligent Motion Detection & Tracking • This is an intelligent function that automatically detects a motion of an object. You can set a virtual fence so it displays an alert if an object passes / enters /exits the virtual fence or virtual area. -
Page 8: Product & Accessories
Introduction ❖ Coaxial Cable Communication • This is a remote control function that overlaps the coaxial cable (for a transfer of the video signal) with the control signal. In installation or repair, this helps you control the communication controller (optional) without additional cabling. -
Page 9: Part Names And Functions
PART NAMES AND FUNCTIONS ❖ Components of your camera Introduction Test monitor output 테스트 모니터 출력 Lens 렌즈 Video connector 비디오 커넥터 Power connector 전원 커넥터 English –... - Page 10 Introduction Name Cover dome Covers the inner cover, lens, and main body to protect them. Inner cover Covers the main body to protect it. Push a long thin screwdriver into its narrow spot and press it outward when you want to Wing locker remove the inner cover.
- Page 11 ❖ Setting switches • SETUP Switch This switch is used to set the function or property. When this switch is pressed for at least 2 seconds, the MAIN MENU appears. (Left/Right) : By pressing this switch left or right, you can move left or right on the menu or change the (Up/Down) : By pressing this switch up or down, you can move up or down on the menu.
-
Page 12: Installation
Installation BEFORE INSTALLATION Before installing your camera, you have to read the following cautions. • You have to check whether the location (ceiling or wall) can bear fi ve times the weight of your camera. • Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise it may cause a breakdown or fi... - Page 13 ❶ Press the Locker button on the bottom of your camera and remove the Cover dome from the Main body using the other hand. The Main body and Inner cover will be exposed to you. ❷ To install and adjust your camera, you have to fi rst remove the Inner cover. To remove the Inner cover from the Main body, push a long thin screwdriver into the narrow spot of the Wing locker and press it outward to remove the cover.
-
Page 14: Adjusting The Camera Direction
Installation ADJUSTING THE CAMERA DIRECTION When the camera is fi xed on the ceiling, you can adjust the camera viewing angle. You can rotate your camera leftward or rightward (Panning), and can change the slope of your camera upward or downward (Tilting). In case of panning, the rotation limit of your camera is set to 355 degree (100 degree clockwise and 255 degree counterclockwise). -
Page 15: How To Use Osd Menu
USING ICONS IN THE MENU • (EXIT) Exits the menu setting. Before you exits the menu setting, select SAVE to save your settings, or select QUIT to cancel. • (RET) Returns to the previous menu. • (HOME) Returns to the main menu. •... -
Page 16: Profi Le
How to use OSD Menu PROFILE In the PROFILE menu, you can confi gure the following camera settings at once. CAMERA SET Menu STANDARD Previous Sub-menus Menu IRIS LENS LEVEL BACKLIGHT MOTION (F.FAST)--- SHUTTER SENS-UP AUTOx4 DAY/ AUTO NIGHT NIGHT BURST 16 –... - Page 17 CAMERA SET Menu STANDARD Previous Sub-menus Menu WHITE MODE ATW2 BLUE NIGHT User setting BRIGHTNESS allowed MODE User setting allowed User setting BLUE allowed DETAIL ❖ It will be set automatically so you can easily check the traffi c conditions. ❖...
-
Page 18: Camera Setup
How to use OSD Menu CAMERA SETUP CAMERA SET CAMERA ID IRIS MOTION (F.FAST)--- SHUTTER SENS-UP AUTO X4 FLICKERLESS DAY/NIGHT AUTO WHITE BAL DIGITAL ZOOM DETAIL V-SYNC (INT)--- AGC COLOR SUP REVERSE POSI/NEGA 18 – DIGITAL COLOR DOME CAMERA Setup the general functions of zoom camera module. Use the switch to select a menu item. - Page 19 LEVEL BACKLIGHT The LEVEL menu is used to adjust the overall brightness, where “+” will increase the brightness and “–” will decrease it. If you set the BACKLIGHT option to BLC, you will see a menu where you can set the BLC area.
- Page 20 How to use OSD Menu AGC FIX LEVEL [01] If you press the SETUP switch with a FIX sub menu selected, you will see the appropriate screen. As a fi xed value of the AGC gain is used in FIX mode, you can select one of the 16 detailed levels from VERY LOW to VERY HIGH before fi...
- Page 21 Note : If the SENS-UP function is set to AUTO, only items of – OFF and AUTO are available in the SHUTTER menu. If the SENS-UP mode is set to FIX, the SHUTTER menu – will be deactivated. If the FLICKERLESS function is set to ON, the SHUTTER menu –...
- Page 22 How to use OSD Menu If you press the SETUP switch with a NIGHT sub menu selected, you will see a menu where you can set Burst to OFF/ON. If BURST is set to ON, the Burst signal will output together with the black-and-white composite video signal.
- Page 23 You can specify MASK 1 and 2 simultaneously. The MASK is only for determining the mode switching, and any excessive bright area at night will be excluded by the confi gured MASK. Note : – If BACKLIGHT is set to BLC, the MASK AREA function will be deactivated.
- Page 24 How to use OSD Menu • ATW1(Auto Tracing White Balance mode 1): The camera can automatically adjust the color temperature in real time, according to the ambient conditions. The color temperature ranges from approx. 2500K to 9300K. • ATW2: The color temperature ranges from approx.
-
Page 25: Intelligence
❖ AGC COLOR SUP Adjust the color scheme according to the AGC value. ❖ REVERSE Mirrors video signals horizontally, vertically, or both. ❖ POSI/NEGA Output as it is or mirror the video brightness signal. ❖ Displays a sub image together with the main image on the same screen using the Picture In Picture function. - Page 26 How to use OSD Menu • FENCE This is to detect if a moving object passes through the specifi ed LINE or AREA. In a condition where a moving object is detected in an analysis of the previous and current frames whose movement overlaps a certain area, the system displays “PASS”...
- Page 27 - How to set the area PIXEL LEVEL <SIZE> <LOCATION> If you press the SETUP switch with the AREA option set to ON, you can specify the position and size of the area. If you change the PIXEL LEVEL for setting the position, specify the pixel that moves by a single pressure of the In <SIZE>, press the SETUP switch and use...
-
Page 28: Privacy Zone Setup
How to use OSD Menu ❖ DISPLAY [ON, OFF] With the DISPLAY option set to ON, a motion or a set ADVANCED function will be displayed on the screen, if detected. ❖ SENSITIVITY [1~7] Set the sensitivity of the motion detection. ❖... -
Page 29: Other Set
- How to set the point You can set each position of the 4 points. If you press the SETUP switch in <POINT>, you will see the points available in the PRIVACY ZONE. Each time you press the SETUP switch, the points available will move. Use the switch to set the position of each point. -
Page 30: System Information
How to use OSD Menu SYSTEM INFORMATION SYSTEM INFO TYPE 3_VAR_NOR_N SERIAL NO. 000000000000000 CAMERA VER. 0.50_090101 You can check the system information such as SERIAL NO and CAMERA VER. LANGUAGE LANGUAGE ENGLISH FRANÇAIS ESPAÑOL 日文 INGLÊS The camera supports 5 different languages. Select a preferred language. -
Page 31: Specifications
SPECIFICATIONS Items Sub-items Camera Type Device Image Pixels System Scanning Line Frame Scanning Internal Mode Horizontal Frequency Line-lock Mode Internal Mode Vertical Frequency Line-lock Mode Sens-up Min. Scene Illumination 512 times 512 times 512 times Number of Privacy Zone Day/Night Motion Detection eXtended Dynamic Range(XDR) D-Zoom... - Page 32 VBS 1.0Vp-p, 75 Ω Approx. 52dB Auto Iris (DC) SCC-B5366 : focal length = 2.5 to 6.0mm / Aperture ratio = F 1.2 SCC-B5368 : focal length = 2.8 to 11.0mm / Aperture ratio = F 1.2 0 ~ 355°(100° in CW(Clockwise) direction, 255°...
- Page 33 Items Sub-items Camera Type Device Image Total Pixels Effective System Scanning Line Frame Scanning Internal Mode Horizontal Frequency Line-lock Mode Internal Mode Vertical Frequency Line-lock Mode Sens-up Min. Scene Illumination 512 times 512 times 512 times Number of Privacy Zone Day/Night Motion Detection eXtended Dynamic Range(XDR)
- Page 34 VBS 1.0Vp-p, 75 Ω Approx. 52dB Auto Iris (DC) SCC-B5366 : focal length = 2.5 to 6.0mm / Aperture ratio = F 1.2 SCC-B5368 : focal length = 2.8 to 11.0mm / Aperture ratio = F 1.2 0 ~ 355°(100° in CW(Clockwise) direction, 255°...
